High quality imaging with 4 MP resolution
Clear imaging against strong backlight due to Digital WDR technology
Focus on human and vehicle classification based on deep learning
Provide real-time security via built-in two-way audio
Hik-Connect cloud service and app for remote management and views of devices
| Image Sensor | 1/3" Progressive Scan CMOS | Max. Resolution | 2560 × 1440 |
| Min. Illumination | Color: 0.005 Lux @ (F1.6, AGC ON), B/W: 0 Lux with IR | Shutter Time | 1/3 s to 1/100,000 s |
| Day & Night | IR cut filter | Angle Adjustment | Pan: 0° to 360°, tilt: 0° to 90°, rotate: 0° to 360° |
| Focal Length & FOV | 2.8 mm, horizontal FOV 92°, vertical FOV 50°, diagonal FOV 110° 4 mm, horizontal FOV 75°, vertical FOV 41°, diagonal FOV 89° |
Aperture | F1.6 |
| Lens Mount | M12 | DORI | 2.8 mm: D: 56.0 m, O: 22.2 m, R: 11.2 m, I: 5.6 m 4 mm: D: 79.4 m, O: 31.5 m, R: 15.9 m, I: 7.9 m |
| Supplement Light Type | IR | Supplement Light Range | Up to 10 m |
| IR Wavelength | 850 nm | Smart Supplement Light | Yes |
| Main Stream | 50 Hz: 25 fps (2560 × 1440, 1920 × 1080, 1280 × 720) 60 Hz: 30 fps (2560 × 1440, 1920 × 1080, 1280 × 720) |
Sub-Stream | 50 Hz: 25 fps (1280 × 720, 768 × 432, 512 × 288) 60 Hz: 30 fps (1280 × 720, 768 × 432, 512 × 288) |
| Video Compression | Main stream: H.265/H.264 Sub-stream: H.265/H.264 |
Video Bit Rate | Up to 2 Mbps |
| H.264 Type | Baseline Profile/Main Profile/High Profile | H.265 Type | Main Profile |
| Bit Rate Control | CBR/VBR | Environment Noise Filtering | Yes |
| Audio Sampling Rate | 8 kHz/16 kHz | Audio Compression | G.711/AAC-LC |
| Audio Bit Rate | 64 Kbps (G.711ulaw/G.711alaw)/16 to 64 Kbps (AAC-LC) | Simultaneous Live View | Up to 4 channels |
| API | ONVIF, SDK | Protocols | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, RTP, RTSP, RTCP, NTP, UPnP, IGMP, QoS, IPv4, UDP, Bonjour, SSL/TLS |
| User/Host | Administrator | Security | Password protection, HTTPS encryption, Security Audit Log, basic and digest authentication for HTTP/HTTPS, TLS 1.1/1.2, WSSE for Open Network Video Interface |
| Client | iVMS-4200, HiLookVision, Hik-Partner-Pro | Encryption Mode | WPA-PSK/WPA2-PSK |
| Wi-Fi Protocol | IEEE 802.11b, 802.11g, 802.11n | Frequency Range | 2.412 GHz to 2.472 GHz |
| Channel Bandwidth | 20 MHz | Modulation | 802.11b: CCK, QPSK, BPSK 802.11g: OFDM 802.11n: OFDM |
| Wireless Range | Up to 50 m (The performance varies based on actual environment) | Transfer Rate | 11b: up to 54 Mbps 11g: up to 54 Mbps 11n: up to 150 Mbps |
| Wide Dynamic Range | Digital WDR | Privacy Mask | 4 programmable polygon privacy masks |
| Day/Night Switch | Day, Night, Auto, Schedule | Image Parameters Switch | Yes |
| Image Settings | Saturation, brightness, contrast, sharpness, gain, white balance adjustable by client software | Built-in Microphone | Yes, 1 built-in microphone |
| Built-in Speaker | Yes, 1 built-in speaker | On-Board Storage | Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB |
| Reset Key | Yes | Ethernet Interface | 1 RJ45 10 M/100 M self-adaptive Ethernet port |
| Basic Event | Motion detection (support alarm triggering by specified target types: human and vehicle), exception | Linkage | Upload to memory card, notify surveillance center, trigger capture, audible warning, auto-tracking lite |
| Power | 12 VDC, 0.38 A, max. 4.56 W, Ø2.0 mm coaxial power plug PoE: IEEE 802.3af, Class 3 |
General Function | Heartbeat, mirror |
| Storage Conditions | -10 °C to 45 °C (14 °F to 113 °F). Humidity 95% or less (non-condensing) | Startup and Operating Conditions | -10 °C to 45 °C (14 °F to 113 °F). Humidity 95% or less (non-condensing) |
| Material | Plastic | Dimension | 102.9 mm × 65.2 mm × 32.9 mm (4.1" × 2.6" × 1.3") |
| Package Dimension | 150 mm × 125 mm × 99 mm (5.9" × 4.9" × 3.9") | Weight | Approx. 120 g (0.3 lb.) |
| With Package Weight | Approx. 430 g (0.9 lb.) | EMC | CE-EMC (EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3:2013+A1:2019, EN 50130-4: 2011 +A1: 2014) |
| RF | CE-RED (EN 301489-1 V2.1.1(BT or 2.4G); EN 301489-17 V3.1.1(BT or 2.4G); EN 300328 V2.1.1(BT or 2.4G); EN 62311:2008(BT or 2.4G)) | Safety | CE-LVD (EN 62368-1:2014/A11:2017) |
| Environment | CE-RoHS (2011/65/EU) WEEE (2012/19/EU) |
