The SK-150P-A1 is a 15″ standard format convertible monitor perfect for any industrial grade application, embedded or exposed, that requires quality and reliability in high use environments. Versatile by design, this 15” monitor fits a variety of applications with the ability to withstand harsh conditions while retaining high performance levels. The IP65 rating coupled with an updated I/O selection for seamless integration and OSD controls built into the back housing create a user experience that is effortless and simplistic.
| Size | 15" TFT LCD | Maximum Resolution | 1024 x 768 |
| Contrast Ratio | 800:1 | Aspect Ratio | 4:3 |
| Brightness | 350 nits (No Touch), 315 nits (P-CAP) | View Angle | H:160°, V:150° |
| Video Port | 1 x VGA (DB15), 1 x HDMI, 1 x DP | Warranty | 3 Years |
| Touch Screen | Projected Capacitive | Touch Points | 10 |
| Touch Screen Interface | USB-HID (Type B) | USB Port | 1 x USB 2.0 (Type B) for Touch Interface |
| Audio Port | – | Power Input | 1 x 2.1 mm 12V DC Jack |
| Other Port | 1 x RJ11 Remote OSD | Power Supply | Max. 60W (12V, 5A) External Power Adaptor |
| Speaker | – | Housing Color | Black |
| Construction | Glass, SECC Metal, Plastic (ABS) | Compliance | Front Panel IP65, Rear IPX1 |
| Dimensions (W x H x D) | 337.4 x 265.4 x 44.3 mm | Net Weight | 2.7 kg |
| Gross Weight | 4 kg | Carton (W x H x D) | 355 x 435 x 165 mm |
| VESA | 100 x 100 mm | Ball Drop | – |
| Certifications | CE, FCC, UL(62368), CB(62368), CCC | Operating Temperature | 0°C ~ 40°C, 20% ~ 80% RH |
| Storage Temperature | -20°C ~ 60°C, 10% ~ 90% RH | Industrial Stand | IS-000-A1 (Primary Stand, Sold Separately) |
| Remote OSD | Rem11-A1 (Sold Separately) | Box Contents | LCD Touch Monitor, Power Cord, DC Power Supply, HDMI Cable, VGA Cable, USB Cable (A to B), M3 Screw & IO Cover |
| Optional Accessories | Bracket Kit: BRKT-KIT-A1, 50W Power Supply (PS-3316005049F0), Power Cables (PC-5330001214FI / EPC-5331021201FI), HDMI Cable (HDMI-5313118134FH), DP Cable (DP-5313118123FV), VGA Cable (VGA-5313118072FH), USB Cable (USB-5313118047FV) | ||
| Description | Downloads |
|---|---|
| MicroTouch 15" TFT LCD Slimline Kiosk Touch Monitor | SK-150P-A1 DataSheet | Download |
| MicroTouch 15" TFT LCD Slimline Kiosk Touch Monitor | SK-150P-A1 User Manual | Download |
