General |
|
Enclosure Colour |
White |
Networking |
Ethernet |
Device Type |
3LCD projector - 1080p |
Expansion / Connectivity |
|
Interfaces |
1 x RGB input - 15 pin HD D-Sub (HD-15), 1 x audio line-in - mini-phone stereo 3.5 mm, 1 x DVI-D input - 24+1 pin digital DVI, 1 x HDMI input - 19 pin HDMI Type A, 1 x HDBaseT - RJ-45, 1 x composite video input - BNC, 1 x VGA output - 15 pin D-Sub (DB-15), 1 x audio line-out - mini-phone stereo 3.5 mm, 1 x DVI-D output - 24+1 pin digital DVI, 1 x remote control - 9 pin D-Sub (DB-9), 1 x network - RJ-45, 1 x remote control - mini-phone stereo 3.5 mm, USB |
Miscellaneous |
|
Security Features |
Security lock slot (cable lock sold separately) |
Security Slot Type |
Kensington security slot |
Power |
|
Power Consumption Stand by |
0.5 Watt |
Power Source |
AC |
Power Consumption Operational |
397 Watt |
Voltage Required |
AC 100-240 V (50/60 Hz) |
Environmental Parameters |
|
Min Operating Temperature |
0 °C |
Max Operating Temperature |
45 °C |
Sound Emission |
36 dB |
Sound Emission (Economic Mode) |
34 dB |
Humidity Range Operating |
20 - 80% (non-condensing) |
Video Input |
|
TV System |
NTSC, SECAM, PAL |
DVI-D with HDCP Input |
Yes |
LAN and Wireless Image Transferring Protocols |
Wired LAN |
Video Interfaces |
HDMI, DVI, RGB, HDBaseT |
Video Modes |
1080/60i, 480/60p, 720/60p, 1080/50i, 720/50p, 576/50p, 1080/50p, 1080/60p, 480/60i, 576/50i, 3840/25p, 3840/24p, 3840/30p, 3840/60p, 4096/24p, 4096/60p, 4096/30p, 4096/25p |
Dimensions & Weight |
|
Weight |
13 kg |
Width |
46 cm |
Depth |
49.4 cm |
Height |
16.9 cm |
Projector |
|
Native Aspect Ratio |
16:10 |
Controls & Adjustments |
Keystone correction, lens shift dial (horizontal), lens shift dial (vertical) |
Image Size |
102 cm - 1524 cm |
Throw Ratio |
1.39 - 2.23:1 |
Resolution |
WUXGA - WUXGA (1920 x 1200) |
Display Format |
6,912,000 pixels (1920 x 1200) x 3 |
Bulb type |
Laser diode |
Brightness (Colour) |
6000 lumens |
Brightness |
6500 lumens |
Brightness (Reduced) |
4800 lumens |
Contrast Ratio |
∞:1 |
Max Sync Rate (V x H) |
93 Hz x 63 kHz |
Bulb life cycle |
Up to 20000 hour(s) - standard mode, Up to 30000 hour(s) - middle mode |
Features |
Auto Input Search, High-bandwidth Digital Content Protection System (HDCP), 3LCD Technology, BrightEra, Cloning Function, Reality Creation, auto power on, Z-Phosphor light source, Bright View |
Lens |
|
Vertical Keystone Correction |
-30 / +30 |
Horizontal Keystone Correction |
-30 / +30 |
Zoom Factor |
1.6x |
Keystone Correction Direction |
Horizontal, vertical |
Lens Shift Direction |
Horizontal, vertical |
Zoom Type |
Powered |
Focus Type |
Powered |
Lens Shift Type |
Powered |
Type |
Standard lens |
Horizontal Lens Shift |
32% / 32% |
Vertical Lens Shift |
5% / 70% |
