StarTech 4-Port DisplayPort KVM Switch - USB 3.0, 4K 30Hz | SV431DPU3A2
SKU: SV431DPU3A2
£337.08 (Excl. VAT)
- Description
- Specifications
- Downloads
-
StarTech 4-Port DisplayPort KVM Switch - USB 3.0, 4K 30Hz | SV431DPU3A2
This 4-Port USB 3.0 DisplayPort KVM switch lets you control four DisplayPort (DP) computers with a single monitor, keyboard and mouse. The KVM also features 3.5 mm audio and a built-in 3-port USB 3.0 hub.
Convenient and cost-effective USB 3.0 peripheral sharing
This KVM switch offers a built-in 3-port USB 3.0 hub that's separate from your HID keyboard and mouse, so you can share USB peripheral devices between each connected computer and avoid the expense of separate equipment. The USB 3.0 hub automatically switches your connected USB devices to the selected computer, saving you the hassle of disconnecting and reconnecting your peripherals.With support for USB 3.0, you can achieve data transfer rates up to 5Gbps, to ensure flawless performance for your USB peripherals - great for quickly transferring data to external USB 3.0 drives.
Astonishing picture quality
Offering support for resolutions up to Ultra HD 4K at 30 Hz, this 4-port DisplayPort KVM switch has the ability to drive large DP displays with ease, making it ideal for graphical applications that require high-resolution video support.
Complete multimedia control
The KVM switch features auxiliary 3.5 mm audio ports that enable you to share independent analog audio, from each of your connected computers, with your desktop speaker set. Independent audio, along with 4K DP video, gives you full multimedia control between different computers, making this KVM perfect for creative professional applications such as video and sound design or editing.Applications
Control four DisplayPort USB computers with a single set of console peripherals (keyboard, mouse and monitor)Perform Ultra HD multimedia applications such as graphic design or CAD and CAM creations
Share USB 3.0 peripherals between four computers
-
Category Detail Warranty Information 2 Years Connector(s) Console Interface(s) 1 - DisplayPort (20 pin) 1 - 3.5 mm Mini-Jack (3 Position) 4 - USB Type-A (9 pin, 5 Gbps) Host Connectors 4 - DisplayPort (20 pin) 4 - USB 3.2 Type-B (9 pin, Gen 1, 5Gbps) 4 - 3.5 mm Mini-Jack (3 Position) Other Interface(s) 3 - USB Type-A (9 pin, 5 Gbps) Environmental Operating Temperature 0°C to 40°C (32°F to 104°F) Storage Temperature -10°C to 60°C (14°F to 140°F) Humidity 0~80% RH Non-Condensing Hardware Audio Yes KVM Ports 4 PC Interface USB 3.2 Gen 1 (5Gbps) PC Video Type DisplayPort Number of Monitors Supported 1 Rack-Mountable Optional Cables Included No Industry Standards HDCP 2.2 Daisy-Chain No Indicators LED Indicators 4 - Port selection/link LEDs 1 - Power LED Packaging Information Package Height 8.6 cm [3.4 in] Package Length 29.4 cm [11.6 in] Shipping (Package) Weight 1.6 kg [3.5 lb] Package Width 24.4 cm [9.6 in] Package Quantity 1 Performance On-Screen Display No IP Control No Hot-Key Selection Yes Maximum Cable Length 10 m [32.8 ft] Maximum Digital Resolutions 3840x2160 @ 30 Hz Wide Screen Supported Yes Audio Specifications Port Selection Support Push Button and Hotkeys MTBF 143,000 hours Physical Characteristics Color Black Product Length 22 cm [8.7 in] Product Width 13 cm [5.1 in] Product Height 4.3 cm [1.7 in] Weight of Product 1.1 kg [2.3 lb] Power Input Voltage 100 - 240 AC Output Voltage 12V DC Output Current 1.5 A Plug Type M Power Consumption (In Watts) 18W Special Notes / Requirements Note Active video adapters are required for optimal performance. What's in the Box Included in Package 1 - 4-port DisplayPort KVM switch 4 - Rubber feet 1 - Universal power adapter (NA, EU, UK, ANZ) 1 - Quick start guide -
Description Downloads Datasheet Downloads User Manual Downloads
