Elo 1790L 17" SXGA Class Open-frame TFT LCD Touchscreen Monitor
SKU: E326942
£427.99 (Excl. VAT)
- Display Size17"
- Touch CapabilitiesSingle-Touch
- Net Weight3.6 kg
- Operating SystemNone
- VESA Patterns100x100
- Panel TypeTFT Panel
- ResolutionSXGA
- Screen TypeFlat
- Response Time5ms
- Screen Ratio5:4
- Brightness200 cd/m2
- Operating Hours24/7
Book a Free Product Demo
Remote or on-site. No obligation.
Integrator or Installer?
Trade pricing, volume discounts, same-day collection.
Education & Public Sector Solutions
Exclusive pricing, flexible terms, and dedicated support for schools, universities, NHS, and government organisations.
- Description
- Specifications
- Downloads
-
Elo 1790L 17" Open-Frame Touchscreen Monitor | SXGA 1280x1024 | AccuTouch/IntelliTouch | HDMI VGA DP USB
The Elo 1790L 17-inch open-frame LCD touch display features a slim design and narrow outside dimensions thanks to the state-of-the-art, energy-saving LED backlight, using less electricity to operate and generating less heat. This compact touch display is designed for touch with proven Elo expertise and reliability built in. The 1790L provides stable, drift-free operation with outstanding image clarity and light transmission-for accurate touch responses and vivid images. Instantly grabbing and holding users' attention, the 17-inch open frame is perfect for kiosks, casino and amusement, retail self-service, and industrial automation environments.
Easily integrated.
The touchscreen is sealed against dirt, dust and liquids, which simplifies integration into the final enclosure. Projected capacitive (PCAP) units can be sealed into a solution and obtain an IP65 rating on the front side of the unit. With the design and tooling being controlled by Elo, long-lasting product availability can be expected.
Touch ready.
The 1790L is available with a choice of industry-leading touch technologies, in both single touch and multi touch versions. The seamless zero-bezel 17-inch multi-touch display is available with our latest multi-touch TouchPro™ PCAP two-glass solution (2GS) technology has a zero-bezel that delivers both a 10-touch tablet-like experience along with two-touch thru-glass functionality-both modes support single or dual latex gloves as well as cloth gloves. Standard bezel, single-touch display options include AccuTouch® five-wire resistive, IntelliTouch® SAW or SecureTouch® anti-vandal SAW.
Commercial-grade.
The Elo open frame touchscreen display delivers the quality and reliability Elo is known for, and is backed by our three-year standard warranty. We design, build and are responsible for the complete solution with touch integrated from the start. Using our own touchscreens combined with our software and drivers, everything is designed to work together and is tested as part of our life testing processes. All of our products go through rigorous reliability testing (over 20 tests) to deliver 50,000 MTBF. -
Feature Description Part Numbers IntelliTouch (Worldwide) - E326942
AccuTouch (Worldwide) - E326347Enclosure Color Black Touch Technology IntelliTouch® SAW – Single Touch
AccuTouch® 5-Wire Resistive – Single TouchTouch Interface Dual Serial/USB 2.0 Diagonal Size 17'' diagonal, Active matrix TFT LCD (LED) Aspect Ratio 5:4 Active Area 13.3" x 10.6" / 337.92 mm x 270.336 mm Resolution 1280 x 1024 Brightness (typical) IntelliTouch: 225 nits
AccuTouch: 200 nitsResponse Time 5 msec Contrast Ratio 1000:1 Viewing Angle Horizontal: ±85° (170° total)
Vertical: ±80° (160° total)Number of Colors 16.7 million I/O Ports USB Type B · Serial Port (Bezel models only) · RJ45 (OSD remote key) · VGA · HDMI · DisplayPort · 12V DC in Power Consumption ON (75% Brightness): 8.52 W · ON (100% Brightness): 9.90 W · Sleep: 1.5 W · Off: 0.5 W Dimensions Bezel: 14.50" x 12.06" x 1.87" / 368.4 mm x 306.4 mm x 47.5 mm Shipping Box Dimensions 18.74" x 16.46" x 7.21" / 476 mm x 418 mm x 183 mm Weight Unpackaged: 7.94 lbs / 3.6 kg
Packaged: 12.35 lbs / 5.6 kgOperating Temperature 0°C to 40°C / 32°F to 104°F Storage Temperature -20°C to 60°C / -4°F to 140°F Humidity Operating: 20% to 80% · Storage: 10% to 95% MTBF 50,000 hours demonstrated Sealability Touchscreen sealed to bezel and LCD Mounting Options 75 mm & 100 mm VESA · 2-hole side mounting · Front/Rack mount with optional bezel kit Warranty 3-year (Extended service options available) Regulatory Approvals UL, FCC, CE TUV, UKCA, CCC, VCCI, KCC, NOM, BSMI, RCM, IC, CB, EAC, RoHS, WEEE What's in the Box HDMI Cable · VGA Cable · RJ45 OSD Remote · USB Cable · Quick Install Guide · Brackets & Screws (depending on model) -
Description Downloads Elo 1790L 17" SXGA Class Open-frame TFT LCD Touchscreen Monitor DataSheet Download Elo 1790L 17" SXGA Class Open-frame TFT LCD Touchscreen Monitor User Manual Download Elo 1790L 17" SXGA Class Open-frame TFT LCD Touchscreen Monitor Quick Installation Guide Download
