ELO 2202L 22" 60Hz 14ms Full HD Touchscreen Monitor | E351600
SKU: E351600
£387.36 (Excl. VAT)
- Display Size22"
- Touch Capabilities10pt multi-touch
- Net Weight6.75kg
- Operating SystemNone
- VESA Patterns100x100
- Panel TypeN/A
- Description
- Specifications
- Downloads
-
22" Full HD Touchscreen Monitor with PCAP Technology (E351600)
2202L Touchscreen Monitor
The Elo 02-Series of Touchscreen Monitors designed with seamless style across all sizes includes four options — a 19-inch square aspect ratio display and 22, 24 and 27-inch wide aspect ratio displays. With a compact form factor and clean design for easy integration, the 02-Series monitors are well-suited for point-of-sale, point of information, signage and hospitality applications. And with a variety of peripherals, the monitors can be transformed to meet the demands of your blueprint.
Brilliant Displays from 19 to 27-inches
The brilliant touchscreens with Elo's industry-leading TouchPro™ PCAP technology offer wide viewing angles with impeccable image clarity, resolution, and light transmission for accurate touch response and vivid images. With up to 10 touches enabled, the 02-Series Monitors, provide a tablet-like experience.Well-Suited for...
Not all businesses have the same needs. Whether you need a touchscreen at the point of sale to process a transaction or in a restaurant to enable self-service for guests to view your menu and submit their order, the line of 02-Series monitors can support the installation needs with ease while maintaining a modern, sleek aesthetic.
Elo Edge Connect™ Lets You do More!
Built with versatility in mind, the Elo Edge Connect system offers a wide assortment of peripheral options. Whether for endless aisle, self-order or collaboration applications, you can seamlessly attach any combination of up to four peripherals to the edge of the touchscreen creating a bespoke solution. And, you can add or move them later as your needs change!
Fingerprint Scanner
The Biometric Fingerprint Scanner can be attached to provide secure and quick login.
MSR
Elo offers the flexibility of integrating payment devices, including a Magtek 3-track encryptable MSR payment terminal.
Barcode Scanner
Enhance self-service checkout and price-checker applications by coupling a high-performance barcode scanner onto the Elo touchscreen.
NFC
The Near Field Communication (NFC) adapter can be integrated for easy mobile payments with just a touch of the phone.
One for You.
One for Your Customers.
Offer your customers a point of interaction by adding a touchscreen for them to review their transactions, participate in loyalty programs or see the latest promotion.
Mount with Flexibility
Customers demand a seamless shopping experience from first step into the store through check-out. From the stands that come with the monitors to pole mounts, shelf mounts, wall mounts and 3rd party VESA mounts, the touchscreens can be integrated with ease.Connections
-
Part Number(s) Clear with Stand - E351600
Clear without Stand - E126096
Anti-glare with Stand - E159758
Anti-glare without Stand - E992622Enclosure Color Black Touch Technology & Capacity PCAP (TouchPro® Projected Capacitive) - 10 Touch Diagonal Size 21.5'' diagonal, Active matrix TFT LCD (LED) Aspect Ratio 16:9 Active Area 18.74" x 10.54" / 476.06 mm x 267.79 mm Resolution 1920 x 1080 @ 50, 60Hz Other Supported Resolutions 640 x 480 60Hz
640 x 400 70Hz
720 x 400 70Hz
800 x 500 60Hz
800 x 600 56Hz, 60Hz
1024 x 768 60Hz
1280 x 720 @ 58Hz, 60Hz
1280 x 800 60Hz
1280 x 1024 60Hz
1366 x 768 60Hz, 60Hz RB
1440 x 900 60Hz, 60Hz RB
1680 x 1050 60Hz, 60Hz RBViewing Angle Horizontal: ±89° or 178° total / Vertical: ±89° or 178° total Number of Colors 16.7 million Brightness (typical) LCD Panel: 250 nits
TouchPro PCAP: 225 nitsResponse Time-total (typical) 14 msec Contrast Ratio 1000:1 Touch Interface USB Surface Treatment Clear On Screen Display Accessible through switches along the bottom:
Controls: Menu, Up, Down, Select
Settings: Brightness, Contrast, Clock, Phase, H-position, V-position, Auto-Adjust, Aspect Ratio, Sharpness, Color Temperature, OSD Timeout, OSD Language, Volume, Mute, Recall Defaults, Audio Select, Power LED ON/OFF, Touch Thru
