BOSE FreeSpace 3 Series II Acoustimass Bass Module
SKU: 843090-0110
£347.52 (Excl. VAT)
Book a Free Product Demo
Remote or on-site. No obligation.
Integrator or Installer?
Trade pricing, volume discounts, same-day collection.
Education & Public Sector Solutions
Exclusive pricing, flexible terms, and dedicated support for schools, universities, NHS, and government organisations.
- Description
- Specifications
- Downloads
-
Bose FreeSpace 3 Series II Acoustimass Bass Module – 5.25" Woofer, 200W, Deep Non-Localized Bass for Commercial Audio
Designed to provide flush-mount bass augmentation for new and existing background music systems. Features one 5.25-inch (133 mm) woofer that delivers deep bass down to 40 Hz without audible distortion. For indoor applications only.
FEATURES
Low-frequency loudspeaker featuring one 5.25-inch (133 mm) woofer that delivers deep, non-localized bass support down to 40 Hz without audible distortion. For flush, ceiling, pendant and wall-mount applicationsAcoustimass speaker technology filters out audible distortion to deliver non-localized bass
Designed to work with the FreeSpace 3 flush and surface satellite speakers, or existing systems where additional bass reinforcement is desired
Module design allows parallel connection of multiple bass modules and can accommodate two or four FreeSpace 3 satellites per bass module
Plenum rated for use in air handling spaces (with optional plenum cover)
Selectable 70/100V or low impedance with transformer tap adjustment under speaker grille
Applications
Designed for a wide range of applications, including:Retail stores
Restaurants and bars
Lobbies and conference rooms
-
Category Specifications PHYSICAL Colors Black, white Enclosure Material PC/ABS Environmental Testing Indoor only Grille Material Expanded metal Mounting/Rigging Provisions (4) mounting arms, (3) suspension/safety cable attachment points Net Weight 14.0 lb (6.4 kg) Product Dimensions (H×W×D) 15.4 in × 7.4 in (391 mm × 189 mm), loudspeaker diameter × depth / 14.3 in (362 mm), ceiling hole diameter Shipping Weight 20.0 lb (9.1 kg) PERFORMANCE Frequency Range (-10 dB) 40 Hz – 315 Hz Coverage, Horizontal Omnidirectional below 200 Hz Maximum SPL at 1 m Per channel: 96 dB continuous, 102 dB peak / Mono: 102 dB continuous, 108 dB peak Nominal Impedance 6 Ω mono direct (transformer bypassed) Power Handling, Continuous 70/100 V: 200 W mono / Low impedance: 50 W per channel stereo or 100 W mono Power Handling, Peak 70/100 V: 800 W peak mono / Low impedance: 200 W peak per channel stereo or 400 W peak mono Recommended Signal Processing Recommended Sensitivity (SPL/1 W at 1 m) Per channel: 76 dB / Mono: 79 dB Transformer Taps, 100V 25 W, 50 W, 100 W, 200 W Transformer Taps, 70V 25 W, 50 W, 100 W, 200 W Coverage, Vertical Omnidirectional below 200 Hz TRANSDUCERS Driver Protection Recommended high-pass filter 40 Hz high-pass filter Low-Frequency Transducer Quantity and Size 5.25 in (133 mm) dual-voice-coil low-frequency driver -
Description Downloads BOSE FreeSpace 3 Series II Acoustimass Bass Module DataSheet Downloads
