Allsee M65UHD4 – 65" 4K Large Format Commercial Display
Ultra-high definition professional monitors with built-in 4K Android media player
Lightweight Design
By using less and lighter materials this generation is considerably lighter than the previous version, making installation and maintenance much more convenient.
Remarkable 4K Display
With four times the resolution of Full HD you can achieve a truly immersive experience with an incredible image quality. The 4K resolution is now compatible with the integrated Android Media Player, our CMS software, HDMI channels and third party devices, giving you ultimate flexibility.
Integrated Android Media Player
There is an integrated 4K Android media player inside the screen allowing you to upgrade to a network version without needing any additional hardware. You can also install third party Android apps if required.
24/7 Commercial Use
These displays use a commercial grade LCD panel and LED backlight. They have the ability to be in constant use 24/7 for over 70,000 hours and have no external buttons or controls to avoid tampering.
Plug and Play
Plug and Play is the most straightforward way to upload content to the screen. Simply load images and videos on a USB stick, insert in the display, wait for your content to copy over and then remove. Your images and videos will now play in a continuous loop.
Slim Bezel
The screens feature an extremely sleek and narrow bezel meaning that the enclosure to display area ratio is very low. The front is crafted from segmented aluminium to achieve ultimate precession while the polymer rear keeps the display super slim and lightweight.
Connect Devices
Should you need to use the screen as a monitor you can connect it to an external source, like a PC or media player, using the HDMI input.
Eco-Friendly Power Timer
The eco-friendly power timer allows you to assign daily or weekly on and off times for your screen meaning that it is only in use when it needs to be; improving your environmental efficiency.
Built-In Speakers
Take your digital signage solution to the next level by adding an audio element using the two integrated slimline speakers.
-
Category |
Attribute |
Value |
Display |
Resolution |
3840x2160 (4K UHD) |
|
Display Area |
1428.5x803.5 mm |
|
Brightness (cd/m²) |
450 |
|
Contrast Ratio |
1200:1 |
|
Aspect Ratio |
16:9 |
|
Viewing Angle |
178° |
|
Colour |
1.07 Billion |
Dimensions |
Unit Size (WxHxD) |
1463.2x838.3x76.4 mm |
|
With Wi-Fi Module |
1463.2x845.4x76.4 mm |
|
Package Size |
1623x950x212 mm |
|
VESA Holes |
600x400 M8 |
Weight |
Net Weight |
23.54 kg |
|
Gross Weight |
31.84 kg |
Power |
Avg. Power Consumption |
<330 W |
Audio |
Speaker Type |
2 x 10W |
AV Ports |
HDMI In |
x3 |
|
HDMI Out |
x1 |
|
USB |
USB 2.0, USB 3.0, USB-C |
|
Others |
Audio Out, SPDIF, RS-232, RJ45 In/Out |
Environmental |
Operating Temp |
0°C to 40°C |
|
Storage Temp |
-20°C to 60°C |
|
Operating Humidity |
10% to 90% |
|
Storage Humidity |
10% to 90% |
Media Player |
Media Formats |
Video, Audio, Image |
|
Media Resolution |
3840x2160 |
Computer |
CPU |
A55×4 (64-bit) |
|
RAM |
4GB |
|
GPU |
Mali G52MP2 |
|
Storage |
32GB eMMC |
|
USB |
USB 2.0, USB 3.0 |
|
LAN |
100/1000 Ethernet |
|
Wi-Fi |
802.11b/g/n/ac (2.4G & 5G) |
|
OS |
Android 11 |
Accessories |
Included |
Remote, Manual, Power Lead |
|
Optional |
Network Upgrade |
-
Warranty
3-year warranty.
All standard product ranges come with a 3 year warranty starting from date of invoice.
Any warranty extension needs to be completed at point of order and should be clearly noted on the sales invoice.
Covers hardware failure but excludes accidental damage or user error.
All screen sizes up to and including 55”, as well as media players, are covered by a swap-out warranty. There may be some situations (such as not having a particular model in stock) where an advanced replacement product cannot be supplied, in these cases a collection, repair and return service will be implemented. Screens larger than 55” and freestanding models (“L” and “OT” ranges only, excluding “LUHB”, “LHDS”, “TAO”, “AB” and “OAB” ranges) are covered by an on-site service.
-
