Yealink MD86 MeetingDisplay 86" 4K Ultra HD For MTR System (MTR Display)
SKU: MD86
£1,462.78 (Excl. VAT)
- Display Size86"
- Operating SystemAndroid 13
- VESA Patterns600x400
- Panel TypeIPS Panel
- ResolutionUltra HD (4K)
- Screen TypeFlat
- Description
- Specifications
- Downloads
-
Brilliant 86” 4K Ultra HD Display with Anti-Glare Coating
INSTALL LIKE A BREEZE
The customized installation structure* makes installation easy, without the trou-
ble of wall drilling. Just screw and hang, the meetingbar and display are ready!ONE WAY AS ALL COORDINATION
Integrated with Yealink MeetingDisplay, Yealink unified solution supports automatic switching to current input source
(regardless of which source you are on, when a Teams call comes in, it will automatically switch to Teams),
as well as sleep and wake-up functionality.
Enjoy smooth and seamless meeting device coordination.ONE TOUCH CONSOLE,
GET TO THE HEART OF CONFIGURATION FAST.
One touch console is enough. Configure MTR devices and MeetingDisplay easily,
without TV remote control. Effortlessly switch signal inputs and adjust Meeting-
Display’s brightness, contrast, volume, etc.MANAGEMENT OVER THE AIR
With Yealink Management Cloud Service (YMCS), you can manage both MeetingDisplay
and MTR devices from a single platform — no need to switch between systems.
CONNECT. SHARE. ENGAGE.
The MeetingDisplay features a Dual-Ethernet design, with one port capable of providing network connectivity for MTR devices—solving the issue of limited Ethernet availability. It also supports seamless wireless content sharing via presentation pod, enabling effortless local collaboration. Additionally, near-zero latency HDMI-in ensures smooth, lag-free communication.
-
Screen Size 86" Display Type IPS Surface Treatment Anti-glare Coating Refresh Rate 60Hz Response Time 8ms (Grayscale) Color Gamut 72% NTSC Colour Depth 1.07B (10bit) Viewing Angle 178°(H)/178°(V) Contrast Ratio 1200:1 Resolution 3840 x 2160 (4K UHD) Brightness 500 cd/m² Haze 25% Operation Time 7*18h Speaker 12W x 2 Wired Sharing HDMI In Wireless Sharing AirPlay, Miracast, Wireless Pod* Video Inputs HDMI In 2.0 x 3 Audio Out 3.5mm Stereo Mini Jack USB Ports USB-A 2.0 x 2, USB-B 2.0 x 1 LAN 2x RJ45 (10/100/1000M) Control RS232, IP Control Reset Yes Wi-Fi Wi-Fi 6, Dual-band Bluetooth 5.1 IR Supported Installation Wall / Floor Stand Operating System Android 13 Memory / Storage 4GB / 32GB Power Supply 100-240V~ 50/60Hz Power (86") Max: 323W, Typ: 268W Operating Temp. 0~40°C Storage Temp. -20~60°C Humidity 10~95% Warranty 3 Years -
Description Downloads Datasheet Download
