Zebra 220Xi4 300dpi Industrial Label Printer | 223-80E-00003
SKU: 223-80E-00003
£5,835.21 (Excl. VAT)
- Description
- Specifications
-
Zebra 220Xi4 300dpi Industrial Label Printer | 223-80E-00003
Designed to produce large labels up to 8.5” (216 mm) wide at 10” (254 mm) per second at 203 dpi and 6" per second at 300 dpi (152 mm) resolution, the 220Xi4 is ideal for industrial applications—chemical drum (HAZMAT) identification labels, pallet/container shipping labels and product identification labels for large rolls of paper or textiles.
In addition, the Xi4 provides the following new features:
LCD content customizable to user needs.Large, easy to use, multilingual LCD screen.
Flexible connectivity including simultaneous parallel/Ethernet with internal Ethernet included as standard in the product.
Advanced ribbon- and media-low LCD/e-mail alerts.
Intelligent printhead system.
Benefits
Faster Ethernet performance with Internal ZebraNet 10/100 PrintServer - included standard.Handles everything from paper to specialty label/tag stocks.
Satisfies high-volume label requirements.
Offers a wide range of connectivity solutions.
Standard Features
Print methods: Thermal transfer or direct thermal.Construction: 12-gauge steel frame.
Single 32 bit 133 Mhz RISC processor.
16 MB SDRAM; 8 MB non-volatile Flash memory.
Automatic media/ribbon sensing capability.
Improved head test for element out.
Auto calibration.
Clear media side door for ease of supplies monitoring.
300 unique darkness settings.
RS-232, Parallel ports.
USB 2.0 port.
Internal ZebraNet 10/100 PrintServer.
ZPL or ZPL II Programming Language.
XML enabled printing.
Mirror feature allows user-defined printer configurations to be retrieved from the network.
Create and design customizable printer LCD menus.
Large (240W x 128H pixels), multilingual, backlit, graphical LCD display.
Transmissive and reflective media sensors.
Multi-level Element Energy Equalizer (E3) for superior print quality.
Unicode™ - Compliant.
Intelligent printhead.
-
Feature Description Brand Name Zebra Model 220Xi4 300dpi Print Technology Direct thermal / Thermal transfer Maximum Resolution 300 x 300 DPI Colour Printing No Flash Memory 8 MB Internal Memory 16 MB Supported Paper Width 21.6 cm (8.5") Maximum Media Length 99.1 cm (39") Media Thickness 0.076 - 0.305 mm (0.003 - 0.012") Maximum Roll Diameter 8.13 cm Core Diameter 2.54 cm Ribbon Length 300 m Built-in Barcodes Code 39, 49, 93, MaxiCode, PDF417, Postnet, QR Code, UPC-A, UPC-E Connectivity Technology Wired Standard Interfaces Ethernet, USB 1.1, RS-232, Parallel USB Ports 1x USB 1.1 RS-232 Ports 1 Parallel Ports 1 Power Requirements 90 - 264 VAC, 48 - 62 Hz Operating Temperature 5 - 40 °C Storage Temperature -40 - 60 °C / -40 - 140 °F Operating Humidity 20 - 85 % Storage Humidity 5 - 85 % Dimensions (WxDxH) 401.6 x 517.5 x 393.7 mm Product Width 51 cm Product Depth 60.5 cm Product Height 55.5 cm Net Weight 39.28 kg (72 lbs) Gross Weight 39.98 kg Certifications BSMI, CE, FCC Class B, VCCI, KCC, CCC, GOST-R, NOM, and others ECCN Code (US) EAR99 ECCN Code (EU) N/A HS Code 84433210 Warranty 2 Years Page Description Languages XML, ZPL II
