Synology DiskStation DS1823XS+ Ryzen Embedded V1780B 8 GB DDR4 NAS/Storage Server
SKU: DS1823XS+
£1,486.43 (Excl. VAT)
- Description
- Specifications
- Downloads
-
Synology DiskStation DS1823xs+ | 8-Bay NAS Server, AMD Ryzen V1780B 3.35GHz, 8GB DDR4 ECC, 144TB Scalable Storage
The DS1823xs+ is a powerful central storage server that can easily be deployed anywhere to provide secure data storage and sharing, endpoint and server backup, VM storage, surveillance management, and other business applications. It is perfect in environments where no dedicated server rack or data center is available.
Built-in data integrity protection, remote management options, and easy hardware expansion make the DS1823xs+ dependable, easy to maintain, and cost efficient.
Desktop-sized powerhouse
Over 3,100/2,600 MB/s seq. read/write, 1 built-in 10GbE, and up to 144 TB raw storage before expansion.Flexible configuration
Add up to 10 extra drive bays, 25GbE or Fiber Channel, and SSD cache volumes when needed.Versatile applications
Back up 300 endpoints, manage 75 IP cameras, 4 or safely sync and share files between devices and sites.Data integrity protection
The Btrfs file system helps prevent data corruption and loss through metadata mirroring, file self-healing, and efficient point-in-time snapshots. ECC memory provides additional integrity safeguards.Efficient remote management
Monitor, manage, and replace drives and storage online in Synology DiskStation Manager (DSM). Remotely reboot, reset, or view logs while the system is down thanks to out-of-band management (OOB).Plug-and-Play expansion
The DS1823xs+ can be scaled to up to 18 bays by adding two DX517 expansion units without system downtime, thanks to online storage and volume expansion.The performance you need
Configure the DS1823xs+ to handle any workload. Easily add 1/10/25GbE or Fibre Channel ports and designate NVMe or SATA SSD volumes as read/write cache to boost HDD performance.Simply faster
Experience faster file indexing and higher sequential throughput with Synology Drive.Store, share, and protect
Manage all your documents, photos, and other files, back up applications and devices, and protect your physical assets with professional video surveillance.Backup repository
Back up files, folders, physical devices, VMs, and SaaS applications with free solutions, and protect your NAS with built-in technologies.Business application platform
Host cost-efficient business solutions, either through containers, virtual machines, or Synology DSM's own solutions, including a powerful free backup suite, a versatile mail server, and a surveillance VMS with transparent licensing.Get more with DiskStation manager
Take advantage of a host of native productivity, management, and security solutions available in the web-based Synology DSM operating system. -
Feature Description CPU Model AMD Ryzen V1780B CPU Quantity 1 CPU Cores 4 CPU Architecture 64-bit CPU Frequency 3.35 GHz (base) / 3.6 GHz (turbo) System Memory 8 GB DDR4 ECC SODIMM Pre-installed Memory 8 GB (8 GB × 1) Total Memory Slots 2 Maximum Memory Capacity 32 GB (16 GB × 2) Memory Notes Synology may replace modules with same/higher frequency due to lifecycle; performance is verified.
Use Synology memory for optimum compatibility; non-Synology modules may void full warranty/support.
For multi-module configs, all modules must be identical (same model number).Drive Bays 8 Max Drive Bays (with Expansion) 18 (DX517 × 2) M.2 Drive Slots 2 × NVMe (M.2 2280) Supported Drive Types 3.5" SATA HDD; 2.5" SATA SSD; M.2 2280 NVMe SSD Hot-Swappable Drives Supported (not for M.2 SSD slots) Storage Notes Full functionality and reliability guaranteed for drives on Synology compatibility list. Non-validated components may limit functionality or cause data loss/system instability. 