2 MP (WDR) CMOS
High quality imaging with 1920 × 1080 resolution
Min. illumination: 0.1 Lux @ (F2.2, AGC ON)
Clear imaging against strong backlight due to 120 dB true WDR technology
AGC for self-adaptive brightness
Low distortion lens for reducing image distortion
Built-in 4-mic array microphones with clear sound
Built-in a full-range, high definition speakers
USB Type C interface, supporting USB 3.0 interface. Plug-and-play, no need to install driver software
Built-in 2450 mAh lithium battery
Compatible with leading online communication softwares
| Image Sensor | 1/2.7" 2 MP CMOS | Maximum Resolution | 1920 (H) × 1080 (V) |
| Minimum Illumination | 0.1 Lux @ (F2.2, AGC ON) | Shutter Time | PAL: 1/25 s to 1/50,000 s NTSC: 1/30 s to 1/50,000 s |
| Angle Adjustment | Tilt: -10° to 10° | Zoom | 2× |
| Lens Type | 2.8 mm fixed focal lens | Focal Length and FOV | Horizontal FOV: 110° Vertical FOV: 75° Diagonal FOV: 120° |
| Object Distance Range | 0.3 m to ∞ | Microphone Amount | 4 |
| Microphone Polar Pattern | 360° omni-directional | Microphone Pickup Distance | Radius up to 5 m |
| Microphone Sensitivity | -38 dBV/Pa | Microphone SNR | 66 dB(A) |
| Microphone Frequency Response | 100 Hz to 8 kHz | Microphone Type | MEMS |
| 3A Algorithm | AEC, ANS, AGC | Microphone Sampling Rate | 16 kHz / 48 kHz |
| Speaker Rated Power | 5 W | Speaker Range | Radius up to 8 m |
| Speaker THD | <3% @ 1 kHz | Maximum Output Loudness | 87 dB SPL @ 1 m, 1 kHz |
| Effective Bandwidth (-10 dB) | 170 Hz to 20 kHz | Image Function | Auto, manual and fixed white balance; backlight compensation; left/right flip; up/down flip; centre mirror |
| Audio Function | Supports smart noise reduction, echo suppression, anti-reverberation and squeal suppression to enhance speech quality and deliver high-quality audio | LED Indicator | Solid red: Mute Solid white: Working normally No light: Standby |
| Power Indicator | Solid red: Low power (≤15%) Solid orange: Medium power (15% < x ≤ 30%) Solid white: Enough power (30% < x ≤ 100%) |
Communication Method | USB cable |
| Wired Communication Distance | 2 m | Battery Capacity | 7.2 V / 2450 mAh |
| Charging Temperature | 0°C to 45°C (32°F to 113°F) | Discharging Temperature | -20°C to 60°C (-4°F to 140°F) |
| Storage Temperature | 0°C to 35°C (32°F to 95°F) for one year | MJPG Frame Rates | 1920 × 1080 @ 30/25 fps 1280 × 960 @ 30/25 fps 1280 × 720 @ 30/25 fps 640 × 480 @ 30/25 fps 640 × 360 @ 30/25 fps |
| YUV2 Frame Rates | 1920 × 1080 @ 5 fps 1280 × 960 @ 5 fps 1280 × 720 @ 10 fps 640 × 480 @ 30/25 fps 640 × 360 @ 30/25 fps |
H.264 Frame Rates | 1920 × 1080 @ 30/25 fps 1280 × 960 @ 30/25 fps 1280 × 720 @ 30/25 fps 640 × 480 @ 30/25 fps 640 × 360 @ 30/25 fps |
| Wide Dynamic Range | ≥120 dB | Cable in Package | Type-C to Type-A interface |
| Device Interface | USB Type-C interface | Windows Compatibility | Windows 7, 8, 10 and 11 |
| Android Compatibility | Android 8.1 and above | Linux Compatibility | Linux 4.14 and above |
| macOS Compatibility | macOS 10.12 and above | Chrome OS Compatibility | Chrome OS |
| Operating Condition | -10°C to 45°C (14°F to 113°F); humidity 90% or less, non-condensing | Material | Main body: Plastic with cloth Base: Metal |
| Packing List | Camera × 1 Privacy shutter × 1 Remote control with battery × 1 USB 3.0 cable, 2 m × 1 User manual card × 1 |
Power | 5 VDC ± 5% via USB cable, maximum 4.5 W |
| Dimensions | Ø91.7 mm × 271.3 mm (Ø3.61" × 10.68") | Package Dimensions | 337 mm × 150 mm × 156 mm (13.27" × 5.91" × 6.14") |
| Weight | Approximately 930 g (2.05 lb.) | Weight with Package | Approximately 1465 g (3.23 lb.) |
| Colour | Silver grey |
