The commercial-grade SK-215P-A1 is a Full HD wide format convertible monitor perfect for a wide range of applications, embedded or exposed, that require quality and reliability in high use environments. Versatile by design, this 21.5” wide monitor fits a variety of applications with the ability to withstand harsh conditions while retaining high performance levels. The IP65 rating coupled with an updated I/O selection for seamless integration and OSD controls built into the back housing create a user experience that is effortless and simplistic.
| Size | 21.5" TFT LCD | Maximum Resolution | 1920 x 1080 |
| Contrast Ratio | 1000:1 | Aspect Ratio | 16:9 |
| Brightness | 250 nits (No Touch), 217 nits (P-CAP) | View Angle | H:178°, V:178° |
| Video Port | 1 x VGA (DB15), 1 x HDMI, 1 x DP | Warranty | 3 Year |
| Touch Screen | Projected Capacitive | Touch Points | 10 |
| Touch Screen Interface | USB-HID (Type B) | USB Port | 1 x USB 2.0 (Type B) for Touch Interface |
| Power Input | 1 x 2.1 mm 12V DC Jack | Other Port | 1 x RJ45 Remote OSD |
| Power Supply | Max. 60W (12V, 5A) External Power Adaptor | Speaker | – |
| Housing Color | Black | Construction | Glass, SECC Metal, Plastic (ABS) |
| Compliance | Front Panel IP65, Rear IPX1 | Dimensions (W x H x D) | 517.4 x 313.3 x 46.0 mm |
| Net Weight | 4.4 kg | Gross Weight | 6.8 kg |
| Carton (W x H x D) | 610 x 405 x 160 mm | VESA | 100 x 100 mm |
| Certifications | CE, FCC, UL(62368), TUV(60950), CCC, BSMI, LVD(65950) | Ball Drop | – |
| Operating Temperature | 0°C ~ 40°C, 20% ~ 80% RH | Storage Temperature | -20°C ~ 60°C, 10% ~ 90% RH |
| Box Contents | LCD Touch Monitor, Power Cord, DC Power Supply, HDMI Cable, VGA Cable, USB Cable (A to B), M3 Screw & IO Cover | ||
| Optional Peripheral | Industrial Stand: IS-000-A1 (Primary Stand, Sold Separately), Remote OSD: Rem45-A1 (Sold Separately) | ||
| Optional/Replacement Accessories | Bracket Kit: BRKT-KIT-A2, 50W Power Supply (PS-3316005049F0), Power Cables (PC-5330001214FI / EPC-5331021201FI), HDMI Cable (HDMI-5313118134FH), DP Cable (DP-5313118123FV), VGA Cable (VGA-5313118072FH), USB Cable (USB-5313118047FV) | ||
| Description | Downloads |
|---|---|
| MicroTouch 21.5" Full HD TFT LCD Slimline Kiosk Touch Monitor | SK-215P-A1 DataSheet | Download |
| MicroTouch 21.5" Full HD TFT LCD Slimline Kiosk Touch Monitor | SK-215P-A1 User Manual | Download |