Languages: English, French, Italian, German, Spanish, Japanese, Traditional Chinese, Simplified Chinese, Russian, Korean
Lockouts: OSD, PowerI/O Ports VGA
HDMI
Combo Jack
DC jack
USB Type B
USB 2.0 Type A
4x Micro USBSpeakers Two x 2W internal speakers Input Video Format VGA (VGA DE-15 (DB-15) Male connecter cable included)
HDMI (HDMI cable included)Input Video Frequency Horizontal: 30 – 82KHz
Vertical: 50 - 75HzPower Consumption (Typical) Monitor + AC/DC adapter
ON (Default - 80% Brightness): 14.80 W
ON (Typical - 100% Brightness): 16.78 W
SLEEP: 0.69 W
OFF: 0.28 WInput Voltage 12VDC +/- 5%
100-240VAC, 50/60HzInput Connector Coaxial power jack (2.1 mm pin outer diameter, 6.4mm barrel inner diameter) Peripheral Mounting 4x Micro USB side ports (Top, Bottom, Left, Right) Monitor Dimensions (without Stand) 12.87" x 20.74" x 1.68" / 326.9 mm x 526.9 mm x 42.7 mm Monitor Dimensions (with Stand) 15.11" x 20.74" x 7.61" / 383.8 mm x 526.9 mm x 193.4 mm Shipping Box Dimensions With Stand: 18.78" x 24.29" x 10.24" / 477 mm x 617 mm x 260 mm
Without Stand: 17.72" x 24.92" x 7.72" / 450 mm x 633 mm x 196 mmWeight (Unpackaged) With Stand: 14.88 lbs / 6.75 kg
Without Stand: 10.47 lbs / 4.75 kgWeight (Packaged) With Stand: 23.81 lbs / 10.8 kg
Without Stand: 15.87 lbs / 7.2 kgOperating Temperature 0°C to 40°C / 32°F to 104°F Storage Temperature -20°C to 60°C / -4°F to 140°F Humidity Operating: 20% to 80%; Storage: 10% to 95% (38.7℃ max wet bulb temperature) Sealability Touchscreen sealed to bezel; Touchscreen sealed to LCD MTBF 50,000 hours demonstrated Mounting Options VESA 4-hole 100mm mounting interface on rear of unit Warranty 3-year Extended Service Options 4 year warranty coverage - Elo P/N: E898247
5 year warranty coverage - Elo P/N: E898449
3 year warranty coverage + AUR - Elo P/N: E898648
4 year warranty coverage + AUR - Elo P/N: E894921
5 year warranty coverage + AUR - Elo P/N: E895125Regulatory approvals and declarations Canada CUL, IC
China CCC
Europe CE
United Kingdom UKCA
Korea KCC
Taiwan BSMI
United States FCC, UL
Japan VCCI
International CB
Australia RCM
Russia EAC
Mexico CoC
India BIS
RoHS, China RoHS, WEEE, REACHIngress Protection IPX1 - Front only Impact Protection IK06 Power Cables North America Power Cable C13 - Elo P/N: E593865
Australia Power Cable C13 - Elo P/N: E594067
Europe Power Cable C13 - Elo P/N: E594264
Korea Power Cable C13 - Elo P/N: E594466
China Power Cable C13 - Elo P/N: E594670
Taiwan Power Cable C13 - Elo P/N: E594869
Japan Power Cable C13 - Elo P/N: E793799What's in the Box Touchmonitor
Quick Install Guide
3x Tie wraps
VGA cable
HDMI cable
Touch USB cable
Audio cable
Power brick
NA Power cable
EU Power cable
EEI Label
4 screws (for E126096, E992622)Replacement DC Power Supply Power Brick 50W - E593661 Optional Peripherals Magnetic Stripe Reader (MSR) – Elo P/N: E001002
Fingerprint Scanner – Elo P/N: E134286
2D Barcode Scanner (Black - SE4720) – Elo P/N: E384627
2D Barcode Scanner (Black - SE4107) – Elo P/N: E245047
EMV Cradle for MagTek eDynamo - Elo P/N: E375343
EMV Cradle for Ingenico RP457c (with Audio Jack, BT and USB) - Elo P/N: E586981
EMV Cradle for Ingenico RP457c (with BT and USB) - Elo P/N: E710930
Status Light (Micro-USB Connectivity) - Elo P/N: E644767
3D Camera - Elo P/N: E134699
Webcam - Elo P/N: E201494
RFID - Elo P/N: E673037
Elo Edge Connect™ Speaker Bar (Black) - Elo P/N: E894719
Elo Edge Connect™ Speaker Bar (White) - Elo P/N: E133780Stands, Mounts & Kits Wall Mount Kit (75mm or 100mm VESA) – Elo P/N: E143088
Shelf Mount Bracket (75mm or 100mm VESA) - Elo P/N: E043382
Pole Mount Bracket (75mm or 100mm VESA) - Elo P/N: E045151
1.8m Cable Kit - Elo P/N: E408193
Elo Stand 1902/3-2202/3 - Black (100 mm VESA) - Elo P/N: E804330
Slim Self-Service Countertop Stand (75mm or 100mm VESA) - Elo P/N: E514693
Slim Self-Service Floor Stand (75mm or 100mm VESA) - Elo P/N: E514881 + E515260
Elo Backpack® 4 (Value Model) - Elo P/N: E393754
Elo Backpack® 4 (Standard Model) - Elo P/N: E393359 -
Description Downloads Specification Sheets Download
