NovaStar NovaPro UHD Jr All-in-One Controller

SKU: NOVAPROUHDJR
NovaStar NovaPro UHD Jr All-in-One Controller NovaStar Video Switches NovaStar
Availability:
Out of stock
🚚 Order before 3PM, get it by tomorrow.
Sold out

£4,931.57 (Excl. VAT)

- £5,917.88 (Inc. VAT)
£4,931.57 - £4,931.57
- - £5,917.88
Availability:
Out of stock
payment-icons

Bulk Price & Price Match Request

Contact our expert sales team on 020 8191 9223 for best price and dedicated assistance.

Educational & Public Sector Prices Available

For more details, please call us at 020 8191 9223 or email us at info@screenmoove.com

  • Description
  • Specifications
  • Downloads

  • NovaStar NovaPro UHD Jr All-in-One Controller

    NOVAPROUHDJR

    The NovaPro UHD Jr is a NovaStar’s new all-in-one controller that features excellent video processing capabilities, sending card functions and LED screen configurations.

    The NovaPro UHD Jr provides a variety of video input connectors, supporting 4K×2K@60Hz image processing and sending capabilities.

    With the help of smart control software V-Can from Novastar, the NovaPro UHD Jr can enable richer image mosaic effects and faster and easier operations.

    The NovaPro UHD Jr can send the processed video to the LED screen via Neutrik Ethernet ports and optical fiber ports. Thanks to its powerful video processing capabilities and sending functions, the NovaPro UHD Jr is well suited for stage control systems, conference sites, activities, exhibition sites and other high-end rental applications as well as fine-pitch LED displays.

  • Category Specification
    Inputs
    DVI 4x Single-link DVI (Max Res: 2048x1152@60Hz)
    12G-SDI 2x 12G-SDI (Max Res: 4096x2160@60Hz)
    DP 1.2 1x DP 1.2 (Max Res: 3840x2160@60Hz)
    HDMI 2.0 1x HDMI 2.0 (Max Res: 3840x2160@60Hz)
    Outputs
    Ethernet Ports 16x Neutrik Gigabit (Max: 10,400,000 pixels)
    OPT Ports (10G) 4x Optical (Copy & Hot Backup Modes)
    HDMI 2.0 Loop 1x HDMI Loop Output
    12G-SDI Loop 2x SDI Loop Outputs
    Monitor 1x HDMI (1920x1080@60Hz)
    Control Ports
    Ethernet 1x RJ45 (PC/Web Communication)
    USB Type-B 1x for PC Control
    USB Type-A 1x for Image Mosaic
    Genlock In/Loop 1x Genlock Sync Input
    RS232 1x for Central Control
    Special Features
    DVI Mosaic 4 DVI Inputs can form a single input source
    HDR Output Enhanced image clarity and vividness
    Decimal Frame Rates Supports 23.98, 29.97, 59.94 fps
    Low Latency Output Reduces latency with NovaStar Armor Receivers
    Custom BKG Settings Pure Color and Image Backgrounds
    Image Scaling Full Screen, Pixel-to-Pixel, Custom Scaling
    Capture Function Captures input image for BKG use
    Image Mosaic Connect up to 4 units for large screens
    V-Can Software Compatible for Smart Control
    User Presets Supports up to 10 User Presets
    EDID Management Custom and Standard EDID Support
    Electrical Specs
    Power Supply AC 100-240V, 50/60Hz
    Max Power Consumption 60W
    Mechanical Specs
    Dimensions (W x H x D) 440 x 50 x 320 mm
    Weight 4.5 kg (9.92 lbs)
    Cooling Active
    Rack Units 1U Standard Rack Size
    IP Rating IP20 (Indoor Use Only)
    Max Ambient Temp 60°C (140°F)
    Min Ambient Temp -10°C (14°F)
    Operating Humidity 20-90% RH
    Included Items DVI Cable, HDMI Cable, USB Cable, IEC Power Cable
