Elo 1517L 15" TFT LCD XGA iTouch ZB Black Monitor | E829550
SKU: E829550
£474.45 (Excl. VAT)
- Display Size15"
- Touch CapabilitiesSingle-Touch
- Net Weight4.5 kg
- Operating SystemNone
- VESA Patterns75x75
- Panel TypeTFT Panel
- ResolutionXGA
- Screen TypeFlat
- Response Time23 ms
- Screen Ratio4:3
- Brightness270 cd/m2
- Operating Hours24/7
Book a Free Product Demo
Remote or on-site. No obligation.
Integrator or Installer?
Trade pricing, volume discounts, same-day collection.
Education & Public Sector Solutions
Exclusive pricing, flexible terms, and dedicated support for schools, universities, NHS, and government organisations.
- Description
- Specifications
- Warranty
- Downloads
-
Elo 1517L 15" Touchscreen Monitor | XGA 1024x768 |IntelliTouch | HDMI VGA USB
Overview
The Elo 1517L standard format touchscreen monitor is built to withstand the rigors of continuous public use with a rugged built-for-touch design. Its stylish, thin, and modern look, coupled with a retail-focused feature set is an attractive solution for commercial touchscreen monitor needs. The 1517L is well suited for point-of-sale, point-of-information, point-of-service, interactive signage and loyalty systems. The touch monitor is environmentally friendly, lightweight, and uses less power with state-of-the-art LED backlights in the display panel.
Integrated touch.
The 15-inch touchscreen monitor offers a choice of four touchscreen technologies. AccuTouch® five-wire resistive is widely used in retail and hospitality environments based on its proven ability to survive splashing liquids, food, and grease. Both AccuTouch® five-wire resistive and IntelliTouch® surface acoustic wave (SAW) and IntelliTouch SAW zero-bezel deliver the ultimate in optical quality for dry retail and hospitality applications.
MSR ready.
The 1517L offers an optional three-track magnetic stripe reader (MSR), programmable to either HID or Keyboard Emulation (USB only), is easily installed by the user, providing an elegant, integrated solution and eliminating the need for external brackets or attachments.
Flexible mounting.
The Elo 1517L offers multiple mounting options to ensure installation flexibility including wall- and pole-mount via standard VESA mount patterns as well as tabletop accommodations with the use of the desktop stand. Capped through-mount holes on the base of the touch monitor ensure table-top security.
Other features.
Sleek and thin design with built-for-touch reliability
Flexible and space-saving
60% Energy savings using LED technology
Sealed touchscreen against dirt, dust and liquids
Removable base and mounting options including VESA, wall and pole-mounting
USB and RS232 serial connections
Typical power consumption: 12W, internal and external power options
Three-year standard warrantyConfigurations
-
Specifications Details Part Number(s) - IntelliTouch Black (Worldwide) - E344758 - IntelliTouch ZB Black Antiglare (Worldwide) - E273226 - IntelliTouch ZB Black (Worldwide) - E829550 - AccuTouch Black (Worldwide) - E523163 - AccuTouch ZB Black (Worldwide) - E144246 Enclosure Color Black Touch Technology & Capacity - 5-Wire Resistive (AccuTouch®) - Single-Touch - SAW (IntelliTouch® Surface Acoustic Wave) - Single Touch - SAW ZB (IntelliTouch® Surface Acoustic Wave) - Single Touch Diagonal Size 15'' diagonal, Active matrix TFT LCD (LED) Aspect Ratio 4:3 Active Area 11.97" x 8.98" / 304.13 mm x 228.10 mm Resolution 1024 x 768 @ 60Hz, 75Hz Other Supported Resolutions - 640 x 480 @ 60Hz, 75Hz - 720 x 400 @ 70Hz - 800 x 600 @ 56Hz, 60Hz, 75Hz - 1024 x 768 @ 60Hz, 75Hz Viewing Angle Horizontal: ± 80° or 160° total / Vertical: 70°/80° or 150° total Number of Colors 16.2 