Run time for load |
1000 W |
|
Min-max: 100-1000 W |
|
6min 30s |
Max. Capacity Used |
100 % |
Main Input Voltage |
230 V |
Other Input Voltage |
220 V |
|
240 V |
Main Output Voltage |
230 V |
Other Output Voltage |
220 V |
|
240 V |
Rated power in W |
1000 W |
Rated power in VA |
1500 VA |
Input Connection Type |
IEC 320 C14 |
Output Connection Type |
8 IEC 320 C13 |
|
2 IEC Jumpers |
Cable Length |
1.83 m |
Number of Cables |
1 |
Battery Type |
Lead-acid battery |
Provided Equipment |
Installation guide |
|
USB cable |
Complementary |
|
Software Package |
SmartConnect software for remote power monitoring feature availability varies by terms of use |
Batteries & Runtime |
|
Run Time |
View Runtime Graph |
Efficiency |
View Efficiency Graph |
Additional Information |
Configurable for 220 : 230 or 240 nominal output voltage |
|
Extended runtime: 0 |
Number of Battery Filled Slots |
0 |
Number of Battery Free Slots |
0 |
Battery Recharge Time |
3 h |
Number of Battery Replacement Quantity |
1 |
Battery Life |
3-5 year(s) |
Replacement Battery |
RBC7 |
Battery Charger Power |
136 W rated |
General |
|
Number of Power Module Filled Slots |
0 |
Number of Power Module Free Slots |
0 |
Product Web Sub-family |
Cloud-enabled monitoring |
Redundant |
No |
Physical |
|
Colour |
Black |
Height |
21.9 cm |
Width |
17.1 cm |
Depth |
43.9 cm |
Net Weight |
24.09 kg |
Mounting Location |
Front |
Mounting Preference |
No preference |
Mounting Mode |
Not rack-mountable |
|
Two post mountable: 0 |
USB Compatible |
No |
Input |
|
Input Voltage Limits |
151-302 V adjustable |
|
160-286 V |
Network Frequency |
50/60 Hz +/- 3 Hz auto-sensing |
Output |
|
Harmonic Distortion |
Less than 5 % |
Maximum Configurable Power in VA |
1500 VA |
Maximum Configurable Power in W |
1000 W |
Transfer Time |
6 ms typical : 10 ms maximum |
UPS Type |
Line interactive |
Wave Type |
Sine wave |
Output Frequency |
50/60 Hz +/- 3 Hz sync to mains |
Conformance |
|
Product Certifications |
CE |
|
EAC |
|
RCM |
|
VDE |
Standards |
EN/IEC 62040-1:2019/A11:2021 |
|
EN/IEC 62040-2:2006/AC:2006 |
|
EN/IEC 62040-2:2018 |
Environmental |
|
Acoustic Level |
45 dBA |
Heat Dissipation |
135 Btu/h |
Operating Altitude |
0-10000 ft |
Ambient Air Temperature for Operation |
0-40 °C |
Ambient Air Temperature for Storage |
-15-45 °C |
Storage Altitude |
0-15240.00 m |
Relative Humidity |
0-95 % |
Storage Relative Humidity |
0-95 % |
Communications & Management |
|
Control Panel |
Multifunction LCD status and control console |
Free Slots |
1 |
Communication Port Support |
SmartConnect Ethernet port: for cloud monitoring feature availability varies by terms of use |
Alarm |
Alarm when on battery: distinctive low battery alarm: overload continuous tone alarm |
Surge Protection and Filtering |
|
Surge Energy Rate |
459 J |
Noise Suppression |
Full-time multi-pole noise filtering: 0.3% IEEE surge let-through: zero clamping response time: meets UL 1449 |
Packing Units |
|
Unit Type of Package 1 |
PCE |
Number of Units in Package 1 |
1 |
Package 1 Height |
37.6 cm |
Package 1 Width |
59.5 cm |
Package 1 Length |
32.8 cm |
Package 1 Weight |
27.23 kg |
Logistical Informations |
|
Country of Origin |
PH |
Contractual Warranty |
|
Warranty |
3 years repair or replace (excluding battery) and 2 years for battery |
