Blackmagic Design Video Assist 7 inch 12G HDR | HYPERD/AVIDA12/7HDR
SKU: HYPERD/AVIDA12/7HDR
£617.08 (Excl. VAT)
- Description
- Specifications
-
Blackmagic Design Video Assist 7 inch 12G HDR | HYPERD/AVIDA12/7HDR
Blackmagic Video Assist 7" 12G HDR adds professional monitoring and recording to any SDI or HDMI camera in all HD, Ultra HD, 2K and 4K DCI formats! The super bright 2500nit 7 inch HDR monitor supports 3D LUTs and features professional scopes along with powerful focus assist and exposure tools that help you accurately set focus, exposure and frame shots. Dual built in SD card recorders save files from any camera in 10‑bit 4:2:2 ProRes or DNx formats. You also get two mini XLR connections with 48V of phantom power and a noise floor of ‑128dBV for high quality, crystal clear audio recording. Plus, you can start editing immediately because you don’t have to convert the files! -
Feature Description Connections SDI Video Inputs 1x 12G-SDI SDI Video Outputs 1x 12G-SDI HDMI Video Inputs 1x HDMI 2.0a HDMI Video Outputs 1x HDMI 2.0a Analog Audio Inputs 2x Balanced Mini XLR with Phantom Power Analog Audio Outputs 1x 3.5mm Headphone Jack Built-in Speaker Mono Screen 7 inch 1920 x 1200, 2500 nits brightness, P3 wide color gamut SDI Audio Inputs 16 channels embedded via 12G-SDI SDI Audio Outputs 16 channels embedded via 12G-SDI HDMI Audio Inputs 8 channels embedded via HDMI 2.0a HDMI Audio Outputs 8 channels embedded via HDMI 2.0a Remote Control 1x 2.5mm LANC for Record Start/Stop SD Interface Dual UHS-II SD slots Storage Type Removable SDXC UHS-II, SDXC UHS-I and SDHC UHS-I SD cards Computer Interface 1x USB Type-C 3.1 Gen 1 for external drive recording, webcam out, software updates & control Standards SDI Video Standards NTSC/PAL, 720p, 1080p, 1080i, 2Kp, Ultra HD, 4K DCI (various frame rates) SDI Compliance Various industry standards Audio Sampling 48 kHz, 24-bit Video Sampling 4:2:2 YUV Color Precision 10-bit Color Space REC 601, REC 709, REC 2020 HDR Support HDR10, Hybrid Log Gamma HDMI Video Standards Same as SDI standards HDMI Color Precision 10-bit Media 2x UHS-II SD slots, USB Type-C for external drive recording Supported Codecs Extensive list including Blackmagic RAW and various Apple ProRes, DNxHR formats Control Recorder Control Touchscreen LCD with on-screen controls External Control LANC, SDI and HDMI start/stop and timecode run Blackmagic RAW Records from various supported cameras (see table) Software Blackmagic OS included Scopes Waveform, RGB Parade, Vector, RGB Histogram Viewing Modes Scopes with picture in picture or overlay, Waveform and Parade with standard and HDR graticules Operating Systems Mac 10.14 Mojave or later, Windows 8.1 and 10 Power Requirements Power Supply External 12V power supply (compatible with Sony NP-F batteries, not included) Physical Specifications Operating Temperature 0° to 40° C (32° to 104° F) Storage Temperature -20° to 45° C (-4° to 113° F) Relative Humidity 0% to 90% non-condensing Warranty 12 Month Limited Manufacturer's Warranty
