MicroTouch 19" TFT LCD Open Frame Touch Monitor | OF-190P-A1
SKU: OF-190P-A1
£143.18 (Excl. VAT)
- Display Size19"
- Touch Capabilities10pt multi-touch
- Net Weight6 kg
- Operating SystemNone
- VESA Patterns100x100
- Panel TypeTFT Panel
- ResolutionSXGA
- Screen TypeFlat
- Response TimeN/A
- Screen Ratio5:4
- Brightness215 cd/m2
- Operating HoursN/A
- Description
- Specifications
- Downloads
-
MicroTouch OF-190P-A1 19" Open Frame Touch Monitor with 1280×1024 Resolution, HDMI/DP/VGA Inputs & 10-Point PCAP Touch
This industrial-grade, OF-190P-A1, 19″ open frame monitor is the perfect solution for a wide variety of embedded applications. Uniquely designed with the glass settling proud of the bezel allowing for a seamless fit into a broad range of kiosks and fixtures, exceeding your integration expectations – The IP65 rating, 10-point touch, 1280×1024 resolution and innovative bezel design encourages a memorable end-user experience that outperforms the competition with a dependable, reliable, performance driven product.
-
Size 19" TFT LCD Maximum Resolution 1280 x 1024 Contrast Ratio 1000:1 Aspect Ratio 5:4 Brightness 250 nits (No Touch), 215 nits (P-CAP) View Angle H:170˚, V:160˚ Video Port 1 x VGA, 1 x HDMI, 1 x DP Warranty 3 Year Touch Screen Projected Capacitive Touch Points 10 Touch Screen Interface USB-HID (Type B) USB Port 1 x USB 2.0 (Type B) for Touch Interface (USB-HID) Audio Port – Power Input 1 x 2.1 mm 12V DC Jack Other Port 1 x RJ11 Power Supply Max. 60W (12V, 5A) External Power Adaptor Speaker – Housing Color Dark Gray Construction Glass, SECC Metal, Plastic (ABS) Compliance Front Panel IP65 Compliant, Rear IPX1 Dimensions (W x H x D) 432.9 x 360.3 x 58.4 mm Net Weight 5.8 kg Gross Weight 8.2 kg Carton (W x H x D) 525.0 x 460.0 x 165.0 mm VESA 75 x 75 mm, 100 x 100 mm Ball Drop – Certifications CE, FCC, CB, UL Operating Temperature 0°C ~ 40°C, 20% ~ 80% RH. Non-Condensing Storage Temperature -20°C ~ 60°C, 10% ~ 90% RH. Non-Condensing Box Contents LCD Touch Monitor, Power Cord, DC Power Supply, USB Cable (A to B), VGA Cable, HDMI Cable, DP Cable, Side Brackets, Screws M4 x 6 Optional Accessories 50W Power Supply: PS-3316005049F0, Power Cable: PC-5330001214FI, EU Power Cable: EPC-5331021201FI, HDMI Cable: HDMI-5313118134FH, DP Cable: DP-5313118123FV, VGA Cable: VGA-5313118072FH, USB Cable: USB-5313118047FV -
Description Downloads MicroTouch 19" TFT LCD Open Frame Touch Monitor | OF-190P-A1 DataSheet Download MicroTouch 19" TFT LCD Open Frame Touch Monitor | OF-190P-A1 User Manual Download