million Brightness (typical) - LCD panel: 300 nits - AccuTouch: 240 nits - IntelliTouch: 270 nits Response Time-total (typical) 23 msec Contrast Ratio 800:1 Touch Interface Serial (RS232) and USB On Screen Display Accessible through switches along the bottom: - Controls: Menu, Up, Down, Select, Power - Settings: Contrast, Brightness, H-Position, V-Position, Auto-Adjust, Sharpness, Color, Temperature, Clock, Phase, OSD timeout, OSD Language, Recall, Defaults, Information - Languages: English, French, Italian, German, Spanish, Japanese, Traditional Chinese, Simplified Chinese - Lockouts: OSD, Power I/O Ports - VGA - HDMI - DC jack - AC jack - USB Type B - RS-232 (DB-9) Video - Analog VGA on Female DB-15 connector - Digital HDMI on Type A receptacle Input Video Horizontal Sync frequency range 31.5 – 60KHz Input Video Vertical Sync (frame rate) frequency range 56-75Hz Power Monitor AC input power connector: IEC 60320 C6 Monitor AC input voltage specifications: 100-240VAC, 50/60Hz. Monitor DC input power connector: Coaxial power jack (2.0mm pin outer diameter, 6.4mm barrel inner diameter) Monitor DC input voltage specifications: 12VDC +/- 5% Power Consumption (Typical) - Monitor Only - ON: 10.5W - SLEEP: 1.4W - OFF: 0.3W Monitor Dimensions (with Stand) 14.1" x 7.8" x 12.5" / 358 mm x 197 mm x 319 mm Shipping Box Dimensions 19.2" x 9.1" x 19.1" / 487 mm x 231 mm x 485 mm Weight (Unpackaged) 9.48 lbs / 4.3 kg Weight (Packaged) 16.09 lbs / 7.3 kg Operating Temperature 0°C to 40°C / 32°F to 104°F Storage Temperature 20°C to 60°C / -4°F to 140°F Humidity Operating: 20% to 80% Storage: 10% to 95% (38.7°C max wet bulb temperature) MTBF 50,000 hours demonstrated Mounting Options VESA 4-hole 75mm mounting interface on rear of unit 3-hole threaded mounting on bottom of stand Warranty 3-year Extended Service Options - 4 year warranty coverage - Elo P/N: E898247 - 5 year warranty coverage - Elo P/N: E898449 - 3 year warranty coverage + AUR - Elo P/N: E898648 - 4 year warranty coverage + AUR - Elo P/N: E894921 - 5 year warranty coverage + AUR - Elo P/N: E895125 Regulatory approvals and declarations - Argentina S-mark - Australia RCM - Canada cUL, IC - China CCC - Europe CE - United Kingdom UKCA - Japan VCCI - Korea KCC, e-Standby - Mexico NOM - Taiwan BSMI Mark - United States UL, FCC - International CB - RoHS, China RoHS, WEEE What's in the Box - Touch monitor - Quick Install Guide - VGA Cable (DB-15 male to DB-15 male) - Touch USB Cable (USB Type A plug to USB Type B plug) - Power cable, IEC 60320-C5 to NA/EU plug - Stand Base assembly - Filler Plate - HDMI cable Optional Peripherals - Magnetic Stripe Reader (Black MSR) – Elo P/N: E500356 - North America power adapter and cable kit - Elo P/N: E005277 - European & Korea power adapter and cable kit - Elo P/N: E571601 - UK power adapter and cable kit - Elo P/N: E180092 - China power adapter and cable kit - Elo P/N: E558862 - Taiwan power adapter and cable kit - Elo P/N: E818655 - Japan power adapter and cable kit - Elo P/N: E182546 - Argentina power adapter and cable kit - Elo P/N: E887099 - Australia power adapter and cable kit - Elo P/N: E637593 Stands, Mounts & Kits - 1517L VESA Mount Plate (White) - Elo P/N: E000420 - 1517L VESA Mount Plate (Black) - Elo P/N: E000404 - 1517L Replacement Stand (White) - Elo P/N: E483197 - 1517L Replacement Stand (Black) - Elo P/N: E264383 - China AC power cable – Elo P/N: E501749 - UK AC power cable – Elo P/N: E102073 -
Touchscreen Monitors LCD Monitors 3 years
-
Item Download
Dimensional Drawing Download CAD Drawings Download Agency Approval Certificates Download EU Regulation 2019/2013 Download Energy Efficiency Fiche Download Spec Sheet Download