1GbE LAN (RJ-45) 2 ports 10GbE LAN (RJ-45) 1 port Out-of-Band Mgmt LAN 1 port USB 3.2 Gen 1 3 ports Expansion Ports 2 × eSATA LAN MTU Note 1GbE ports max MTU: 1,500 bytes PCIe Expansion 1 × Gen3 x8 slot (x4 link) Size (H × W × D) 166 mm × 343 mm × 243 mm Weight 6.2 kg System Fans 2 × 120 mm Fan Speed Modes Full-Speed, Cool, Quiet Easy Fan Replacement Yes Adjustable Front LEDs Yes (brightness adjustable) Power Recovery Supported Noise Level 23.6 dB(A) Scheduled Power On/Off Supported Wake on LAN/WAN Supported Power Supply 250 W PSU AC Input 100–240 V AC, 50/60 Hz, Single Phase Power (Access / Hibernation) 87.93 W / 28.37 W Thermal Output (Access / Hibernation) 300.23 / 96.87 BTU/hr Power/Noise Notes Power measurement per Synology methodology. Noise tested with Synology SATA HDDs (idle), dual microphones at 1 m; background 16.49–17.51 dB(A); temp 24.25–25.75 °C; humidity 58.2–61.8%. Operating Temperature 0 °C to 40 °C (32 °F to 104 °F) Storage Temperature −20 °C to 60 °C (−5 °F to 140 °F) Operating Humidity 8% to 80% RH Storage Humidity 5% to 95% RH Certifications FCC, CE, BSMI, VCCI, RCM, EAC, CCC, KC, BIS Warranty 5 Years (from purchase date) Environmental RoHS Compliant Package Contents Main Unit ×1; Accessory Pack ×1; AC Power Cord ×1; RJ-45 LAN Cable ×2; Quick Installation Guide ×1 Optional Accessories DDR4 ECC SODIMM (D4ES02-8G / D4ES01-16G); Expansion Unit DX517; HAT5300 (Enterprise HDD); HAT3300 (Plus HDD); SAT5200 (Enterprise SSD); SNV3400 & SNV5400 (M.2 NVMe); 25GbE NIC E25G30-F2; 10GbE NICs E10G30-F2 / E10G30-T2 / E10G18-T1 Max Single Volume Size Up to 200 TB (requires 32 GB memory); otherwise 108 TB Max Internal Volume Count 256 M.2 SSD Storage Pools Supported (Synology-verified SSDs required) SSD Cache / TRIM Read/Write cache; SSD TRIM supported Supported RAID Types RAID F1, Basic, JBOD, RAID 0/1/5/6/10 RAID Migration Basic ➜ RAID 1/5; RAID 1 ➜ RAID 5; RAID 5 ➜ RAID 6 Volume Expansion (Larger HDDs) RAID F1, RAID 1/5/6/10 Volume Expansion (Add HDD) RAID F1, JBOD, RAID 5/6 Global Hot Spare (RAID) RAID F1, RAID 1/5/6/10 Storage Notes Volumes >108 TB require ≥32 GB RAM. Usable capacity depends on filesystem/metadata. Creating M.2 storage pools requires Synology-verified SSDs tuned for thermal management. Internal Filesystems Btrfs, ext4 External Filesystems Btrfs, ext4, ext3, FAT32, NTFS, HFS+, exFAT File Protocols SMB, AFP, NFS, FTP, WebDAV, Rsync Max SMB Connections 340 (FSCT-based) Windows ACL Integration Supported NFS Kerberos Authentication Supported Max Local User Accounts 2,048 Max Local Groups 512 Max Shared Folders 512 Max Shared Folder Sync Tasks 12 Max Hybrid Share Folders 15 Hyper Backup Folder/Package & Entire System Backup (DSM 7.2+) High Availability Synology High Availability supported Syslog Events per Second 3,000 Virtualization Platforms VMware vSphere (ESXi 6.5–8.0), Microsoft Hyper-V (Windows Server 2022), Citrix XenServer 8 / Citrix Hypervisor 8.2 LTSR CU1, OpenStack Cinder Supported Protocols SMB1/2/3, NFSv3/v4/v4.1, NFS Kerberized, iSCSI, Fibre Channel, HTTP/HTTPS, FTP, SNMP, LDAP, CalDAV Supported Browsers Chrome, Firefox, Edge, Safari Supported Languages English, Deutsch, Français, Italiano, Español, Dansk, Norsk, Svenska, Nederlands, Русский, Polski, Magyar, Português (BR/EU), Türkçe, Český, ภาษาไทย, 日本語, 한국어, 繁體中文, 简体中文 Central Management System Supported Synology AI Console Third-party AI model integration supported Max De-Identification Rate 340 words/second (requires ≥8 GB memory & Container Manager) Synology Chat – Max Users 400 Download Station – Max Tasks 80 concurrent SAN Manager – Max iSCSI Targets 64 SAN Manager – Max LUNs 128 (LUN clone/snapshot, Windows ODX supported) MailPlus – Free Accounts 5 (more via licenses) MailPlus – Max Users 710 (performance depends on configuration/workload) DLNA Compliance Supported Synology Photos Facial & Object Recognition Max Snapshots per Shared Folder 256 Max System Snapshots 4,096 Surveillance Station Licenses 2 included (add-on required for more) Max IP Cameras / FPS (H.264) 1080p: 75 ch / 2100 FPS; 3M: 75 / 1500; 5M: 75 / 900; 4K: 55 / 550 Max IP Cameras / FPS (H.265) 1080p: 75 ch / 2250 FPS; 3M: 75 / 2250; 5M: 75 / 1500; 4K: 75 / 900 Synology Drive – Max Users 610 Synology Drive – Max Hosted Files 5,000,000 Synology Office – Max Users 590 VMM – Recommended VMs 8 instances VMM – Recommended Virtual DSM 8 (incl. 1 free license) VPN Server – Max Connections 12 -
Description Downloads Synology DiskStation DS1823XS+ Ryzen Embedded V1780B 8 GB DDR4 NAS/Storage Server DataSheet Download
