The Synology Disk Station DS925+ is a NAS server that offers scalability and performance for personal and business use. Designed with a robust Ryzen quad-core processor operating at 2.2 GHz, this device ensures efficient multitasking and seamless data access. With 4 GB of DDR4 ECC RAM and support for a maximum storage capacity of 200 TB, it meets the demands of data-intensive environments, enabling users to store and manage large volumes of information effectively. Equipped with four hot-swap bays for 2.5" / 3.5" drives and two M.2 2280 expansion slots, the DS925+ supports flexible storage configurations and provides easy upgrades. This server includes features like hardware encryption, scheduled power on/off, and H.264/H.265 encoding for multimedia applications. Networking is enhanced with 2.5 Gigabit Ethernet support and compatibility with various network file systems and protocols, making it an ideal choice for homes and businesses seeking reliable and high-performance storage solutions.
Efficient cooling system
The DS925+ features two built-in 92 mm fans that maintain optimal operating temperatures, ensuring the system remains cool during heavy workloads and extends the lifespan of the components.
Flexible storage options
With four hot-swap bays, users can easily install or replace hard drives without downtime, along with support for SSDs to enhance data access speeds.
Advanced data protection
This NAS server offers data protection with RAID levels 0, 1, 5, 6, 10, and JBOD, allowing customization based on performance and redundancy needs.
Comprehensive network compatibility
It supports various network protocols such as SMB, FTP, and NFS, providing options for data sharing and management across different operating systems.
Energy-efficient design
Operating at a low power consumption of 37. 91 watts, the DS925+ delivers efficient performance while minimizing energy costs, making it a sustainable option for data storage.
What's in the box
Synology Disk Station DS925+
2 x network cable
Power adapter, accessory pack, power cable
| Feature | Description |
|---|---|
| CPU | AMD Ryzen V1500B, Quad-Core, 64-bit, 2.2 GHz, Hardware Encryption Engine |
| Memory | 4 GB DDR4 ECC SODIMM (1x 4 GB installed), 2 slots, Max 32 GB (16 GB x 2) |
| Drive Bays | 4 Bays, Expandable to 9 (DX525 x 1), 2x M.2 NVMe Slots, Supports 3.5" SATA HDD, 2.5" SATA SSD, M.2 2280 NVMe SSD |
| Hot Swappable | Yes (HDD/SSD only, not for M.2) |
| External Ports | 2x 2.5GbE LAN (RJ-45), 2x USB 3.2 Gen1, 1x USB Type-C Expansion |
| Size / Weight | 166 x 199 x 223 mm, 2.26 kg |
| System Fans | 92 x 92 mm x 2, Modes: Full-Speed, Cool, Quiet |
| Noise Level | 20.5 dB(A) |
| Power Supply | 100W / 120W, AC 100–240V, 50/60Hz, Power Consumption: 37.91W (Access), 12.33W (HDD Hibernation) |
| Temperature | Operating: 0°C to 40°C, Storage: -20°C to 60°C |
| Humidity | Operating: 8%–80% RH, Storage: 5%–95% RH |
| Certification | FCC, CE, BSMI, VCCI, RCM, UKCA, EAC, CCC, KC, BIS |
| Warranty | 3 Years (Extendable to 5 Years with EW201 / Extended Warranty Plus) |
| Environment | RoHS Compliant |
| DSM Storage | Max Volume: 200 TB (requires 32 GB RAM), 108 TB without. Up to 32 internal volumes. Supports Btrfs, ext4. |
| RAID Support | SHR, Basic, JBOD, RAID 0, 1, 5, 6, 10. Migration and expansion supported. |
| File Services | SMB, AFP, NFS, FTP, WebDAV, Rsync. Max 40 SMB connections. Windows ACL, NFS Kerberos supported. |
| User & Group Limits | 512 users, 128 groups, 128 shared folders, 4 sync tasks |
| Virtualization | VMware vSphere, Microsoft Hyper-V, Citrix XenServer, OpenStack |
| Surveillance Station | 2 free licenses. H.265: Up to 40x 1080p / 1200 FPS, 40x 3M / 1000 FPS, 40x 5M / 600 FPS, 30x 4K / 300 FPS |
| Applications | Synology Drive (80 users, 500k files), Synology Office (80 users), Synology Chat (150 users), Synology MailPlus (90 users) |
| VM Manager | Up to 8 VM instances, 8 Virtual DSM (1 free license) |
| VPN Server | Max 8 connections |
| Description | Downloads |
|---|---|
| Synology DiskStation DS925+ NAS/storage Server Ryzen Embedded V1500B 4 GB DDR4 DataSheet | Download |
| Synology DiskStation DS925+ NAS/storage Server Ryzen Embedded V1500B 4 GB DDR4 User Manual | Download |
| Synology DiskStation DS925+ NAS/storage Server Ryzen Embedded V1500B 4 GB DDR4 SpecSheet | Download |
