HikAI-ISP for excellent noise reduction effect
Super clear 24/7 colorful imaging with ColorVu 3.0 technology
Motion Detection 3.0, more accurate on person and vehicle classification
Smart Hybrid Light: integrates IR and white lights, 3 supplemental lighting modes
-SL/-SRB: Provide real-time security via built-in two-way audio and strobe light alarm
-F: Support on-board storage up to 512 GB (SD card slot) (Optional)
Water and dust resistant (IP67)
| Image Sensor | 1/2.8" Progressive Scan CMOS | Max. Resolution | 1920 × 1080 |
| Min. Illumination | Color: 0.0005 Lux @ (F1.0, AGC ON), 0 Lux with light | Shutter Time | 1 s to 1/100,000 s |
| Day & Night | IR cut filter | Angle Adjustment | Pan: 0° to 360°, Tilt: 0° to 75°, Rotate: 0° to 360° |
| Lens Type | Fixed focal lens, 2.8 and 4 mm optional | Focal Length & FOV | 2.8 mm: Horizontal FOV 106°, Vertical FOV 56°, Diagonal FOV 129° 4 mm: Horizontal FOV 88°, Vertical FOV 47°, Diagonal FOV 103° |
| Lens Mount | M12 | Iris Type | Fixed |
| Aperture | F1.0 | Depth of Field | 2.8 mm: 1.2 m to ∞ 4 mm: 1.3 m to ∞ |
| DORI | 2.8 mm: D 44 m, O 17 m, R 8 m, I 4 m 4 mm: D 53 m, O 21 m, R 10 m, I 5 m |
Supplement Light Type | IR, White Light |
| Supplement Light Range | Up to 30 m | Smart Supplement Light | Yes |
| IR Wavelength | 850 nm | Main Stream | 50 Hz: 25 fps (1920 × 1080, 1280 × 720) 60 Hz: 30 fps (1920 × 1080, 1280 × 720) |
| Sub-Stream | 50 Hz: 25 fps (640 × 480, 640 × 360) 60 Hz: 30 fps (640 × 480, 640 × 360) |
Video Compression | Main stream: H.265+/H.265/H.264+/H.264, Sub-stream: H.265/H.264/MJPEG |
| Video Bit Rate | 32 Kbps to 8 Mbps | H.264 Type | Baseline Profile, Main Profile, High Profile |
| H.265 Type | Main Profile | Bit Rate Control | CBR, VBR |
| Region of Interest | 1 fixed region for main stream and sub-stream | Scalable Video Coding | H.264 and H.265 encoding |
| Audio Type | Mono sound | Audio Compression | G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/AAC-LC/MP3 |
| Audio Bit Rate | 64 Kbps (G.711), 16 Kbps (G.722.1), 16 Kbps (G.726), 32 to 160 Kbps (MP2L2), 16 to 64 Kbps (AAC-LC), 8 to 160 Kbps (MP3) | Audio Sampling Rate | 8 kHz/16 kHz |
| Environment Noise Filtering | Yes | Protocols | TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, RTCP, NTP, IPv4, IPv6, IGMP, UDP, QoS, FTP, SMTP |
| Simultaneous Live View | Up to 6 channels | API | ONVIF (Profile S, Profile G), ISAPI, SDK |
| Security | Password protection, complicated password, watermark, basic and digest authentication for HTTP, WSSE and digest authentication for Open Network Video Interface, security audit log, host authentication (MAC address) | User/Host | Up to 32 users 3 user levels: administrator, operator, and user |
| Client | iVMS-4200, HiLookVision | Web Browser | Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Edge 89+, Safari 11 Local service: Chrome 57.0+, Firefox 52.0+, Edge 89+ |
| Image Settings | Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance, adjustable by client software or web browser | Day/Night Switch | Day, Night, Auto, Schedule |
| Wide Dynamic Range | 120 dB | SNR | ≥ 52 dB |
| Image Enhancement | BLC, HLC, 3D DNR | Privacy Mask | 4 programmable rectangular privacy masks |
| Ethernet Interface | 1 RJ45 10 M/100 M self-adaptive Ethernet port | On-Board Storage | -LU: NA -LUF/S(L)(RB): Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB |
| Built-in Microphone | Yes, 1 built-in microphone | Built-in Speaker | -LU: NA -LUF/S(L)(RB): Max. power consumption: 2 W, max. sound pressure level: 10 cm: 101 dB |
| Audio Interface | NA | Alarm | NA |
| Reset Key | -LU: NA -LUF/S(L)(RB): YES |
Basic Event | Motion detection (support alarm triggering by specified target types: human and vehicle), video tampering alarm, exception |
| Linkage | Upload to memory card/FTP, notify surveillance center, send email, trigger recording, trigger capture | Power | -LUF/S(L)(RB): 12 VDC ± 25%, 0.52 A, max. 6.24 W, Ø5.5 mm coaxial power plug, reverse polarity protection, PoE: IEEE 802.3af, Class 3, max. 7.52 W -LU(F): 12 VDC ± 25%, 0.52 A, max. 6.2 W, Ø5.5 mm coaxial power plug, reverse polarity protection, PoE: IEEE 802.3af, Class 3, max. 7.5 W |
| Material | Cover: Plastic, main body: Metal | Dimension | Ø112 mm × 82 mm (Ø4.4" × 3.2") |
| Package Dimension | 150 mm × 150 mm × 141 mm (5.9" × 5.9" × 5.6") | Weight | -LU: Approx. 350 g (0.8 lb.) |
| With Package Weight | -LU: Approx. 530 g (1.2 lb.) | Storage Conditions | -30 °C to 60 °C (-22 °F to 140 °F), humidity 95% or less (non-condensing) |
| Startup and Operating Conditions | -30 °C to 60 °C (-22 °F to 140 °F), humidity 95% or less (non-condensing) | Language | English, Russian, Ukrainian, Arabic, Spanish, French, Portuguese, Turkish, Polish, German |
| General Function | Heartbeat, mirror, flash log, password reset via email, password protection, anti-banding | Flashing Light | -LU: NA -LUF/SL: White Light -LUF/SRB: Red and Blue Light |
| EMC | CE-EMC: EN 55032:2015+A1:2020, EN 50130-4:2011+A1:2014, EN IEC 61000-3-2:2019+A1:2021, EN 61000-3-3:2013+A1:2019+A2:2021 | Safety | CB: IEC 62368-1: 2014+A11 CE-LVD: EN 62368-1: 2014/A11: 2017 |
| Environment | CE-RoHS: 2011/65/EU WEEE: 2012/19/EU Reach: Regulation (EC) No 1907/2006 |
Protection | IP67: IEC 60529-2013 |
