StarTech HDMI KVM Extender over IP Network - 4K 30Hz | SV565HDIP
SKU: SV565HDIP
£513.91 (Excl. VAT)
- Description
- Specifications
- Downloads
-
StarTech HDMI KVM Extender over IP Network - 4K 30Hz | SV565HDIP
This HDMI KVM extender kit lets you use a keyboard, mouse and monitor to remotely control any computer over your IP-enabled local area network (LAN). Combined with a KVM switch, the KVM console extender can be used with multiple computers. The extender features four USB ports that enable you to connect other USB devices, in addition to your keyboard and mouse.
Supports UHD 4K 30HzThe HDMI KVM extender delivers astonishing 4K UHD picture quality to your remote display with support for resolutions up to 3840 x 2160p at 30Hz.
Hassle-Free Installation
With a transmitter and a receiver, the KVM extender provides a complete end-to-end solution that supports mounting for tidy installation. Plus, it uses standard CAT5e or CAT6 Ethernet cable, eliminating the expense and hassle of specialized cables and enabling you to use existing network infrastructure.
The extender supports EDID pass-through, ensuring your computer can automatically configure optimal settings for your display over your LAN.
Versatile Configuration OptionsThe extender uses your local intranet to connect your computers to your remote workstation. You can connect additional receivers (sold separately) to distribute your HDMI signal to multiple displays in your remote location, or combine the source to create a video wall that expands your single video source across multiple displays.
For smaller-scale applications, you can connect the transmitter and receiver units directly over CAT5e or CAT6 cabling up to 330 feet (100 meters).
-
Category Detail Warranty Information Warranty 2 Years Hardware On-Screen Display Yes KVM Ports 1 PC Interface USB PC Video Type HDMI Number of Monitors Supported 1 DVI Support Yes IP Control No Hot-Key Selection No Cables Included Yes Max Transfer Distance 100m [328 ft] Connector(s) Local Unit Connectors 1 - RJ-45 1 - HDMI (19 pin) 2 - RJ-11 2 - 3.5 mm Audio 2 - 3.5 mm Mini-Jack (3 Position) 1 - USB Mini-B (5 pin) Remote Unit Connectors 1 - RJ-45 1 - HDMI (19 pin) 2 - RJ-11 2 - 3.5 mm Audio 2 - 3.5 mm Mini-Jack (3 Position) 2 - USB 2.0 Type-A (4 pin, 480Mbps) 2 - USB Type-A (4 pin; HID Port) USB 1.1 Environmental Operating Temperature 0℃ to 40℃ (32°F to 104°F) Storage Temperature -10℃ to 60℃ (14°F to 140°F) Humidity 0% to 80% Hardware Audio Yes Chipset ID ASPEED - AST1520 Daisy-Chain No Indicators LED Indicators Transmitter: Green, Blue, Flashing Blue/Green, Flashing Orange Receiver: Red, Blue, Flashing Blue/Red, Flashing Orange Packaging Information Shipping (Package) Weight 2.5 kg [5.4 lb] Package Quantity 1 Package Length 36.6 cm [14.4 in] Package Width 23.6 cm [9.3 in] Package Height 7.6 cm [3.0 in] Performance Maximum Data Transfer Rate 12MBps Maximum Cable Length 100 m [328.0 ft] Maximum Digital Resolutions 3840 x 2160 @ 30Hz (4K) Supported Resolutions 3840x2160 (4K) @ 30Hz, 2560x1600, 1920x1200 @ 60Hz, 1920x1080 (1080p), 1280x720 (720p) Wide Screen Supported Yes Audio Specifications MTBF 60,000 hours Physical Characteristics Color Black Material Steel Product Length 13.0 cm [5.1 in] Product Width 11.7 cm [4.6 in] Product Height 2.8 cm [1.1 in] Weight of Product 0.6 kg [1.3 lb] Power Power Source 2 AC Adapters Included Input Voltage 100 - 240 AC Input Current 0.6 A Output Voltage 12V DC Output Current 1.5A Center Tip Polarity Positive Plug Type M Power Consumption (In Watts) 18W Special Notes / Requirements Note Router must support IGMP snooping What's in the Box Included in Package 1 - Transmitter Unit 1 - Receiver Unit 2 - Universal Power Adapters (NA, JP, EU, UK, AU/NZ) 2 - Mounting Kits 2 - Ethernet Cables 2 - DB9 Serial Adapters 2 - RJ11 Serial Cables 1 - HDMI Cable (1.2 m) 1 - USB Cable (1.5 m) 8 - Rubber Feet 1 - Plastic Screwdriver 1 - Quick-Start Guide -
Description Downloads Datasheet Downloads User Manual Downloads
