At A Glance
Samsung’s QET Series features intelligent upscaling technology to display all content in eye-catching UHD resolution. The powerful Crystal Display and a slim, modern design provide an enthralling viewing experience in virtually any business environment. The displays are economical and efficient, integrating with Samsung’s MagicINFO Lite software to provide users with a simple content management solution.
Powerful Crystal UHD delivers accurate and smooth color in brilliant 4K, no matter the source
Easily load, share and remotely manage content with MagicINFO Lite digital signage software
Sleek, elegant and minimalistic design with a super-slim bezel that keeps the focus on your content
Reliable commercial displays built to operate 16 hours a day, 7 days a week with a 3-year onsite warranty
FEATU
Powerful Crystal UHD Picture Quality
With an ultra-fast Crystal 4K processor and Crystal UHD resolution, you can capture your customer’s attention by showcasing lifelike images and intricate details better than ever before. Content will be displayed with more accurate and smoother color in brilliant 4K, no matter the source.
Load and Share Content With Ease
Each QET Series display leverages the integrated MagicINFO Lite Player to bring a range of on-demand or pre-scheduled images and videos to life. You can load new content either by connecting your personal laptop directly to the display’s built-in port or transferring from a compatible USB drive. For added convenience, the QET Series allows you to store content in a specific folder that will play without the need for separate scheduling.
Control Displays in Multiple Locations Instantly
A connection to the MagicINFO server allows remote monitoring and management of QET Series displays. Device information, content playback schedules, network data monitoring, time scheduling, alarms and various controls are all available remotely, without needing to be in front of the displays.
Slim and Modern Design
The sleek, elegant and minimalistic design helps to draw customers into the screen's content from any angle. And with a super-slim bezel, the QET Series keeps the focus on your content and blends seamlessly into virtually any business environment.
Full 3-Year Onsite Commercial Warranty, 16/7 Operation
Featuring an impressive 3-year onsite warranty, the QET Series is built to operate reliably 16 hours a day, 7 days a week.
- Product Specifications
Technical Specifications
Series Name
QET Series
Screen Size
55''
Panel Technology
55''
Resolution
3840 x 2160
Brightness
300 nit
Contrast Ratio (Typical)
4000:1
Contrast Ratio (Dynamic)
MEGA
Response Time
8ms (Typ.)
Operation Hours
16/7
Input
VIDEO: HDMI 2.0 (2)
HDCP: HDCP 2.2
AUDIO: Stereo Mini Jack, HDMI / Audio (Common)
USB: USB 2.0 (1)
Output
AUDIO: Stereo Mini Jack
External Control
RS232C(in) thru stereo jack, RJ45
Power Supply
AC 100 - 240 V~ (+/- 10 %), 50/60 Hz
Power Consumption (Typical/Max)
105 W/h (Typical) / 154 W/h (Max)
Power Consumption (Standby)
0.5 W/h
Operating Temperature
0℃~ 40℃
Operating Humidity
10~80%
Special
HARDWARE: Temperature Sensor, Clock Battery (168hrs Clock Keeping), Built-in Speaker (10W 2ch), IP5x Rating
SOFTWARE: Auto Source Switching & Recovery,
LFD Home UI, Button Lock, Hot Key Option, Plug & Play (Initial Setting)
SMART Signage Platform
Yes
Speaker Type
Built-in Speaker (10W + 10W)
Built-in Speakers
Yes
System On Chip
Yes
Processor
Cortex A72 1.7GHz Quad-Core CPU
On-Chip Cache Memory
L1 Instruction Cache : 48KB
L1 Data Cache : 32KB
L2 Cache : 2MB
Graphics
Graphic Resolution : 1920x1080
Output Resolution : 3840x2160 (Scale Up From Graphic Processing Result)
Storage
8GB
(3.88GB Occupied by O/S, 4.12GB Available)
Multimedia
VIDEO DECODER: MPEG-1/2/4, H.263, H.264/AVC, UHD H.264/AVC, VC-1, AVS+, HEVC, JPEG, PNG, VP8, VP9
AUDIO DECODER: AC3 (DD), MPEG
IO Ports
USB 2.0
Operating System
Tizen 4.0 (VDLinux)
Without Stand (W x H x D)
48.4” x 27.8” x 2.4”
Packaging (W x H x D)
54x.6” x 33.2” x 6.2”
Bezel Width
3 Bezel-less
Product Weight
31.1 lbs
Package Weight
42.4 lbs
Included in Box
Quick Setup Guide, Warranty Card,
Power Cord, Remote Controller, Batteries
Optional Wall Mount Kit
WMN4070SE
Optional Stand
STN-L4355F
Optional Touch Overlay
CML400XK
VESA Mount
200 x 200
