Design |
Tool Name: UR90 |
|
Front Color: Dark Iron Gray |
|
Stand Type: 1 pole (Fixed) |
Display |
Inch: 65" |
|
Resolution: 3,840 x 2,160 (4K UHD) |
|
Brightness: 380 nit |
Video |
AI Picture Pro: Yes |
|
HDR 10 Pro / HDR HLG: Yes / Yes |
|
Game Optimizer: Yes |
Audio |
Audio Output: 20 W |
|
AI Sound: Yes |
|
AI Acoustic Tuning: Yes (Ready, MMR Required) |
|
LG Sound Sync: Yes |
Broadcasting System |
Digital: DVB-T2/C |
|
Analog (NTSC / SECAM / PAL): PAL |
|
Teletext (Auto Teletext): Yes |
Hospitality Solution |
Solution Type: Pro:Centric (Smart, Cloud, Direct, V) |
|
Quick Menu: Yes |
|
Pro:Idiom (DRM / Media): Yes / Yes |
Smart Feature |
webOS23, Web Browser, Magic Remote Compatibility (Ready) |
|
Multi View, AOD, Mood Display, Gallery Mode |
|
Wi-Fi, Bluetooth, SoftAP, Screen Share |
|
DIAL, Bluetooth Audio Playback, HDMI-ARC (HDMI 2) |
|
Voice Recognition (Standalone/Solution), IoT |
|
Anti-theft System: Kensington Lock, Credenza/Security Screw Hole, Lock Down Plate |
Hospitality Feature |
EzManager, USB Cloning, Wake on RF, WOL |
|
SNMP, Diagnostics (IP Remote), HTNG-CEC, Simplink |
|
IR Out, Multi IR Code, Hotel Mode, PDM, Installer Menu |
|
Welcome Video, Welcome Screen, Insert Image |
|
One Channel Map, External Speaker Out, USB Auto Playback |
|
Instant ON, V-Lan Tag, Mobile Remote, Port Block |
|
Lock Mode, RJP Compatibility, Conformal Coating |
|
Energy Saving Mode, Healthcare Headphone Mode |
|
RTC, NTP Sync Timer, BEACON, Video Tag |
Dimension |
VESA Compatible: 300 × 300 mm |
|
W × H × D / Weight (without Stand): 1,456 × 840 × 29.7 mm / 23.6 kg |
|
W × H × D / Weight (with Stand): 1,456 × 909/869 × 285 mm / 27.4 kg |
|
W × H × D / Weight (Shipping): 1,600 × 970 × 203 mm / 34.7 kg |
|
On Bezel Width (L/R/U/B): 13.5 / 13.5 / 13.5 / 17.4 mm |
|
Off Bezel Width (L/R/U/B): 7.5 / 7.5 / 7.5 / 14.8 mm |
Power |
Power Supply (Voltage, Hz): AC 100-240 V, 50-60 Hz |
|
Power Consumption (Typ. / Max.): TBD / TBD |
|
Standby Power Consumption: Under 0.5 W |
Connectivity |
HDMI In (3), USB 2.0, RF In, AV In |
|
Digital Audio Out (Optical), External Speaker Out (3.5 mm Phone Jack) |
|
Headphone Out, RJ45 (Usage Purpose) (2, Ethernet, Aux) |
|
RS-232C (Phone Jack) |
Accessory |
Remote Type: S-Con / MMR (Option) |
|
Power Cable: TBD |
Required Listing |
Safety: CB |
|
EMC: CE |
