Blackmagic Design Video Assist 5 inch 12G HDR | HYPERD/AVIDA12/5HDR
SKU: HYPERD/AVIDA12/5HDR
£443.35 (Excl. VAT)
- Description
- Specifications
-
Blackmagic Design Video Assist 5 inch 12G HDR | HYPERD/AVIDA12/5HDR
Blackmagic Video Assist 5” 12G HDR adds professional monitoring and recording to any SDI or HDMI camera in all HD, Ultra HD, 2K and 4K DCI formats! The super bright 2500nit 5 inch HDR monitor supports 3D LUTs and features professional scopes along with powerful focus assist and exposure tools that help you accurately set focus, exposure and frame shots. The built in SD card recorder save files in broadcast quality 10‑bit 4:2:2 ProRes or DNx formats. The files are all standard, so you can start editing immediately without having to convert them! -
Blackmagic Video Assist 5" 12G HDR Specifications
Feature Details Connections SDI Video Inputs 1 x Micro BNC SDI Video Outputs 1 x Micro BNC HDMI Video Inputs 1 x HDMI 2.0a HDMI Video Outputs 1 x HDMI 2.0a Analog Audio Inputs None Analog Audio Outputs 1 x 3.5mm headphone jack (mono) Built-in Speaker Mono Screen Dimensions 5 inch, 1920 x 1080 resolution Screen Brightness 2500 nits Screen Color P3 wide color gamut SDI Audio Inputs 16 channels embedded via 12G-SDI SDI Audio Outputs 16 channels embedded via 12G-SDI HDMI Audio Inputs 8 channels embedded via HDMI 2.0a HDMI Audio Outputs 8 channels embedded via HDMI 2.0a Remote Control None SD Interface 1 x UHS-II SD slot Storage Type Removable SDXC UHS-II, SDXC UHS-I and SDHC UHS-I SD cards Computer Interface 1 x USB Type-C 3.1 Gen 1 for external drive recording, webcam output, software updates & control SDI Video Standards SD Video Standards NTSC & PAL formats HD Video Standards Extensive list from 720p to 1080i60 2K Video Standards DCI formats at various frame rates (progressive & PsF) Ultra HD Video Standards Up to 2160p60 4K Video Standards DCI formats at various frame rates SDI Compliance Various SMPTE standards SDI Metadata Support HD RP188 Audio Sampling 48 kHz, 24-bit Video Sampling 4:2:2 YUV Color Precision 10-bit Color Space REC 601, REC 709, REC 2020 HDR Support HDR10, Hybrid Log Gamma Multiple Rate Support Auto-switching between various SDI & HDMI rates SDI RAW Blackmagic RAW HDMI Video Standards Same as SDI HDMI Color Precision 10-bit HDR Support HDR10, Hybrid Log Gamma Copy Protection Can't capture from copy-protected sources Media Media Storage 1 x UHS-II SD (for Ultra HD) or regular SD (for HD) USB-C for external drive recording Media Type SDXC UHS-II, SDXC UHS-I and SDHC UHS-I SD cards Supported Codecs Extensive list including Blackmagic RAW, Apple ProRes, DNxHR Control Recorder Control Touchscreen LCD with Blackmagic OS for settings & menus External Control SDI & HDMI start/stop and timecode run Blackmagic RAW Supported cameras listed in table Software Software Included Blackmagic OS Scopes Waveform, RGB Parade, Vector, RGB Histogram Viewing Modes Scopes with picture in picture or overlay, Waveform & Parade with standard/HDR graticules Operating Systems Mac 10.14 Mojave or later, Windows 8.1 & 10 Power Requirements Power Supply External 12V power supply Battery Compatibility Sony NP-F style batteries (not included) Physical Specifications Environmental Specifications Operating Temperature 0° to 40° C (32° to 104° F) Storage Temperature -20° to 45° C (-4° to 113° F) Relative Humidity 0% to 90% non-condensing What's Included Blackmagic Video Assist 5" 12G HDR Universal power supply with locking connector and international adapters Warranty 12 Month Limited Manufacturer's Warranty
