Lindy 4x4 HDMI 4K60 Matrix | 38152
Matrices are multi-port solutions for distributing content from multiple sources to several displays in a variety of configurations.
The Lindy 4x4 HDMI® 4K 60 Matrix is an effective solution for distributing 4K content from up to 4 HDMI® source devices, including PCs and media players, to 4 displays.
Supporting 4K@60Hz resolutions, content can be viewed in excellent quality - great for use with digital signage in retail, information display setups in educational buildings or engaging conference installations.
The matrix can be easily controlled with a variety of simple, effective options including push buttons on the main unit, IR or via RS-232 for integration into professional control systems.
The terms HDMI, HDMI High-Definition Multimedia Interface, HDMI Trade dress and the HDMI Logos are trademarks or registered trademarks of HDMI Licensing Administrator, Inc.
-
AV Interface HDMI® Interface Standard HDMI® 2.0 Supports Bandwidth 18 Gbps Max Resolution 4096x2160@60Hz 4:4:4 8bit with HDR HDCP Support 2.2 Supported Audio Audio Pass-through, Dolby Atmos IR Support 30-60kHz CEC Support - Serial Interface - LED / LCD Display - Control IR, Push Button Special Features EDID Management Input 4 x HDMI® (Female) Output 4 x HDMI® (Female) Control Port USB Micro-B (Female) Power Connector 5.5/2.1mm DC socket Dimensions (WxHxD) 220x105x19mm (8.66x4.13x0.75in) Housing Material Metal Nett Weight 0.535kg (1.81lb) Operating Temp 0°C - 40°C (32°F - 104°F) Storage Temp -20°C - 60°C (-4°F - 140°F) Humidity 20 - 90% (non-condensing) Power Requirement 12VDC 2.5A Colour Black Packaging Type Carton box Packaging Dimensions 301x61x235mm (11.85x2.4x9.25in) Gross Weight 1.35kg (2.98lb) Warranty (Years) 2 Product Compliance CE, FCC, RoHS, REACH, California Proposition 65 Package Contents HDMI® Matrix, IR Remote, Multi-Country PSU (EU, UK, US & AUS), Lindy Manual No. 38152 EAN 4002888381529 -
Description Downloads Manual Downloads
