Elo Touch Solutions 1004L 10.1" 10TP Touchscreen Monitor | E968703
SKU: E968703
£281.42 (Excl. VAT)
- Display Size10"
- Touch Capabilities10pt multi-touch
- Net Weight1 kg
- Operating SystemNone
- VESA Patterns75x75
- Panel TypeTFT Panel
- ResolutionWXGA
- Screen TypeFlat
- Response Time30ms
- Screen Ratio16:10
- Brightness360 cd/m2
- Operating HoursN/A
Book a Free Product Demo
Remote or on-site. No obligation.
Integrator or Installer?
Trade pricing, volume discounts, same-day collection.
Education & Public Sector Solutions
Exclusive pricing, flexible terms, and dedicated support for schools, universities, NHS, and government organisations.
- Description
- Specifications
- Downloads
-
Elo 1004L 10" Touchscreen Monitor | PCAP 10-Touch, 360 nits, USB-C & Edge Connect
1004L 10-inch Touchscreen Monitor
The 1004L touchmonitor delivers a stunning design, enhanced durability, increased touch accuracy and brilliant display clarity. With state-of-the-art optical bonding and IP54-sealed design, the 10” touch monitor offers a feature-rich platform and the versatility to extend across a diverse range of applications from point-of-sale, self-service and kitchen display systems to warehouse automation, access control and HMI.
Create the perfect payment stack with the 10" touchscreen.
Easily pair the 10-inch touchscreen monitor with one of Elo's integrated payment devices - from Elo Pay mobile computers to the Elo Pay 7", the 1004L offers the perfect compact touch display with the connectivity you need at the point of sale.
State of the art optical viewing.
Designed with high quality optical bonding, anti- glare coverglass and low-blue light settings - the 1004L 10-inch touchscreen monitor brings the best-in-class solution for viewing comfort and clarity.
Secure your cables into place.
Never lose your port covers and screws with the security of the captive design. With a port cover that locks into place, cables are
less prone to becoming disconnected, resulting in minimal disruptions to the device.
Connect accessories to the edge.
Elo Edge Connect™ offers an expansive lineup of accessories that seamlessly attach to the edge of the display including - EMVs, barcode scanners, status lights, cameras, RFID, MSR, fingerprint scanner and more.
Navigate the OSD directly on the touchscreen.
The on-screen display (OSD) controls are now directly on the touchscreen - making navigation easier while still offering OSD lock security.
Expand the possibilities with touch through.
Elo's TouchPro PCAP monitors feature touch through capability, supporting use with gloves and additional layers of films and filters to meet specific industry requirements. -
Feature Description Part Number(s) PCAP - E968703
Non-Touch - E315290Enclosure Color Black Touch Technology & Capacity Non-Touch
PCAP (Projected Capacitive) - 10 TouchDiagonal Size 10.1'' diagonal, Active matrix TFT LCD (LED) Aspect Ratio 16:10 Active Area 8.54" x 5.34" / 216.96 mm x 135.6 mm Resolution 1280 x 800 Other Supported Resolutions 640x480 60Hz, 800x500 60Hz, 800x600 60Hz,
1024x768 60Hz, 1280x720 60Hz, 1280x800 60Hz, 60Hz RB,
1920x1080 60Hz, 1920x1200 60HzViewing Angle Horizontal: ±85° (170° total)
Vertical: ±85° (170° total)Number of Colors 16.7 million Brightness (typical) LCD panel: 400 nits
PCAP: 360 nitsResponse Time 30 msec (typical) Contrast Ratio 800:1 Touch Interface USB Surface Treatment Anti-glare Speakers 2 x 2W internal Power Consumption ON: 6.5W
SLEEP: 0.5–1.0W
OFF: 0.25WDimensions (w/o Stand) 9.80" x 6.61" x 0.98" / 249 mm x 168 mm x 25 mm Weight Unpackaged: 0.90 kg
Packaged: 2.2 kgOperating Temp 0°C to 40°C / 32°F to 104°F Ingress Protection IP54 Impact Protection IK07 Warranty 3 years (extended options available) What's in the Box Touchmonitor, Quick Install Guide, EU & UK EEI Labels,
HDMI cable, USB-A to C cable, Power brick,
NA & EU Power cables -
Description Downloads Elo Touch Solutions 1004L 10.1" 10TP Touchscreen Monitor | E968703 DataSheet Download
