High quality imaging with 6 MP resolution
24/7 colorful imaging
Support Person and Vehicle Detection
Smart Hybrid Light: advanced technology with long range cover
Provide real-time security via built-in two-way audio
Efficient H.265+ compression technology
Support on-board storage up to 512 GB (SD card slot)
Water and dust resistant (IP67)
180° Field of view
Active strobe light and audio alarm to warn intruders off
| Image Sensor | 1/2.5" Progressive Scan CMOS | Max. Resolution | 3632 × 1632 |
| Min. Illumination | Color: 0.001 Lux @ (F1.0, AGC ON), 0 Lux with light | Shutter Time | 1 s to 1/100,000 s |
| Day & Night | 24/7 color imaging | Angle Adjustment | Pan: 0° to 360°, tilt: 0° to 75°, rotate: 0° to 360° |
| Lens Type | Fixed focal lens, 2.8 mm | Focal Length & FOV | 2.8 mm, horizontal FOV 180°, vertical FOV 79° |
| Lens Mount | M12 | Iris Type | Fixed |
| Aperture | F1.0 | DORI | 2.8 mm, D: 44 m, O: 17 m, R: 8 m, I: 4 m |
| Supplement Light Type | IR, White Light | Supplement Light Range | Up to 30 m |
| Smart Supplement Light | Yes | IR Wavelength | 850 nm |
| Main Stream | 50 Hz: 20 fps (3632 × 1632) 60 Hz: 20 fps (3632 × 1632) |
Sub-Stream | 50 Hz: 20 fps (1200× 536, 960 × 432) 60 Hz: 20 fps (1200× 536, 960 × 432) |
| Video Compression | Main stream: H.265+/H.265/H.264+/H.264 Sub-stream: H.265/H.264/MJPEG |
Video Bit Rate | 32 Kbps to 16 Mbps |
| H.264 Type | Baseline Profile, Main Profile, High Profile | H.265 Type | Main Profile |
| Bit Rate Control | CBR, VBR | Scalable Video Coding | H.264 and H.265 encoding |
| Region of Interest | 1 fixed region for main stream | Audio Type | Mono sound |
| Audio Compression | G.711/G.722.1/G.726/MP2L2/PCM/AAC-LC | Audio Bit Rate | 64 Kbps (G.711ulaw/G.711alaw), 16 Kbps (G.722.1), 16 Kbps (G.726), 32 to 160 Kbps (MP2L2), 16 to 64 Kbps (AAC-LC) |
| Audio Sampling Rate | 8 kHz/16 kHz | Environment Noise Filtering | Yes |
| Protocols | TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, RTCP, NTP, IPv4, IPv6, IGMP, UDP, QoS, FTP, SMTP | Simultaneous Live View | Up to 6 channels |
| API | ONVIF (Profile S, Profile T, Profile G), ISAPI, SDK | User/Host | Up to 32 users 3 user levels: administrator, operator, and user |
| Security | Password protection, complicated password, watermark, basic and digest authentication for HTTP, WSSE and digest authentication for Open Network Video Interface, security audit log, host authentication (MAC address) | Client | iVMS-4200, HiLookVision |
| Web Browser | Plug-in required live view: IE 11 Local service: Chrome 80+, Firefox 80+, Edge 89+ |
Image Settings | Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance, adjustable by client software or web browser |
| Day/Night Switch | Day, Night, Auto, Schedule | Wide Dynamic Range | 120 dB |
| SNR | ≥ 52 dB | Image Enhancement | BLC, HLC, 3D DNR |
| Privacy Mask | 4 programmable polygon privacy masks | Ethernet Interface | 1 RJ45 10 M/100 M self-adaptive Ethernet port |
| On-Board Storage | Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB | Built-in Microphone | Yes, 1 built-in microphone |
| Built-in Speaker | Yes, 1 built-in speaker, Max. power consumption: 2 W, max. sound pressure level: 10 cm: 97 dB | Reset Key | Yes |
| Basic Event | Motion detection (support alarm triggering by specified target types (human and vehicle)), video tampering alarm, exception | Linkage | Upload to FTP, upload to memory card, send email, notify surveillance center, trigger recording, trigger capture, audible warning, strobe light flashing |
| Power | 12 VDC ± 25%, 0.83 A, max. 10 W, Ø5.5 mm coaxial power plug, reverse polarity protection PoE: IEEE 802.3af, Class 3, max. 11.5 W |
Material | Base: Metal, cover: Plastic |
| Dimension | Ø130.1 mm × 109.1 mm (Ø5.1" × 4.3") | Package Dimension | 150 mm × 150 mm × 141 mm (5.5" × 4.5" × 5.6") |
| Weight | Approx. 580 g (1.3 lb.) | With Package Weight | Approx. 760 g (1.7 lb.) |
| Storage Conditions | -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) | Startup and Operating Conditions | -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) |
| Language | English, Turkish, Polish, Romanian, Czech, Slovak, Traditional Chinese, Thai, Vietnamese, Croatian, Slovenian, Serbian, Ukrainian | General Function | Heartbeat, anti-banding, password reset via email, password protection |
| Flashing Light | /SRB model: Red and Blue Light /SL model: White Light |
EMC | CE-EMC: EN 55032:2015+A1:2020, EN 50130-4:2011+A1:2014, EN IEC 61000-3-2:2019+A1:2021, EN 61000-3-3:2013+A1:2019+A2:2021 IC: ICES-003: Issue 7 KC: KN32: 2015, KN35: 2015 |
| Safety | CB: IEC 62368-1: 2014+A11 | Environment | CE-RoHS: 2011/65/EU WEEE: 2012/19/EU Reach: Regulation (EC) No 1907/2006 |
| Protection | IP67: IEC 60529-2013 |
| Description | Downloads |
|---|---|
| Datasheet | Download |
| User Manual | Download |
| Quick Start Guide | Download |
