Elo EloPOS 15" FHD Core i5-9500TE 8GB RAM 128GB SSD Touchscreen POS System | E441193
SKU: E441193
£1,118.70 (Excl. VAT)
- Display Size15.6"
- Touch Capabilities10pt multi-touch
- Net Weight5 kg
- Operating SystemWindows 10
- VESA Patterns75x75
- Panel TypeTFT Panel
- ResolutionFull HD (1080p)
- Screen TypeFlat
- Response Time10ms
- Screen Ratio16:9
- Brightness300 cd/m2
- Operating Hours24/7
Book a Free Product Demo
Remote or on-site. No obligation.
Integrator or Installer?
Trade pricing, volume discounts, same-day collection.
Education & Public Sector Solutions
Exclusive pricing, flexible terms, and dedicated support for schools, universities, NHS, and government organisations.
- Description
- Specifications
- Warranty
- Downloads
-
Elo E441193 EloPOS 15" Touchscreen POS System | Intel Core i5-9500TE, 8GB RAM, 128GB SSD, Win10 IoT, FHD

EloPOS™ System
Modern. Modular. Made for Retail.
The versatile EloPOS System combines modern aesthetics, modular flexibility and commercial-grade reliability. Purpose-built for point of sale, EloPOS offers a 15.6-inch touchscreen display, choice of Intel's 8th generation processors and an integrated expansion hub to connect the peripherals you need - whether a customer facing display, payment reader, printer, cash drawer, barcode scanner or scale. From traditional POS to self-service applications, EloPOS delivers the durability needed to survive continuous public use and is backed by Elo's standard 3-year warranty.Interactive Points of Sale
The EloPOS System is designed to offer flexibility across environments. Whether you need a fixed-lane point of sale system or a self-order solution, EloPOS can help ensure that every touch delivers the experience your employees need and your customers expect.Connections. Connections. Connections.
The expansion hub allows you to connect all of the POS peripheral support you need. From cash drawers and printers to barcode scanners and payment devices - there is connectivity to cover it all. With two models, the hub is integrated into the base of the EloPOS stand or mounted to the back of the display for pole and wall mount configurations.Configure Your Solution
EloPOS is designed with the flexibility to be mounted however you desire. With a standard VESA mounting system,and optional pole and self-service stands, EloPOS offers the modularity you need to create the solution you want. From POS terminals to self-service checkout, the EloPOS can be configured to deliver maximum impact.Add a Customer-Facing Display with Ease
The EloPOS System includes USB-C connectivity, allowing you to easily connect a customer-facing - providing touch, data and power with just one cable. By reducing the number of cables required for setup from 3 to 1, installation and servicing is a breeze.Elo Edge Connect™ Lets You do More!
Built with versatility in mind, Elo Edge Connect offers a wide assortment of peripheral options. Whether for point of sale, endless aisle or self-order applications, you can seamlessly attach any combination of up to four peripherals to the edge of the touchscreen creating a bespoke solution. And, you can add or move them later as your needs change!Windows or Linux. You Choose.
EloPOS utilizes the reliability-tested performance and security of Intel 8th Generation processors, integrated Trusted Platform Modules, Intel vPro™ and the Windows 10 operating system. For added flexibility, the EloPOS offers models with no OS - all pretested with Linux SuSE, Ubuntu and Red Hat operating systems, allowing businesses to get the solution best-suited for them.Retail-Hardened
Rigorously tested and backed by a three-year warranty, the EloPOS System delivers superior quality and reliability. The splash-proof housing and rugged retail-hardened design can easily withstand the adverse conditions associated with most commercial environments. Additional one and two-year warranty extensions are available as well as EloCare Advance Exchange options - making EloPOS the ideal product for point of sale applications.Get Peace of Mind With EloCare
Your point of sale system is central to your operation, and no one wants to experience difficulty during the checkout process. With EloCare Advance Exchange, in the event you have an issue, all you have to do is call Elo. We will have you up and running as soon as possible by shipping you a replacement unit. -
