Vivolink HDMI 2.0 4x4 Matrix Switcher | VLHDMIMAT4X4

SKU: VLHDMIMAT4X4
Vivolink HDMI 2.0 4x4 Matrix Switcher | VLHDMIMAT4X4 Matrix Switcher Vivolink
Availability:
Only 3 left at this price!
Save £432.81 Save £432.81

£605.44 (Excl. VAT)

- £726.53 (Inc. VAT)
£605.44 - £605.44
- - £726.53
Availability:
Only 3 left at this price!
  • Visa
  • Mastercard
  • American Express
  • Apple Pay
  • Google Pay
  • Paypal
  • Shop Pay
  • Klarna
  • Bank Transfer (BACS)
Download Product Datasheet i
Trade pricing for verified resellers, proforma issued on official company letterhead for PO processing.
Education & Public Sector Pricing available for schools, universities, NHS, and government organisations. Contact our Public Sector Team on 020 8191 9223 or email info@screenmoove.com.
  • Description
  • Specifications
  • Downloads

  • Vivolink HDMI 2.0 4x4 Matrix Switcher | VLHDMIMAT4X4


    HDMI 2.0 4x4, Matrix switcher w/GUI and RS232 control
    HDCP2.2, audio de-embedder HD Audio support, build-in GUI + LAN control

    Typical installations:
    Professional signal distribution with selectable in and outputs

    Function:
    4 HDMI inputs
    4 HDMI outputs + Audio SPDIF (coax)
    Control: IR + RS232 + TCP/IP

    Smart EDID management, automatically adopt the resolution of the first detected display from port 1 or 2

    Intuitive indicator for connection status & input HDCP compliance status

    HDMI 2.0 matrix HDCP 2.2

    Support 18Gbps bandwidth for 4K@60Hz 4:4:4 8bit

    Deep color formats and HDR capability

    HD Audio support up to DTS:X and Dolby Atmos

    Build-in GUI for matrix set-up and control over LAN

    Smart EDID management, automatically adopt the resolution of the first detected display from port 1 or 2

    Intuitive indicator for connection status& input HDCP compliance status

  • Category Detail
    Features
    Audio formats supported PCM
    Audio output channels 2.0 channels
    Bandwidth 18 Gbit/s
    Consumer Electronics Control (CEC) support Yes
    Extended display identification data (EDID) Yes
    HD type 4K Ultra HD
    HDCP Yes
    HDCP version 2.2
    LED indicators Yes
    Maximum frame rate 60 fps
    Maximum resolution 3840 x 2160 Pixels
    Plug and Play Yes
    Product colour Black
    Rack mounting Yes
    Remote control type IR + RS232
    Legal Information
    EU ECCN Code N/A
    US ECCN Code 5A992
    Operational conditions
    Operating temperature (T-T) -5 - 55 °C
    Package dimensions (verified)
    Depth Verified 54 cm
    Gross Weight Verified 3.1 kg
    Height Verified 14 cm
    Width Verified 35 cm
    Packaging content
    AC adapter included Yes
    Cables included IR sensor
    Mounting brackets included Yes
    Remote control included Yes
    Ports & interfaces
    Audio (L/R) out 1
    Digital audio coaxial out 1
    HDMI in 4
    HDMI ports quantity 8
    HDMI version 2.0
    Number of HDMI outputs 4
    RJ-45 input ports 1
    RS-232 ports 1
    S/PDIF out port Yes
    Power
    AC input voltage 100 - 240 V
    Product dimensions
    Net Weight (Product, kg) 0.5 kg
    Product Depth 54 cm
    Product Height 14 cm
    Product Width 35 cm
    Technical details
    Audio support Yes
    Vendor information
    Brand Name Vivolink
    Warranty 3 Year(s)
  • VLHDMIMAT4X4 : Product Sheet
