| Tool Name |
NANO80 |
| Stand Type |
No Stand, For Accessory: 1 pole (Swivel), Floor Stand |
| Front color |
Meteo Gray |
| DISPLAY |
|
| Inch |
55" |
| Resolution |
3840 x 2160 (UHD) |
| Backlight Unit Type |
EdgeNano |
| Nano |
Yes |
| Brightness |
360 |
| Dynamic Contrast Ratio (Dynamic MCI Hz) |
1000000:1 |
| Static (Panel) Contrast Ratio |
1300:1 |
| Response Time(G to G, ms) |
Typ 8ms |
| Refresh Rate |
60(50)Hz |
| Life span (hrs) |
30000 |
| VIDEO |
|
| SoC |
K7LpSoC (Marketing Name) |
| HDR HDR 10 Pro |
Yes |
| HDR HLG |
Yes |
| AUDIO |
|
| Speaker (sound output) |
10W + 10W |
| Speaker System |
2.0 ch |
| AI Sound |
Yes |
| One Touch Sound Tuning |
Yes (Ready) |
| LG Sound Sync |
Yes (Required Bluetooth) |
| BROADCASTING SYSTEM |
|
| Digital (Terrestrial, Cable, Satellite) |
DVB-T2/C/S2 |
| Analog (NTSC / SECAM / PAL) |
SECAM / PAL |
| Teletext (Auto Teletext) |
Yes |
| Global IPTV Support |
Yes |
| HOSPITALITY SOLUTION |
|
| Data Streaming (IP & RF) |
Yes |
| HCAP (GEM/HTML) ※ Service Carousel (TLL/XML) |
GEM / HTML5 |
| IP Return path |
Yes |
| Multicast / Unicast ready |
Yes / Yes |
| webRTC (Real Time Communication) |
Yes |
| Pro:Centric Cloud (version) |
Yes (1.0) |
| Pro:Centric Direct (version) |
Yes (4.5) |
| Pro:Centric Application (version) |
Yes (PCA3.8) |
| PCS500R |
Yes |
| PCS400R |
Yes |
| Quick Menu (Version) |
Yes (5.0) |
| Pro:Idiom (S/W Type) |
Yes |
| Pro:Idiom (Mobile, Lite) |
Yes |
| SMART FUNCTION |
|
| webOS version |
Yes (webOS 6.0) |
| Smart Home (Launcher Bar) |
Yes |
| Gallery Mode |
Yes |
| Quick Access |
Yes |
| Web Browser |
Yes |
| Pre-loaded App |
Yes |
| SDP Server compatibility |
Yes |
| Magic Remote Compatibility |
Yes (Ready, MR18HA) |
| SW Clock (World Clock / Alarm) |
Yes |
| Mood Display |
Yes |
| Soft AP |
Yes |
| WiFi (version) |
Yes (802.11ac) |
| Screen Share (Miracast) |
Yes |
| Smart Share |
Yes |
| LG ThinQ App |
Yes |
| DIAL |
Yes |
| Bluetooth Audio Playback |
Yes |
| Mobile Connection Overlay |
Yes |
| HDMI-ARC |
Yes (HDMI2) |
| Voice Recognition (Standalone/Solution) |
Yes |
| IoT |
Yes |
| OTHER FEATURE |
|
| EzManager |
Yes |
| USB Cloning |
Yes |
| Wake on RF |
Yes |
| WOL / WOWL |
Yes / No |
| SNMP |
Yes |
| Diagnostics |
Yes (IP Remote) |
| SI Compatible |
Yes (TV Link tuner, RS232C) |
| HTNG-CEC |
Yes (1.4) |
| Simplink(HDMI-CEC) |
Yes (1.4) |
| IR Out |
Yes (RS-232C 4pin, HDMI) |
| Multi IR Code |
Yes |
| Hotel Mode / PDM / Installer Menu |
Yes (Hotel Mode) |
| Lock mode |
Yes (Limited) |
| Port Block |
Yes |
| Welcome Video |
Yes |
| Welcome Screen (Splash Image) |
Yes |
| Insert Image |
Yes |
| One Channel Map |
Yes |
| IP Channel Manager |
Yes |
| External Speaker Out |
Yes |
| Instant ON |
Yes |
| V-Lan Tag |
Yes |
| RJP (remote jack pack) Compatibility |
Yes |
| LG/Teleadapt (RS232C), Teleadapt/Guestlink (HDMI CEC) |
Yes |
| Mobile Remote |
Yes |
| Moving Picture Playback (SD/HD/Plus HD) |
Yes |
| Auto Off / Sleep Timer |
Yes / Yes |
| Energy Saving mode |
Yes |
| Motion Eye Care |
Yes |
| Conformal Coating |
Yes |
| VERTICAL FUNCTION |
|
| Healthcare Headphone Mode |
Yes |
| Hybrid Caption (Closed Caption Digital Only) |
Yes |
| RTC (Real Time Clock) |
Yes |
| NTP sync timer |
Yes (Clock Setup NTP) |
| BEACON |
Yes |
| Video Tag |
Yes (2 supported) |
| JACK INTERFACE |
|
| HDMI In |
2 (2.0) |
| USB |
2 (2.0) |
| Headphone Out |
1 |
| RS-232C(D-Sub 9pin / Phone jack) |
1 (Phone Jack, 4pin) |
| CI Slot |
1 (CI+ 1.4 ECP) |
| RF In |
2 |
| Digital Audio Out (Optical) |
1 |
| External Speaker Out (3.5mm phone jack) |
|
| Audio Line Out (3.5mm phone jack) |
2 (Spk-out 1 (Stereo, Max 2W with 8Ω), Vol. Control 1) |
| RJ45 (Usage Purpose) |
2 (Ethernet, Aux) |
| ETC |
|
| VESA Compatible |
Yes |
| 300x300 |
|
| Kensington Lock |
Yes |
| Credenza/Security Screw Hole |
Yes |
| *This feature supported after purchasing StandLock Down Plate (for easy installing) |
Yes |
| *This feature supported after purchasing Stand |
Yes |
| MECHANIC |
|
| Weight without Stand |
16.3 |
| Weight in Shipping |
20.9 |
| Size without Stand |
1,233 x 716 x 44.2 |
| Size in Shipping |
1,360 x 810 x 152 |
| Bezel Width (L/R/U/B): On Bezel |
11.8/11.8/11.8/18.3 |
| Bezel Width (L/R/U/B): Off Bezel |
5.8/5.8/5.8/14.9 |
| POWER |
|
| Power Supply (Voltage, Hz) |
AC 100 ~ 240V, 50/60Hz |
| Power Consumption(Max) |
177 W |
| Power Consumption(Typ) |
155 W |
| Standby Power Consumption |
0.5 W |
| REQUIRED LISTING(CERTIFICATION) |
|
| Safety |
CB, CU |
| TREMC |
CE |
| Old Label (~2021.3) - ErP Class |
A++ |
| Old Label (~2021.3) - On Power Consumption |
70 W |
| Old Label (~2021.3) - Luminance Ratio (%) |
65% |
| Old Label (~2021.3) - Average Annual Consumption (kWh) |
97.1 kWh |
| New Label (2021.3~) - SDR Grade |
G |
| New Label (2021.3~) - SDR On mode |
84 W |
| New Label (2021.3~) - HDR Grade |
G |
| New Label (2021.3~) - HDR On mode |
128 W |
| ACCESSORY |
|
| Remote type |
S-Con / MMR (Option) |
| Chromecast Dongle Anti-theft Cover |
Yes (option) |
| Power Cable |
Yes (1.5M / Straight) |
