5,500 Lumens Brightness
See crystal-clear, vibrant images from a distance in lecture halls, auditoriums or any large venues with up to 5,500 lumens of brightness.
FHD Resolution
A 100” image of pure beauty in 1080p Full HD looks so real, you’ll swear you’re looking out the window.
Acer ColorBoost3D™
Reproduce lifelike colors and brilliantly bright images with Acer ColorBoost3D™ technology.
Acer LumiSense+™
Project in any environment without loss of detail as Acer LumiSense+™ adjusts brightness and color saturation based on content and ambient light.
Integrated Crestron® Network System
Control, maintain and monitor your device anywhere with an internet connection using Crestron® control systems.
Acer ColorSafe II
Enjoy consistent, natural colors with ColorSafe II technology, which controls the dynamic RGB levels to prevent color decay.
4 Corner Correction
Quickly and easily adjust distortion in each individual corner with 4 Corner Correction.
DLP 3D Ready[1]
DLP 3D ready enables users to view 120Hz 3D frame sequential (progressive) content from a PC with an appropriate 120Hz graphics card and 3D stereoscopic player or Blu-ray Disc title from a Blu-ray player by wearing DLP 3D glasses.
Keystone Correction for Distortion
Finding the right angle for your presentation is easier with keystone correction, which corrects horizontal and vertical distortion.
| Image | |
|---|---|
| Native Resolution | 1920 x 1080 |
| Maximum Resolution | 1920 x 1200 |
| Standard Mode Brightness | 5500 lm |
| Native Aspect Ratio | 16:9 |
| Compatible Aspect Ratio | 4:3 |
| Contrast Ratio | 20,000:1 |
| Throw Ratio | 1.41 to 2.24 |
| Digital Zoom | 2x |
| Vertical Keystone Correction | -30°/+30° |
| Horizontal Keystone Correction | -30°/+30° |
| Maximum Vertical Sync | 120 Hz |
| Maximum Horizontal Sync | 100 kHz |
| Minimum Vertical Sync | 24 Hz |
| Minimum Horizontal Sync | 15 kHz |
| Color Supported | 1.07 Billion Colors |
| Lamp | |
|---|---|
| Number of Lamps | 1 |
| Lamp Power | 365 W |
| Interfaces/Ports | |
|---|---|
| Number of USB Ports | 1 |
| USB | Yes |
| Composite Video | Yes |
| Component Video | Yes |
| Network (RJ-45) | Yes |
| Number of S-Video Ports | 1 |
| S-Video | Yes |
| Number of VGA Inputs | 2 |
| VGA In | Yes |
| Number of VGA Outputs | 1 |
| VGA Out | Yes |
| Number Of Audio Inputs | 1 |
| Number Of Audio Outputs | 1 |
| Audio Line In | Yes |
| Audio Line Out | Yes |
| Technical Information | |
|---|---|
| Projection System | DLP |
| Projection Method | Front Rear Ceiling Rear Ceiling |
| Video Compatibility | NTSC PAL SECAM HDTV EDTV SDTV |
| Computer Compatibility | Windows PC Mac PC Google Chrome PC |
| Audio | |
|---|---|
| Number of Speakers | 2 |
| Speaker Output Power | 10 W |
| Speaker Output Mode | Stereo |
| Network & Communication | |
|---|---|
| Ethernet (LAN) Capability | Crestron eControl |
| Power Description | |
|---|---|
| Input Voltage | 120 V AC 230 V AC |
| Operating Power Consumption | 460 W |
| Standby Power Consumption | 500 mW |
| Physical Characteristics | |
|---|---|
| Installation | Ceiling Mount |
| Weight (Approximate) | 4.50 kg |
| Form Factor | Ceiling Mountable |
| Miscellaneous | |
|---|---|
| Optional Accessories | Lamp (MC.JMG11.004) |
| Standard Accessories | AC Power Cord Battery for remote control Duster Filter Lens Cap Quick Start Guide Remote Control Security Card VGA Cable Carrying Case Dust Filter |
