| Category | Details |
|---|---|
| Output | |
| Max Configurable Power (Watts) | 865 Watts / 1.5kVA |
| Output Frequency (sync to mains) | 50/60 Hz +/- 1 Hz Unsynchronised, 50/60 Hz +/- 3 Hz Sync to mains |
| Topology | Line interactive |
| Waveform type | Stepped approximation to a sinewave |
| Transfer Time | 10 ms typical : 12 ms maximum |
| Input | |
| Input frequency | 50/60 Hz +/- 3 Hz Auto-sensing |
| Input voltage range for main operations | 156 - 300 Adjustable, 176 - 294V |
| Number of Power Cords | 1 |
| Batteries & Runtime | |
| Battery type | Lead-acid battery |
| Typical recharge time | 8 hours |
| Nominal Battery Voltage | 24 V |
| Replacement Battery | APCRBC124 |
| Expected Battery Life (years) | 3 - 5 |
| RBC Quantity | 1 |
| Battery Charge Power (Watts) | 23 Watts |
| Runtime | View Runtime Graph |
| Efficiency | View Efficiency Graph |
| Communications & Management | |
| Interface Port(s) | Optional Simple Signalling RS232 cable, USB |
| Control panel | Multifunction LCD status and control console |
| Surge Protection and Filtering | |
| Surge energy rating | 441 Joules |
| Physical | |
| Maximum Height | 301 mm, 30.1 cm |
| Maximum Width | 112 mm, 11.2 cm |
| Maximum Depth | 380 mm, 38.0 cm |
| Net Weight | 12.8 kg |
| Shipping weight | 13.9 kg |
| Shipping Height | 387 mm, 38.7 cm |
| Shipping Width | 238 mm, 23.8 cm |
| Shipping Depth | 488 mm, 48.8 cm |
| Master Carton Dimensions | 1200 x 800 x 800 mm |
| Master Carton Units | 26.0 |
| Master Carton Weight | 380.0 kg |
| SCC Codes | 10731304268731 |
| Environmental | |
| Operating Temperature | 0 - 40 °C |
| Operating Relative Humidity | 0 - 95 % |
| Operating Elevation | 0 - 3048 meters |
| Storage Temperature | -15 - 45 °C |
| Storage Relative Humidity | 0 - 95 % |
| Storage Elevation | 0 - 15240 meters |
| Audible noise at 1 meter from unit | 45.0 dBA |
| Conformance | |
| Approvals | CE |
| Equipment protection policy | Lifetime : 150000 euros |
| Standard warranty | 2 years repair or replace, 3 years repair or replace for European Union countries |
