Kramer VS-211H2 HDMI 2x1 Switcher | 17.8Gbps | Auto/Manual Switching
SKU: VS-211H2
£232.65 (Excl. VAT)
- Description
- Specifications
- Downloads
-
Kramer VS-211H2 HDMI 2x1 Switcher | 17.8Gbps | Auto/Manual Switching
VS−211H2 is a high−performance auto switcher for 4K@60Hz (4:4:4) HDMI video signals. Offering priority and last−connected auto switching scheme options, it automatically switches input signals to output connection, according to the selected switching scheme, and based on active video signals detection.
HDMI Signal Switching — HDR and HDCP 2.2 compliant, it supports deep color, x.v.Color™, lip sync, HDMI uncompressed audio channels, Dolby TrueHD, DTS–HD, 2K, 4K, and 3D as specified in HDMI 2.0.
Multi–channel Audio Switching — Up to 32 channels of digital stereo uncompressed signals for supporting studio–grade surround sound.
I–EDIDPro™ Kramer Intelligent EDID Processing™ — Intelligent EDID handling, processing, locking and pass–through algorithm ensures Plug and Play operation for HDMI source and display systems.
Cost–Effective Maintenance — Status LED indicators for HDMI ports facilitate easy local troubleshooting.
Easy Installation — Compact DigiTOOLS® fan–less enclosure fits for convenient under tables or dropped–ceiling mounting, or side–by–side mounting of 3 units in a 1U rack space with the recommended rack adapter.Applications
Basic hi–quality auto switcher for any AV distribution solutions
Standard small–medium meeting -
Category Attribute Value Inputs HDMI Inputs 2 x HDMI (female) Outputs HDMI Output 1 x HDMI (female) Ports Contact-Closure Switches 2 (3-pin terminal block) Video Max Data Rate 17.82Gbps (5.94Gbps/channel) Max Resolution 4K@60Hz (4:4:4) HDMI Features Deep Color, x.v.Color™, Lip Sync, 3D Audio Support Dolby TrueHD, DTS-HD, uncompressed audio HDMI Standard HDMI 2.0, HDR10, HDCP 2.2 Controls Interface DIP-switches, contact closure Regulatory Certifications EMC, IEC 60950–1 ed.2 & amendments Environment Operating Temp 0° to +40°C (32° to 104°F) Storage Temp –40° to +70°C (–40° to 158°F) Humidity 10% to 90% RH, non-condensing Power Consumption 5V DC, 560mA Accessories Included Power adapter Dimensions Product Size (W x D x H) 12 x 7.15 x 2.44 cm (4.72" x 2.81" x 0.96") Weight 0.2 kg (0.3 lbs) approx. Shipping Size 15.7 x 12 x 8.7 cm Shipping Weight 0.6 kg (1.4 lbs) approx. -
Description Downloads Kramer VS-211H2 HDMI 2x1 Switcher | 17.8Gbps | Auto/Manual Switching DataSheet Downloads
