Philips EcoDesing 55" 4K Ultra HD Digital Signage Display | 55BDL3650QE/00
SKU: 55BDL3650QE/00
£947.95 (Excl. VAT)
- Display Size55"
- Operating SystemAndroid 10
- VESA Patterns400x400
- Panel TypeIPS Panel
- ResolutionUltra HD (4K)
- Screen TypeFlat
Book a Free Product Demo
Remote or on-site. No obligation.
Integrator or Installer?
Trade pricing, volume discounts, same-day collection.
Education & Public Sector Solutions
Exclusive pricing, flexible terms, and dedicated support for schools, universities, NHS, and government organisations.
- Description
- Specifications
- Downloads
-
Philips EcoDesing 55" 4K Ultra HD Digital Signage Display | 55BDL3650QE/00
100% recycled and recyclable packaging
Designed with manufacturing processes, physical features, materials, packaging and built-in software that are kinder to the environment and deliver better energy efficiency, the Philips Signage 3650 EcoDesign display is designed to operate using less than half the power of its counterparts, while still delivering the same unrivalled performance.Android SoC processor. Native and web apps
Powered by our Android 10 SoC platform, these hard-working displays are optimised for native Android apps, and you can install web apps directly onto the display too. Flexible and secure, ensuring that display specs stay up to the moment for longer.
Connect and control your content via the cloud
Connect and control your content via the cloud with the integrated HTML5 browser. Using the Chromium-based browser, design your content online and connect a single display or your complete network. Show content in both landscape and portrait mode, with full HD resolution. Simply connect the display to the Internet using the optional CRD22 Wi-Fi module or via LAN, and enjoy your own created playlists.EPEAT Silver Climate+ certified
Recognised by and registered with EPEAT with a Silver Climate+ Ecolabel, the Philips Signage 3650 EcoDesign meets the robust set of criteria laid out by the world's premier ecolabel for electronics.FailOver. Ensure that content is always running
Critical for demanding commercial applications, FailOver is a revolutionary technology that automatically plays back-up content onscreen in the unlikely event of an input source or application failure. Simply select a primary input connection and a FailOver connection and you are ready for instant content protection.
Optional Interact for wireless screen share
Wirelessly screen-share using your existing Wi-Fi network to instantly and securely connect devices, or use our optional HDMI Interact dongle to cast directly onto the screen without connecting to the secured network.PPDS Wave ready for remote management
Unlock the power, versatility and intelligence inside your Philips Signage 3650 EcoDesign displays remotely with Wave. This evolutionary cloud platform puts you fully in control, with simplified installation and setup, monitoring and controlling displays, upgrading firmware, managing playlists and setting power schedules — saving you time, energy and environmental impact.Wi-Fi and Bluetooth 5.2 via optional module
Easily schedule content to play from a USB or from internal memory. Your Philips Professional Display will wake from standby to play the content you want, and then return to standby once playback is done. -
Diagonal screen size (metric) 138.7 cm Diagonal screen size (inch) 54.6 inch Aspect ratio 16:9 Panel resolution 3840 x 2160 Pixel pitch 0.315 x 0.315 mm Optimum resolution 3840 x 2160 @ 60 Hz Brightness 350 cd/m² Display colours 1.06 Billion Contrast ratio (typical) 1200:1 Dynamic contrast ratio 500,000:1 Response time (typical) 8 ms Viewing angle (horizontal) 178 degree Viewing angle (vertical) 178 degree Picture enhancement 3/2 - 2/2 motion pull down Dynamic contrast enhancement Motion compens. deinterlacing Panel technology IPS Operating system Android 10 Audio output 3.5 mm jack Video input DVI-I (x 1), HDMI 2.0 (x 2) USB ports USB 2.0 (x 2), USB 3.0 (x 2) Audio input 3.5 mm jack Other connections micro SD External control RJ45, RS232C (in/out) 2.5 mm jack, IR (in/out) 3.5 mm jack Optional WiFi CRD22 Wi-Fi dongle Placement Landscape/Portrait (18/7) Tiled Matrix Up to 15 x 15 Keyboard control Lockable, Hidden Remote control signal Lockable Signal loop through RS232 IR Loop through Yes Energy-saving functions Smart Power Network controllable RS232, RJ45 Built-in speakers 2 x 10 W RMS Mains power 100 ~ 240 VAC Consumption (Typical) 70 W Consumption (Max) 120 W Standby power <0.5 W Power Saving Features Smart Power Energy Label Class D Set Width 1241.8 mm Set Height 712.6 mm Set Depth 63.6 mm Set Width (inch) 48.89 inch Set Height (inch) 28.06 inch Set Depth (inch) 2.50 inch Bezel width 13.9 mm (Even bezel) Product weight 17.2 kg Product weight (lb) 37.92 lb Wall Mount 400 mm x 400 mm, M6 Altitude 0 ~ 3000 m Temperature (operation) 0 ~ 40 °C MTBF 30,000 hour(s) Temperature (storage) -20 ~ 60 °C Humidity (operation) 20~80% RH (No condensation) Humidity (storage) 5~95% RH (No condensation) USB Playback Video H.264, H.263, H.265, MPEG1/2, MPEG4, VP8, VP9 USB Playback Picture JPEG, BMP, PNG USB Playback Audio AAC, HEAAC, MPEG CPU Dual-core Cortex A53 1.1 GHz, Dual-core Cortex A73 1.15 GHz, Quad-Core Cortex A55 GPU G52 MC1 Memory 16 GB, 3 GB DDR Included Accessories IR sensor cable, RS232 daisy-chain cable, Philips logo, AC Power Cord, AC Switch Cover, Cable clips (x2), Quick start guide, RS232 cable, USB Cover On-Screen Display Languages English, French, German, Italian, Polish, Turkish, Russian, Simplified Chinese, Spanish, Traditional Chinese, Arabic, Japanese Warranty 3 year warranty Regulatory approvals CE, CB, BSMI, FCC Class A, VCCI, J-Moss, ETL, RoHS -
Description Downloads Leaflet Downloads Mechanical Drawing Downloads Manual Downloads
