The ultra-modern, unique zero bezel design and small footprint of the DT-100P-A1 makes it a one-stop-shop solution for a variety of applications. The versatile USB-C port with ALT DP mode, power delivery input, and touch acceptance eliminates the need to manage multiple cables enabling a seamless aesthetic while driving efficiencies during the installation process. This 10-point touch projected capacitive display with a 16:10 – 1280×800 resolution is designed to create a memorable touch experience for retail point-of-sale second displays, small form factor point-of-service, in-aisle or end-aisle interactive signage applications, and more. The seamless bezel, advanced PCAP technology and rounded aesthetic bridges the gap between daily consumer devices and commercial devices, a step towards commonality and memorable end-user experience.
| Size | 10.1" TFT LCD | Maximum Resolution | 1280 x 800 |
| Contrast Ratio | 1000:1 | Aspect Ratio | 16:10 |
| Brightness | 350 nits (No Touch), 290 nits (PCAP) | View Angle | H:160˚, V:160˚ |
| Video Port | 1 x VGA, 1 x DP, 1 x HDMI | Warranty | 3 year |
| Touch Screen | Projected Capacitive | Touch Points | 10 |
| Touch Screen Interface | USB-HID | Display Surface | 7H Hardness durable glass |
| OSD Port | 1 x RJ11 | USB Port | 1 x USB Type C (ALT Mode & PD Input) |
| Audio Port | 1 x Audio-Input (3.5 mm Mini-Jack) | Power Input | 1 x DC In 12V Jack Power Input |
| Power Supply | 36W (12V, 3A) External Power Adaptor | Speaker | 2 x 2W Stereo |
| Housing Color | Black | Material | Plastic, Glass, SECC Metal |
| Compliance | IP65 – Front Only | Dimensions (W x H x D) mm | 245.4 x 170.5 x 30.3 mm (monitor only) |
| Net Weight (kg) | 0.95 kg (monitor only) | Gross Weight (kg) | 6.80 kg (5 units set) (monitor only) |
| Carton (W x H x D) mm | 450 x 335 x 295 mm (monitor only) | VESA | 75 x 75 mm |
| Certifications | CE, FCC, UL, CB, UKCA | Operating Temperature | 0˚C ~ 40˚C, 20% ~ 80% RH. Non-Condensing |
| Storage Temperature | -20˚C ~ 60˚C, 10% ~ 90% RH. Non-Condensing | Box Contents | LCD Touch Monitor, Power Cord, Power Supply, AC-DC Adapter, HDMI, USB-C to A, USB-C to C |
| Description | Downloads |
|---|---|
| MicroTouch 10.1" TFT LCD WXGA PCAP Touch Monitor | DT-100P-A1 DataSheet | Download |
