Run time for load |
1000 W |
|
Min-max: 100-1000 W |
|
7min 9s |
Max. Capacity Used |
100 % |
Main Input Voltage |
230 V |
Other Input Voltage |
220 V |
|
240 V |
Main Output Voltage |
230 V |
Other Output Voltage |
220 V |
|
240 V |
Rated power in W |
1000 W |
Rated power in VA |
1500 VA |
Input Connection Type |
IEC 320 C14 |
Output Connection Type |
4 IEC 320 C13 |
|
2 IEC Jumpers C13 |
Number of rack unit |
2U |
Battery type |
Lead-acid battery |
Provided equipment |
Installation guide |
|
Rack mounting support rails |
|
USB cable |
Complementary |
SmartConnect software |
|
Batteries & Runtime |
Run Time |
1000 W |
|
View Runtime Graph |
Efficiency |
View Efficiency Graph |
Additional information |
Configurable for 220 : 230 or 240 nominal output voltage |
Extended runtime |
0 |
Number of battery filled slots |
0 |
Number of battery free slots |
0 |
Battery recharge time |
3 h |
Number of battery replacement quantity |
1 |
Battery life |
3…5 year(s) |
Replacement battery |
APCRBC159 |
Battery charger power |
144 W rated |
General |
Number of power module filled slots |
|
0 |
|
Number of power module free slots |
|
0 |
|
product web sub-family |
|
Cloud-enabled monitoring |
|
Redundant |
|
No |
Physical |
Color |
|
Black |
Height |
8.6 cm |
Width |
43.2 cm |
Depth |
47.7 cm |
Net weight |
26.1 kg |
Mounting location |
Front |
Mounting preference |
Lower |
Mounting mode |
Rack-mounted |
|
Two post mountable |
0 |
USB compatible |
Yes |
Input |
Input voltage limits |
151...302 V adjustable |
|
160...286 V |
Network frequency |
50/60 Hz +/- 3 Hz auto-sensing |
Output |
Harmonic distortion |
|
Less than 5 % |
Maximum configurable power in VA |
1500 VA |
Maximum configurable power in W |
1000 W |
Transfer time |
6 ms typical : 10 ms maximum |
UPS type |
Line interactive |
Wave type |
Sine wave |
Output frequency |
50/60 Hz +/- 3 Hz sync to mains |
Conformance |
Product certifications |
|
CE |
|
EAC |
|
RCM |
|
TÜV |
|
VDE |
Standards |
EN/IEC 62040-1:2019/A11:2021 |
|
EN/IEC 62040-2:2006/AC:2006 |
|
EN/IEC 62040-2:2018 |
Environmental |
Acoustic level |
|
46 dBA |
Heat dissipation |
90 Btu/h |
Operating altitude |
0...10000 ft |
Ambient air temperature for operation |
0…40 °C |
Ambient air temperature for storage |
-15…45 °C |
Storage altitude |
0.00…15240.00 m |
Relative humidity |
0…95 % |
Storage Relative Humidity |
0…95 % |
Communications & Management |
Control panel |
|
Multifunction LCD status and control console |
Emergency power off |
Optional |
Free slots |
1 |
Communication port support |
SmartConnect Ethernet port: for cloud monitoring feature availability varies by terms of use |
Alarm |
Alarm when on battery : distinctive low battery alarm : configurable delays |
Surge Protection and Filtering |
Surge energy rate |
|
459 J |
Noise suppression |
Full time multi-pole noise filtering : 0.3% IEEE surge let-through : zero clamping response time : meets UL 1449 |
Packing Units |
Unit Type of Package 1 |
|
PCE |
Number of Units in Package 1 |
1 |
Package 1 Height |
25.1 cm |
Package 1 Width |
59.4 cm |
Package 1 Length |
60.3 cm |
Package 1 Weight |
31.91 kg |
Unit Type of Package 2 |
P12 |
Number of Units in Package 2 |
4 |
Package 2 Height |
62 cm |
Package 2 Width |
80 cm |
Package 2 Length |
120 cm |
Package 2 Weight |
139.37 kg |
Logistical informations |
Country of origin |
|
PH |
Contractual warranty |
Warranty |
|
3 years repair or replace (excluding battery) and 2 years for battery |
