BOSE DesignMax DM6SE 125W RMS Loudspeakers (1 pair)
SKU: 829682-0120
£641.03 (Excl. VAT)
- Description
- Specifications
- Downloads
-
Bose DesignMax DM6SE Outdoor Loudspeakers – 6.5" Coaxial, 125W RMS, IP55 Weatherproof, Surface-Mount (Pair)
With coaxial two-way drivers, the 125-watt Bose Professional DesignMax DM6SE loudspeaker offers rich lows and clear, intelligible highs — along with premium aesthetics that complement any commercial sound installation. The DM6SE features a 6.5-inch woofer and a 1.25-inch coaxial tweeter mounted within the Dispersion Alignment system, delivering a frequency range of 59 Hz – 20 kHz. The DM6SE is surface-mounted, IP55 outdoor-rated, and locks onto a hidden QuickHold U-bracket for fast, secure installation.
FEATURES
Combine DesignMax models to complete any design, big or small — 12 loudspeakers to mix and match, from 2-inch, low-profile models to 8-inch, high-SPL compression-driver loudspeakers and outdoor-rated options
Deliver rich lows and clear, intelligible highs with coaxial two-way drivers — no DSP or EQ required. For even better sound, use select Bose Professional DSPs and amplifiers to enable Bose Professional loudspeaker EQ and SmartBass processing, which expands performance and response at any listening level
Ensure a consistent listening experience throughout the room with the Dispersion Alignment system, which matches the acoustic pattern of the woofer to the pattern of the tweeter
Blend with any room design with elegant form factors, minimum-bezel grilles available in black or white, and removable logos
Reduce installation time with the patented QuickHold mounting system, which also reduces strain, hassle, and the chance of product damage
Install easily with industry-standard accessories — all models include Euroblock connectors; in-ceiling models include plenum-rated backcans, tile bridges, and front-access audio wiring that makes installation and troubleshooting easier
Install DM6SE outside — IP55 rating with standard aluminum grille for outdoor use
Applications
Designed for a wide range of applications, including:
Performing arts venues
Places of worship
Conference centers
Retail stores
Restaurants and bars
Hospitality venues -
Category Attribute Value COMPLIANCE Safety Ratings UL 1480A, NFPA 70, CE-compliant PHYSICAL Colors Black (RAL 9005), White (RAL 9003), Paintable Enclosure Material UV-resistant engineered plastics Environmental Outdoor, IP55, wet-location ready Grille Perforated aluminum, tamper-resistant, powder-coated Ingress Protection IP55 Logo Rotatable, removable Operating Temp -25 °C to 70 °C (-13 °F to 158 °F) Dimensions (H×W×D) 13.4 × 8.7 × 9.0 in (340 × 222 × 229 mm) With Bracket (H×W×D) 13.4 × 8.7 × 9.7 in (340 × 222 × 245 mm) Net Weight 13.1 lb (5.9 kg) Shipping Weight 32.5 lb (14.7 kg), pair PERFORMANCE Frequency Range (-10 dB) 59 Hz – 20,000 Hz Coverage (H × V) 125° conical Max SPL @ 1 m 111 dB Nominal Impedance 8 Ω (bypass) Power Handling (Cont./Peak) 125 W / 500 W Sensitivity (1W @ 1m) 90 dB Signal Processing Optional Bose EQ & SmartBass Transformer Taps (100V) 5, 10, 20, 40, 80 W, bypass Transformer Taps (70V) 2.5, 5, 10, 20, 40, 80 W, bypass TRANSDUCERS Crossover 1.7 kHz passive 2-way Driver Protection 60 Hz high-pass, 24 dB/oct HF Driver 1.25" Neodymium tweeter, coaxial, weather-treated LF Driver 6.5" Weather-treated woofer PRODUCT CODES 829682-0110 DM6SE PAIR BLACK 829682-0210 DM6SE PAIR WHITE 829682-0120 DM6SE PAIR BLACK (NEW) 829682-0220 DM6SE PAIR WHITE (NEW) INCLUDED ITEMS (1) Powder-coated steel U-bracket -
Description Downloads BOSE DesignMax DM6SE Loudspeakers (1 pair) DataSheet Downloads BOSE DesignMax DM6SE Loudspeakers (1 pair) Painting Guide Downloads
