Aurora Multimedia ASP-42 4K60 4x2 HDMI 2.0 Matrix with USB 3.1 Capture
The ASP-42 is a 4K60 4x2 HDMI 2.0 matrix with USB 3.1 capture. The USB mirrors the second output so a PC can be connected for any of the 4 inputs to be available to the PC. To further round out the product, the ASP-42 has RS-232, IR, and CEC control. Audio is important so in addition to the analog audio output, the unit has a Dante option capable of 2 or 8 channel.
The LAN port allows for IP control and serves up internal control pages. The inputs can be set for auto sense or selection can be controlled through the LAN or front buttons. Perfect for Zoom™, WebEx™, and Teams™ rooms, the ASP-42 is the ultimate all in one cost effective solution.
Features
4K60 4:4:4 18Gbps Uncompressed
HDR (high Dynamic Range)
Four HDMI® 2.0/HDCP 2.2
Auto Switching
Four HDMI® Inputs
Two HDMI® Output
1G PoE LAN Port Connection
USB 3.1 Capture Output for Computer
IP Port Expansion, RS-232 & IR Control
Warrenty: 60 Months -
Feature Description HDMI Inputs 4 (HDMI 2.0b, HDCP 2.2) HDMI Outputs 2 (HDMI 2.0b, HDCP 2.2) Audio Analog Stereo Line In/Out LAN RJ-45 10/100/1000M PoE Video Bandwidth 600MHz Video Resolution Up to 4K2K 4:4:4 @ 60Hz RS-232 Up to 115k Baud IR Bi-Directional USB Connector USB 3.1 Type B Expansion Port Dante® 2Ch/8Ch and ReAX™ Interface IR, Front Buttons, Web Server Housing Black Aluminum Enclosure Dimensions (L×W×H) 177.04 × 104.14 × 26.42mm (6.97” × 4.10” × 1.04”) Weight 0.453kg [1lbs] Mounting Rack Mount Vertical/Horizontal, Under Table Mount Power Supply 48V DC (2 Pin Euro) or PoE Power Consumption 4 Watts Operation Temp. 0~40°C [32~104°F] Storage Temp. -20~60°C [-4~140°F] Relative Humidity 20~90% RH (No Condensation) Package Contents 1x ASP-42, 2x Mounting Ears -
Description Downloads Aurora Multimedia ASP-42 4K60 4x2 HDMI 2.0 Matrix with USB 3.1 Capture DataSheet Downloads Aurora Multimedia ASP-42 4K60 4x2 HDMI 2.0 Matrix with USB 3.1 Capture User Guide Downloads