Feature Description Part Number (SKU) E441193 Model HD Model – i3, Win 10, 4GB RAM, 128GB SSD with I/O Hub Stand Enclosure Color Black Touch Technology & Capacity PCAP (TouchPro® Projected Capacitive) – 10 Touch Processor Intel® Core™ i3-9100TE (6MB Smart Cache, up to 3.20 GHz Turbo) Chipset Intel H310 Express (i3 Models) Graphics Intel UHD Graphics 630 (i3 & i5 Models) BIOS AMI Memory (RAM) 4GB 2666MHz DDR4 SO-DIMM on 1 of 2 slots (expandable to 32GB) Storage 128GB M.2 SATA SSD (80 TBW) TPM 2.0 Intel AMT N/A for i3 Models Diagonal Size 15.6'' diagonal, Active matrix TFT LCD (LED) Aspect Ratio 16:9 Active Area 13.55" × 7.62" / 344.2 mm × 193.5 mm Resolution 1366 × 768 @ 60Hz (HD Model) Number of Colors 262,000 Brightness (typical) LCD: 220 nits / PCAP: 187 nits (HD Models) Response Time (typical) 10 ms (HD Models) Contrast Ratio 400:1 (HD Models) Viewing Angle Horizontal: 45°/45° (90° total) / Vertical: 15°/35° (50° total) Wireless Wi-Fi 802.11 a/b/g/n/ac (2.4 GHz & 5 GHz) Bluetooth Bluetooth 5.0 USB Ports 3 × USB 3.0 (1 on display head, 2 on I/O), 2 × USB 2.0 (on I/O), 4 × Micro USB 2.0 (display head) Powered USB 1 × 24V (on I/O), 2 × 12V (on I/O) Ethernet Port 1 × RJ45 (Gigabit) Serial Ports 2 × RJ45 Cash Drawer Port 12V/24V (EPSON Pinout, 24V default; internal switch selectable) Additional Video Out 1 × Full-function USB-C (Power up to 27W, USB 3.0, DisplayPort) Audio Ports 1 × 3.5 mm headset jack Speakers 2 × 2W internal speakers Operating System Windows 10 IoT Enterprise LTSC 64-bit Power Supply External 24VDC universal power supply brick; AC 100–240V, 50–60 Hz; 180W max output Power Consumption (Typical) 65W (HD i3 Model) Dimensions (with Stand) 15.2" × 14.54" × 8.71" / 386.2 mm × 369.3 mm × 221.2 mm Weight (Unpackaged) 10.8 lbs / 4.9 kg Shipping Box (with Stand) 18.19" × 11.77" × 18.5" / 462 mm × 299 mm × 470 mm Weight (Packaged) 16.1 lbs / 7.3 kg Operating Temperature 0°C to 35°C / 32°F to 95°F Storage Temperature −20°C to 60°C / −4°F to 140°F Humidity Operating: 20%–80% / Storage: 5%–95% (38.7°C max wet bulb) Energy Star Energy Star 7.1 Regulatory Approvals UL (US), FCC (US); cUL (Canada); TUV (Germany); CE (Europe); CB (International); UKCA (UK); NOM (Mexico); RCM (Australia); R-NZ (New Zealand); VCCI (Japan); S-Mark (Argentina); CCC (China); KCC (Korea, i3/i5 FHD & i5 HD); BSMI (Taiwan, i3/i5 FHD); IMDA (Singapore, i3 FHD & i5 HD); SIRIM (Malaysia, i3 FHD & i5 HD); NBTC (Thailand, i3 FHD & i5 HD) Real-Time Clock CR2032 lithium metal battery MTBF 50,000 hours demonstrated Mounting Options 75mm VESA mount Sealability Touchscreen sealed to sub-bezel; touchscreen sealed to LCD Other Features Serviceable internal components; With stand (desktop); Without stand option for 75mm VESA; Kensington lock Warranty 3-year Power Cables North American and European power cables included What's in the Box EloPOS System
North America Power Cord
EU Power Cord
Power Adapter – 180W
Cable RJ-45 to DB-9
Cable cover locking screw
Quick Installation Guide (QIG)Upgrade Options 4GB 2666 MHz DDR4 SO-DIMM – Elo P/N: E264186
8GB 2666 MHz DDR4 SO-DIMM – Elo P/N: E264375
16GB 2666 MHz DDR4 SO-DIMM – Elo P/N: E263989
M.2 SATA 128GB SSD – Elo P/N: E206352
M.2 SATA 256GB SSD – Elo P/N: E206556
Note: Celeron SKUs only support 4GB DDR4 per slotOptional Peripherals Magnetic Stripe Reader (MSR) – E001002
Fingerprint Scanner – E134286
10" CFD (10 touch) – E155834 (requires display mount E835969 & 2ft USB-C cable E969524)
10" CFD (no touch) – E324341 (requires display mount E835969 & 2ft USB-C cable E969524)
1302L CFD (10 touch) – E683595 (requires display mount E835969 & 2ft USB-C cable E969524)
2D Barcode Scanner (SE4720) – E384627
EMV Cradle for MagTek eDynamo – E375343
EMV Cradle for Ingenico RP457c (Audio Jack/BT/USB) – E586981
EMV Cradle for Ingenico RP457c (BT/USB) – E710930
Status Light (Micro-USB) – E644767
6ft Authorized USB-C Cable – E710364
RFID – E673037
Elo Edge Connect™ Speaker Bar (Black) – E894719 / (White) – E133780Stands, Mounts & Kits Shelf Mount Bracket (75/100mm VESA) – E043382
Floor Stand (75/100mm VESA) – E048069
Pole Mount – 6" / 12" / 18" (75/100mm VESA) – E047458 / E047663 / E047864
Pole Mount Bracket (75/100mm VESA) – E045151
Rear-facing Display Mount – E835969 (Requires authorized 2ft USB-C cable)
Power Brick Kit, 24V 180W – E845269
Elo 2ft Authorized USB-C Cable – E969524
RJ45 to DB9 Cable Kit – E641484
-
Touchscreen Monitors LCD Monitors 3 years
-
Resource Name Download EloCare℠ Download Download Drivers Download Spec Sheet Download Dimensional Drawing Download CAD Drawings Download Agency Approval Certificates Download Material Safety Data Sheet (MSDS) Download
