High quality imaging with 2 MP resolution
Support Human and Vehicle Detection
Smart Hybrid Light: advanced technology with long range
Built-in microphone for real-time audio security
Efficient H.265+ compression technology
Water and dust resistant (IP67)
| Image Sensor | 1/2.8" Progressive Scan CMOS | Max. Resolution | 1920 × 1080 |
| Min. Illumination | Color: 0.001 Lux @ (F1.0, AGC ON), 0 Lux with light | Shutter Time | 1/3 s to 1/100,000 s |
| Day & Night | IR cut filter | Angle Adjustment | Pan: 0° to 360°, Tilt: 0° to 75°, Rotate: 0° to 360° |
| Lens Type | Fixed focal lens, 2.8 and 4 mm optional | Focal Length & FOV | 2.8 mm: horizontal FOV 106°, vertical FOV 56°, diagonal FOV 129° 4 mm: horizontal FOV 88°, vertical FOV 47°, diagonal FOV 103° |
| Lens Mount | M12 | Iris Type | Fixed |
| Aperture | F1.0 | DORI | 2.8 mm: D 44 m, O 17 m, R 8 m, I 4 m 4 mm: D 53 m, O 21 m, R 10 m, I 5 m |
| Supplement Light Type | IR, White Light | Supplement Light Range | Up to 30 m |
| Smart Supplement Light | Yes | IR Wavelength | 850 nm |
| Main Stream | 50 Hz: 25 fps (1920 × 1080, 1280 × 720) 60 Hz: 30 fps (1920 × 1080, 1280 × 720) |
Sub-Stream | 50 Hz: 25 fps (640 × 480, 640 × 360) 60 Hz: 30 fps (640 × 480, 640 × 360) |
| Video Compression | Main stream: H.265+/H.265/H.264+/H.264 Sub-stream: H.265/H.264/MJPEG |
Video Bit Rate | 32 Kbps to 8 Mbps |
| H.264 Type | Baseline Profile, Main Profile, High Profile | H.265 Type | Main Profile |
| Bit Rate Control | CBR, VBR | Region of Interest | 1 fixed region for main stream |
| Audio Type | Mono sound | Audio Compression | G.711/G.722.1/G.726/MP2L2/PCM/AAC-LC |
| Audio Bit Rate | 64 Kbps (G.711), 16 Kbps (G.722.1), 16 Kbps (G.726), 32 to 160 Kbps (MP2L2), 16 to 64 Kbps (AAC-LC) | Audio Sampling Rate | 8 kHz/16 kHz |
| Environment Noise Filtering | Yes | Protocols | TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, RTCP, NTP, IGMP, UDP, QoS, FTP, SMTP, UPnP |
| Simultaneous Live View | Up to 6 channels | API | Open Network Video Interface (Profile S, Profile T), ISAPI, SDK |
| Security | Password protection, complicated password, watermark, basic and digest authentication for HTTP, WSSE and digest authentication for Open Network Video Interface, security audit log, host authentication (MAC address) | User/Host | Up to 32 users 3 user levels: administrator, operator, and user |
| Client | iVMS-4200, HiLookVision | Web Browser | Plug-in required live view: IE 10, IE 11 Local service: Chrome 57.0+, Firefox 52.0+, Edge 89+ |
| Image Settings | Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance, adjustable by client software or web browser | Day/Night Switch | Day, Night, Auto, Schedule |
| Wide Dynamic Range | Digital WDR | SNR | ≥ 52 dB |
| Image Enhancement | BLC, HLC, 3D DNR | Privacy Mask | 4 programmable polygon privacy masks |
| Ethernet Interface | 1 RJ45 10 M/100 M self-adaptive Ethernet port | Built-in Microphone | Yes |
| Basic Event | Motion detection (support alarm triggering by specified target types: human and vehicle), video tampering alarm, exception | Linkage | Upload to FTP, notify surveillance center, send email, trigger capture |
| Power | 12 VDC ± 25%, 0.45 A, max. 5.4 W, Ø5.5 mm coaxial power plug, reverse polarity protection PoE: IEEE 802.3af, Class 3, max. 6.5 W |
Material | Metal & Plastic |
| Dimension | Ø112 mm × 82 mm (Ø4.41" × 3.23") | Package Dimension | 150 mm × 150 mm × 141 mm (5.91" × 5.91" × 5.55") |
| Weight | Approx. 375 g (0.8 lb.) | With Package Weight | Approx. 610 g (1.2 lb.) |
| Storage Conditions | -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) | Operating Conditions | -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) |
| Language | English, Ukrainian | General Function | Heartbeat, anti-banding, mirror, password protection, password reset by email |
| EMC | CE-EMC: EN 55032:2015+A1:2020, EN 50130-4:2011+A1:2014, EN IEC 61000-3-2:2019+A1:2021, EN 61000-3-3:2013+A1:2019+A2:2021 RCM: AS/NZS CISPR 32: 2015 IC: ICES-003: Issue 7 |
Safety | CB: IEC 62368-1: 2014+A11 CE-LVD: EN 62368-1: 2014/A11: 2017 |
| Environment | CE-RoHS: 2011/65/EU WEEE: 2012/19/EU Reach: Regulation (EC) No 1907/2006 |
Protection | IP67: IEC 60529-2013 |
