Aurora VPX-TC1-Pro 4K60 4:4:4 1Gbps AV-over-IP Transceiver Box
This Aurora VPX-TC1-Pro 4K60 4:4:4 1Gbps AV-over-IP Transceiver Box provides one of the most advanced 1G IP Streaming solutions on the market utilizing Aurora new Mimix CODEC technology. Mimix compression allows for near perfect reproduction of video and graphic images at resolutions up to 4K60 4:4:4 over 1G networks. It has only one frame (16.6ms) of latency and seamless switching for fast lag free content. Power consumption is important as the VPX-TC1 uses as little as 8 watts. It does this with no fan and a small form factor saving a lot of money in utility bills as it uses 1/3 the power of comparable systems.
Features
Configure as Encoder or Decoder
4K60 4:4:4 UHD 120m over 1G CAT 5e
HDMI 2.0b, HDCP 2.2/2.3
HDR10, HDR10+, Dolby Vision
LPCM up to 12-channels, Dolby Digital Plus, Dolby TrueHD DTS HD Master Audio, Dolby ATMOS
12 bits color depth processing, 16bits OSD
Enterprise Security (AES 256, HTTPS, SSH, etc)
One Frame Latency (16.6ms)
Low Power Fanless Design
Seamless Switching
MJPEG Preview at up to 30 frames
Video Wall with Image Rotation
1G LAN PoE and SFP for Fiber or Second RJ-45
2 HDMI Inputs, 1 HDMI Output
Line In/Out Stereo, Audio Fiber Output, & eARC
RS-232 Serial Port and IR (In/Out)
Channel Mapping with On Screen Display (OSD)
Integrated Web Server for Configuration
1 x USB 2.0 Type C (Host for Camera)
1 x USB 2.0 Type C (Host for HID/Mass Storage)
1 x USB 2.0 Type A (Camera)
2 x USB 2.0 Type A (HID/Mass Storage Devices)
Dante IP 2/8 Ch Audio Option
Audio DSP & eARC
ReAX Control Option
Warrenty: 60 Months -
Feature Description Compression Mimix™ 8:1 Latency 1 Frame (16.6ms) HDMI Inputs 2 (HDMI 2.0b, HDCP 2.2) HDMI Outputs 1 (HDMI 2.0b, HDCP 2.2) Encryption AES 256 Analog Audio Stereo Line In/Out (3.5mm TRS) 1G Ethernet RJ-45 and SFP LAN RJ-45 10/100/1000 PoE Video Bandwidth 600MHz Video Support Up to 4K2K 4:4:4 @ 60Hz Audio Support Up to 12 Channels RS-232 Up to 115k Baud (3.5mm TRS) IR Bi-Directional (3.5mm TRS) USB Connectors 1x USB 2.0 Type C, 1x USB 1.1 Type C, 1x USB 2.0 Type A, 2x USB 1.1 Type A Expansion Port Dante® 2Ch/8Ch and ReAX™ Interface IR or Keyboard via OSD, Web Server Housing Black Aluminum Enclosure Dimensions 177.04 x 150.7 x 26.42mm [6.97” x 5.93” x 1.04”] Weight 0.453kg [1lbs] Mounting Rack/Under Table Mount (optional) Power Supply 48V DC or PoE+ (LAN) Power Consumption 8W (up to 12.9W with USB) Operating Temp 0~40°C [32~104°F] Storage Temp -20~60°C [-4~140°F] Humidity 20~90% RH (No Condensation) -
Description Downloads Aurora VPX-TC1-Pro 4K60 4:4:4 1Gbps AV-over-IP Transceiver Box SpecSheet Downloads Aurora VPX-TC1-Pro 4K60 4:4:4 1Gbps AV-over-IP Transceiver Box User Guide Downloads
