| Category | Description |
|---|---|
| Main | |
| Run time for load | 1980 W |
| Min-max: 198-1980 W | |
| 7 min 27 sec | |
| Max. Capacity Used | 100% |
| Main Input Voltage | 230 V |
| Other Input Voltage | 220 V |
| 240 V | |
| Main Output Voltage | 230 V |
| Other Output Voltage | 220 V |
| 240 V | |
| Rated power in W | 1980 W |
| Rated power in VA | 2200 VA |
| Input Connection Type | IEC 60320 C20 |
| Output connection type | 8 IEC 60320 C13 |
| 1 IEC 60320 C19 | |
| Number of rack unit | 2U |
| Battery type | Li-Ion (Lithium-Ion) |
| Provided equipment | Rack mounting brackets |
| Rack mounting support rails | |
| Screw | |
| Washer | |
| USB cable | |
| Ethernet patch cable | |
| Complementary | Software package |
| SmartConnect software for remote power monitoring feature availability varies by terms of use | |
| Batteries & Runtime | |
| Run Time | View Runtime Graph |
| Efficiency | View Efficiency Graph |
| Battery graph comments | This graph is based on actual measured runtime data. All measurements were taken with new, fully charged batteries and a balanced resistive load (PF = 1.0). Actual runtimes may vary from the values of this graph. Actual runtimes are dependent on several variables. |
| Extended runtime | 0 |
| Battery recharge time | 2 h |
| Number of battery replacement quantity | 1 |
| Battery design life | 8…10 year(s) |
| Battery charger power | 216 W rated |
| General | |
| Product web sub-family | Cloud-enabled monitoring |
| Redundant | No |
| Physical | |
| Colour | Black with silver front bezel |
| Height | 8.6 cm |
| Width | 43.2 cm |
| Depth | 68.3 cm |
| Net weight | 33.3 kg |
| Mounting preference | Lower |
| Mounting mode | Rack-mounted |
| USB compatible | Yes |
| Input | |
| Input protection type | Circuit breaker |
| Input voltage limits | 160...286 V |
| Network frequency | 50/60 Hz +/- 3 Hz auto-sensing |
| Output | |
| Crest factor | 3 : 1 |
| Maximum configurable power in VA | 2200 VA |
| Maximum configurable power in W | 1980 W |
| Transfer time | 6 ms typical : 10 ms maximum |
| UPS type | Line interactive |
| Wave type | Sine wave |
| Output frequency | 50/60 Hz +/- 3 Hz sync to mains |
| Environmental | |
| Acoustic level | 55 dB |
| Operating altitude | 0...10000 ft |
| Ambient air temperature (operation) | 0…40 °C |
| Ambient air temperature (storage) | -15…45 °C |
| Storage altitude | 0.00…7620.00 m |
| IP degree of protection | IP20 |
| Relative humidity | 0…95 % non-condensing |
| Storage Relative Humidity | 0…95 % non-condensing |
| Communications & Management | |
| Alarm | Audible and visible alarms |
| Control panel | Multifunction LCD status and control console |
| Emergency power off | Yes |
| Free slots | 1 |
| Preinstalled device | Network management card 3 with environmental monitoring |
| Communication port support | SmartConnect Ethernet port: for cloud monitoring feature availability varies by terms of use |
| Packing Units | |
| Unit Type of Package 1 | PCE |
| Number of Units in Package 1 | 1 |
| Package 1 Height | 45.8 cm |
| Package 1 Width | 60 cm |
| Package 1 Length | 98 cm |
| Package 1 Weight | 41.5 kg |
| Logistical informations | |
| Country of origin | PH |
| Contractual warranty | 5 year repair or replace |
| Description | Downloads |
|---|---|
| SMTL2200RMI2UCNC:Datasheet | Download |
| SMTL2200RMI2UCNC:User Guide | Download |
