ProDVX IPPC-22-6000 22" Full HD Intel Pentium N4200 Touch Display
SKU: IPPC-22-6000
£1,092.75 (Excl. VAT)
- Display Size22"
- Operating SystemWindows 10
- VESA Patterns100x100
- Panel TypeIPS Panel
- ResolutionFull HD (1080p)
- Screen Ratio16:9
- Description
- Specifications
- Downloads
-
ProDVX IPPC-22-6000 22" Full HD Intel Pentium N4200 Touch Display
The ProDVX IPPC-22-6000 is an Intel Panel PC with a 21.5" Touch Display. The ProDVX IPPC-22-6000 standard comes with an Intel Pentium N4200 1.1 GHz. This device can be connected through RJ45 LAN, WiFi, Bluetooth and is fanless due to passive cooling. This Intel SOC Touch Display has a projected capacitive touch display in plastic housing. Optional accessories for the Pogo Pins are a 1D/2D Barcode Scanner, NFC Module or VESA brackets. This product requires an additional Windows 10 IoT Enterprise LTSC license.
-
Category Specification Panel Panel Type TFT LCD IPS Resolution 1920 x 1080 Aspect Ratio 16:9 wide Backlight Edge-LED backlight Brightness 250 cd/m² Viewing Angle H178° / V178° Contrast Ratio 3000:1 Touch Type 10 TP P-Cap, 20 ms Surface Treatment Glare Display Modes Landscape, Portrait, Table Mode Gyroscope N/A Operation Hours 24/7 System Chipset Intel HD505 CPU Intel Pentium N4200 1.1 GHz GPU Intel HD 505 Graphics Cooling Fanless System Memory 4GB DDR3L Internal Storage 64GB SSD (M.2 2242) External Storage SD Card Slot (door) Storage Socket 2 SD Card Slot (door) OS Windows 10 IoT LTSC Windows License Yes, additional cost Video Input N/A Video Output Yes, mini-HDMI out LED Light Bar N/A Connectivity & I/O Power Input 12V DC-IN COM Ports 2x COM (RJ45) USB Ports 2x USB 3.0, 1x Micro-USB Audio I/O Combo Jack, S/PDIF Network 1x Ethernet RJ45 (10/100/1000 Mbps) WiFi 802.11 a/b/g/n/ac Bluetooth Bluetooth 4.2 Power over Ethernet N/A Integrated NFC via PoGo & USB Camera via PoGo & USB Multimedia Video Support MKV, MP4 Audio Support MP3, WMA Photo Support JPEG, PNG Microphone Yes Speakers 2 x 3 W Physical Housing ABS+PC (Macrolon) Color Black Weight 4200 g Dimensions (mm) 530.5 x 321.22 x 35 mm Mounting VESA 100 Power Supply 12V / 5A (Included) Power Usage 40 ~ 70 Watt Pogo Pins 3x (bottom, left, right) Environmental Storage Temp -10 ~ 55°C Working Temp 0 ~ 40°C Humidity 10 ~ 90% non-condensing MTBF 50,000 hours demonstrated Clock Battery CR2032 Lithium (non-rechargeable) Miscellaneous OSD Language Multi-language Warranty 3 years Certifications CE, RoHS, REACH SKU 6022100 -
Description Downloads Datasheet Downloads User Guide Downloads Drawing Downloads
