Opticon M-11,2D CMOS MP Omni Presentation Desktop Scanner | 14294
SKU: 14294
£239.40 (Excl. VAT)
- Description
- Specifications
- Downloads
-
Opticon M-11 2D CMOS Omni Presentation Desktop Scanner | USB, Black – Fast, Durable & Hands-Free Scanning Solution
M-11,2D CMOS MP Omni presentation desktop scanner,2 LED,Speaker,Tone adjust,HID/VCP,USB cable,Black
This Item:
Opticon M-11, 2D CMOS Megapixel Omnidirectional presentation scanner, desktop scanner, Visual 2 LED's, inbuilt speaker, tone adjustable. HID/VCP, 2 meter USB cable included, Black, Made in Japan.
The M-11 is an omni-directional scanner for on top of the counter as built-in. This scanner comes with high performance 2D CMOS Imager along with a well thought out design. The M-11 can be used as built in scanner in parking areas or as a stationary scanner on the counter in retail. Because the M-11 can be embedded into your built in scanning solution, the M-11 is perfectly suited for scanning passports and ID as well. Of course these are just examples as the M-11 can bring a scanning solution to any business.
The M-11 is an omni-directional presentation scanner, which means the scanner will scan the product or ticket from any direction. This enables an easy and efficient transaction, because the barcodes are scanned whichever way you hold them in front of the scanner.
Applications
The M-11 is perfectly suitable for parking areas and ticketing among other applications. The combination of an impressive design, ease of use and an excellent price-performance ratio makes the M-11 the ideal solution for point-of sales (POS) check-out applications, reading barcodes from mobile phones in mobile marketing applications and document handling within banks and post offices.
How we describe the M-11
The M-11 is an extraordinary product in Opticon’s range. The M-11 is the presentation scanner, combining a powerful 2D CMOS Imager with a stylish design and omni-directional capabilities. The scanner can be triggered manually or automatically, scanning at a maximum speed of 120 fps. With this scanner you can scan hands-free, just position the scanner on you counter or desk and move the barcode in front of the imager. The scanner will do the rest of the work.
The scanner is also durable with a rating of IP42 and a drop resistance of 1.5m upon concrete. The communication is USB and the black color makes it suitable for any counter or embedded in your scanning solutions for ticketing or passport and ID scanning at customs, gates, schools, prisons and so on! -
Feature Description Country of Origin Japan Tariff No. 8473502000 UNSPSC Code 43211701 Operating Humidity 10 - 90 % Operating Temperature -5 - 45 °C Storage Humidity 10 - 90 % Storage Temperature -30 - 60 °C Package Gross Weight 0.2 kg Image Formats Supported BMP, JPEG IP Code IP42 LED Indicators Yes Product Colour Black Cable Length 2.1 m Connectivity Technology Wired Data Transfer Rate 12 Mbit/s Standard Interfaces RS-232 / USB Power Source Type RS-232 / USB Net Weight (Product) 0.1 kg Product Depth 12.44 cm Product Height 4.8 cm Product Width 8.44 cm 2D Barcodes Supported Aztec, Codablock, Composite Codes, Data Matrix, MaxiCode, Micro QR, MicroPDF417, PDF417, QR Code Linear (1D) Barcodes Supported Codabar, Code 11, Code 128, Code 39, Code 93, GS1 DataBar, GS1-128, IATA, Industrial 2 of 5, Interleaved 2 of 5, ISBN, ISSN, JAN, Matrix 2 of 5, MSI, Plessey, S-Code, Telepen, Trioptic, UPC Optical Sensor Resolution 1280 × 800 pixels Pitch Reading Angle -60 – 60 ° Tilt Reading Angle 0 – 360 ° Yaw Reading Angle -70 – 70 ° Scanner Type 1D / 2D Sensor Type CMOS Type Fixed Bar Code Reader Compliance Certificates RoHS Sustainability Certificates RoHS Sustainability Compliance Yes Brand Name Opticon Warranty 2 Year(s) Main Category POS & Auto-ID Subcategory Scanning → On-Counter Scanner -
Description Downloads Opticon M-11,2D CMOS MP Omni Presentation Desktop Scanner | 14294 DataSheet Download Opticon M-11,2D CMOS MP Omni Presentation Desktop Scanner | 14294 Quick Start Guide Download
