Synology DiskStation NAS/Storage Server Desktop - Secure Digital Content With A Modern Look | DS620SLIM
Mini Private Server Combining Performance and Style
DS620slim is a mini 6-bay NAS with a stylish chassis design, perfectly blending in modern workplaces or apartments. Supporting near-instantaneous snapshot technology and real-time 4K video transcoding, DS620slim is an all-around file management solution that fulfills professionals’ needs of advanced data protection and high-quality media streaming.
Remain classic while shrinking footprint
The mini 6-bay design keeps DS620slim classic and saves deployment space. With six 2.5" drive support, DS620slim is able to boost performance by installing SSDs.
Compact Design
Mini design with the dimensions of 121 x 151 x 175 mm, flexible to fit in anywhere
RAID Flexibility
Flexible in a variety of RAID configurations to realize maximum 30TB raw capacity or better data protection with RAID 5/6/10
SSD Cache Support
Further enhance storage performance with SSD read/write cache while still having abundant drive bays for data storage
Btrfs: Next generation storage efficiency
Btrfs file system introduces the most advanced storage technologies to meet the management needs of modern large scale businesses:
Flexible Shared Folder/User Quota System provides comprehensive quota control on all user accounts and shared folders
Snapshot Replication provides schedulable and storage capacity-saving data protection with 1,024 shared folder backups and 65,000 system-wide snapshots
File or folder level data restoration makes data recovery fast and flexible
Automatic file self-healing detects and recovers corrupted files without user intervention
Learn more about the benefits of using Btrfs
Ultimate file management and sharing
File Station is a web-based, fast and secure management tool built to allow easy, drag-and-drop operations without requiring any complex setup on Mac or PC. Advanced search and filtering tools allow for easy organization and file sharing. For complete compatibility, DS620slim supports the following protocols: AFP, FTP, iSCSI, NFS, SMB, and WebDAV.
Synchronize files across your devices
Cloud Station Suite provides real-time data synchronization across all your devices and other Synology NAS. "Intelliversioning" keeps the most important file versions to better utilize storage space.
4K Multimedia Server
Access and stream your 4K media content anytime and anywhere. DS620slim supports 4K H.264/H.265 online transcoding via Video Station and DS video, allowing 4K videos to be converted and played on the fly on other computers, smartphones, and media players that originally do not support Ultra HD formats.
-
| Category |
Specification |
| Battery |
|
| Battery Type |
UN3091 - Lithium METAL inside equipment |
| Lithium Weight (g) |
0.064 g |
| Certificates |
|
| Certification |
BSMI/CCC/CE/EAC/FCC/KC/RCM/UL/VCCI |
| Design |
|
| Chassis Type |
Desktop |
| Cooling Type |
Active |
| Fan Diameter |
8 cm |
| LED Indicators |
Yes |
| Number of Fans |
1 fan(s) |
| Product Colour |
Black |
| Graphics |
|
| Max Graphics Memory |
8 GB |
| Displays Supported |
3 |
| Graphics Base Freq. |
250 MHz |
| Graphics Burst Freq. |
700 MHz |
| Legal Information |
|
| EU ECCN Code |
N/A |
| UNSPSC Code (Icecat) |
43201835 |
| US ECCN Code |
5A992 |
| Logistics Data |
|
| HS Code |
84714100 |
| Memory |
|
| Internal Memory |
2 GB |
| Memory Type |
DDR3L |
| Max RAM Supported |
6 GB |
| Memory Slots |
2 |
| Network |
|
| Ethernet LAN |
Yes |
| Ethernet LAN Rates |
10/100/1000 Mbit/s |
| iSCSI Support |
Yes |
| Network Protocols |
CIFS, AFP, NFS, FTP, WebDAV |
| Wake-on-LAN Ready |
Yes |
| Wi-Fi |
No |
| Operational Conditions |
|
| Operating Temp (°C) |
5 - 40 °C |
| Storage Humidity |
5 - 95 % |
| Storage Temp (°C) |
-20 - 60 °C |
| Package Dimensions |
|
| Depth |
20.6 cm |
| Gross Weight |
2.168 kg |
| Height |
18.9 cm |
| Width |
23 cm |
| Packaging Content |
|
| Cables Included |
AC/LAN (RJ-45) |
| Quick Start Guide |
Yes |
| Performance |
|
| Backup Function |
Yes |
| Device Class |
Small & Medium Business |
| Multilingual Support |
Yes |
| Noise Level |
20.5 dB |
| Number of Users |
1000 user(s) |
| Type |
NAS |
| Ports & Interfaces |
|
| eSATA Ports |
2 |
| Ethernet Ports |
2 |
| USB Ports (Type-A) |
2 |
| USB Port |
Yes |
| Power |
|
| AC Input Freq. |
50 - 60 Hz |
| AC Input Voltage |
100 - 240 V |
| PSU Capacity |
65 Watt |
| Power Consumption |
34.88 Watt |
| Processor |
|
| Processor Model |
Intel® Celeron® J3355 |
| Processor Cores |
2 |
| Processor Freq. |
2 GHz (Base), 2.5 GHz (Boost) |
| Processor Cache |
2 MB Smart Cache |
| Storage |
|
| Storage Drive Type |
No |
| Max Storage Capacity |
108 TB |
| RAID Support |
0/1/10/5/6/JBOD |
| Drive Sizes Supported |
2.5 " |
| Drive Types |
HDD & SSD |
| File Systems |
BTRFS/exFAT/ext3/ext4/Fat/HFS+/NTFS |
| Vendor Info |
|
| Brand Name |
Synology |
| Warranty |
2 Year(s) |
-
