Screen Size (Inches) |
55" (54.6") |
VESA Hole Pitch (W x H) |
30.0 x 30.0 cm |
Weight of Package Carton (Gross) |
Approx. 24 kg |
Dimension of Package Carton (W x H x D) |
Approx. 134.8 x 84.2 x 16.0 cm; Approx. 136.2 x 84.7 x 16.0 cm (ISTA) |
Stand Width (Narrow Position) |
Approx. 40.4 cm |
Stand Width (Soundbar Position) |
Approx. 106.7 cm |
Stand Width (Standard Position) |
Approx. 106.7 cm |
Dimension of TV with Stand (Narrow Position) (W x H x D) |
Approx. 122.5 x 73.8 x 34.5 cm |
Dimension of TV with Stand (Standard Position) (W x H x D) |
Approx. 122.5 x 73.8 x 34.5 cm |
Dimension of TV with Stand (Soundbar Position) (W x H x D) |
Approx. 122.5 x 77.8 x 34.5 cm |
Weight of TV with Stand |
Approx. 17.7 kg |
Weight of TV without Stand |
Approx. 16.9 kg |
Dimension of TV without Stand (W x H x D) |
Approx. 122.5 x 70.7 x 5.6 cm |
Screen Size (cm) |
139 cm |
Auto Low Latency Mode (ALLM) |
Yes (for HDMI™3/4) |
HDCP |
HDCP2.3 (for HDMI™1/2/3/4) |
IF (Satellite) Inputs |
2 (Side) |
RS-232C Inputs |
No |
HDMI Audio Return Channel (ARC) |
Yes (eARC/ARC) |
USB Playback Codecs |
Various including MPEG, AVC, HEVC, AAC, FLAC, etc. |
USB Drive Format Support |
FAT16/FAT32/exFAT/NTFS |
Wi-Fi Standard |
Wi-Fi Certified 802.11a/b/g/n/ac |
Features Specified in HDMI 2.1 |
4K120/eARC/VRR/ALLM |
Apple HomeKit |
Yes |
Chromecast Built-In |
Yes |
Apple AirPlay |
Yes |
Headphone Outputs |
- |
Subwoofer Output(s) |
- |
Composite Video Inputs |
Hybrid with S-Center Speaker Input x1 (Side, Mini jack) |
Component Video (Y/Pb/Pr) Inputs |
No |
Digital Audio Output(s) |
1 (Side) |
HDMI Inputs Total |
4 (4 Side) |
Ethernet Inputs |
1 (Side) |
RF (Terrestrial/Cable) Connection Input(s) |
1 (Side) |
Bluetooth Profile Support |
Version 4.2, HID, HOGP, SPP, A2DP, AVRCP |
USB Ports |
2 (Side) |
USB HDD Recording |
Yes (1 Rec) |
BRAVIA Sync (Including HDMI-CEC) |
Yes |
Variable Refresh Rate (VRR) |
Yes (for HDMI™3/4) |
Wi-Fi Frequency |
2.4GHz/5GHz (Wi-Fi Direct: 2.4GHz Only) |
Backlight Dimming Type |
Local Dimming |
Display Resolution (H x V, Pixels) |
3840 x 2160 |
Display Type |
LCD |
Backlight Type |
Direct (Full Array LED) |
Panel Refresh Rate |
100/120Hz |
Sensor |
Light |
Colour Enhancement |
XR TRILUMINOS PRO™ |
Contrast Enhancement |
XR Contrast Booster 10 |
Clarity Enhancement |
XR 4K Upscaling |
Picture Processor |
Cognitive Processor XR |
Video Signal Support |
Various up to 4096x2160p at various Hz |
HDR Compatibility |
Yes (HDR10, HLG, Dolby Vision) |
Motion Enhancer (Native Hz) |
XR Motion Clarity, Auto mode |
Picture Modes |
Vivid, Standard, Cinema, IMAX Enhanced, Game, etc. |
Netflix Calibrated Mode |
Yes |
BRAVIA CORE Calibrated Mode |
Yes |
XR Clear Image |
Yes |
Audio Power Output |
10W + 10W + 5W + 5W |
Speaker Configuration |
Full Range x2, Tweeter x2 |
Speaker Type |
Acoustic Multi-Audio |
Sound Modes |
Standard, Dialog, Cinema, Music, Sports, Dolby Audio |
DTS Audio Format Support |
DTS Digital Surround |
Dolby Audio Format Support |
Dolby™ Audio, Dolby™ Atmos |
Acoustic Auto Calibration |
Room & User Position Compensation |
FM Radio |
No |
Sound Processing |
No |
Simulated Surround Sound |
3D Surround Upscaling |
Voice Zoom |
Voice Zoom 2 |
Ready for 360 Spatial Sound Personalizer |
Yes (with WLA-NS7) |
Acoustic Center Sync |
Yes (Sony compatible Soundbar) |
Camera |
BRAVIA CAM (Optional) |
Camera Function |
Yes (Camera apps) |
Auto Calibration with CalMAN® |
Yes |
Internet Browser |
Yes |
Electronic Program Guide (EPG) |
Yes |
Built-In Mic Switch |
Yes (Center) |
Application Store |
Yes (Google Play Store) |
On/Off Timer |
Yes |
Closed Captions (Analog/Digital) |
(Analog) No |
Display Language |
Multiple |
On-Board Storage (GB) |
32 GB |
Operating System |
Android TV™ |
Sleep Timer |
Yes |
Text Input Language |
Multiple |
Teletext |
Yes |
Voice Search |
Yes (Voice Search), Yes (Built-in Mic) |
SMART TV |
Google TV™ |
Eco Dashboard |
Yes |
Control Menu |
Yes |
Auto HDR Tone Mapping |
Yes |
Auto Genre Picture Mode |
Yes |
Annual Energy Consumption |
82 kWh/1000h |
Mercury Content (Mg) |
0.0 mg |
Power Saving Mode / Back Light Off Mode |
Yes |
Power Consumption (In Standby) |
0.50 W |
Power Consumption (Networked Standby Mode) |
2.00W (Wi-Fi), 2.00W (LAN), 0.50W (CEC) |
Stand Design |
Aluminum Slim Wedged Stand |
Bezel Color |
Dark Silver |
Bezel Design |
Seamless edge |
Stand Position |
3-way position (Standard, Narrow, Soundbar) |
Stand Color |
Dark Silver |
Remote Control |
IR Remote; Standard Remote |
Number of Tuners (Sat) |
2 |
Tuner Channel Coverage (Digital Cable) |
VHF/UHF/cable (depends on country) |
Number of Tuners (Terrestrial/Cable) |
2 (Digital)/1 (Analog) |
Tuner Channel Coverage (Digital Terrestrial) |
VHF/UHF (depends on country) |
Tuner Channel Coverage (Digital Sat) |
Intermediate Frequency 950-2150MHz |
Tuner Channel Coverage (Analog) |
45.25MHz-863.25MHz (depends on country) |
TV System (Analog) |
B/G, D/K |
TV System (Digital Sat) |
DVB-S/S2 |
CI+ |
Yes |
TV System (Digital Terrestrial) |
DVB-T/T2 |
TV System (Digital Cable) |
DVB-C |
Closed Caption |
Subtitle |
Screen Reader |
Yes |
Voice Search |
Yes (Voice Search), Yes (Built-in Mic) |
Accessibility Shortcut |
Yes |
Text Magnification |
Yes |
Audio Description (Audio Key) |
Yes |
Optional Accessories |
Camera Unit (CMU-BC1); Wallmount Bracket (SU-WL450/SU-WL850) |
