| Category | Description |
|---|---|
| Overview | Intelligent and efficient network power protection |
| Lead time | Usually Ships within 2 Weeks |
| Main | |
| Run time for load | 5min 45s |
| Main Input Voltage | 230 V |
| Main Output Voltage | 230 V |
| Rated power in W | 1200 W |
| Rated power in VA | 1500 VA |
| Input Connection Type | IEC 320 C14 |
| Output Connection Type | 8x IEC 320 C13 + 2x IEC Jumpers |
| Number of rack unit | 2U |
| Cable length | 1.83 m |
| Number of cables | 1 |
| Battery type | Lead-acid battery |
| Batteries & Runtime | |
| Battery recharge time | 3 h |
| Number of battery replacement qty | 1 |
| Battery life | 3-5 year(s) |
| Replacement battery | APCRBC115 |
| Battery charger power | 103 W rated |
| Physical | |
| Colour | Black |
| Height | 8.9 cm |
| Width | 43.2 cm |
| Depth | 49 cm |
| Net weight | 24.82 kg |
| Mounting preference | Lower |
| Mounting mode | Rack-mounted |
| Input | |
| Switching current capacity | 10 A |
| Input voltage limits | 151-302 V adjustable |
| Network frequency | 50/60 Hz +/- 3 Hz auto-sensing |
| Output | |
| Harmonic distortion | Less than 5 % |
| Maximum configurable power in VA | 1500 VA |
| Maximum configurable power in W | 1200 W |
| UPS type | Line interactive |
| Wave type | Sine wave |
| Output frequency | 50/60 Hz +/- 3 Hz sync to mains |
| Conformance | |
| Product certifications | CE, RCM, VDE, EAC |
| Standards | EN/IEC 62040-1:2019/A11:2021, EN/IEC 62040-2:2006/AC:2006, EN/IEC 62040-2:2018 |
| Environmental | |
| Ambient air temperature for operation | 0-45 °C |
| Ambient air temperature for storage | -15-45 °C |
| Relative humidity | 0-95 % non-condensing |
| Communications & Management | |
| Control panel | Multifunction LCD status and control console |
| Emergency power off | Yes |
| Free slots | 1 |
| Alarm | Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm |
| Surge Protection and Filtering | |
| Surge energy rate | 645 J |
| Noise suppression | Full time multi-pole noise filtering : 5% IEEE surge let-through : zero clamping response time : meets UL 1449 |
| Packing Units | |
| Unit Type of Package 1 | PCE |
| Number of Units in Package 1 | 1 |
| Package 1 Height | 24.6 cm |
| Package 1 Width | 58.9 cm |
| Package 1 Length | 62 cm |
| Package 1 Weight | 30 kg |
| Unit Type of Package 2 | PAL |
| Number of Units in Package 2 | 16 |
| Package 2 Height | 133 cm |
| Package 2 Width | 100 cm |
| Package 2 Length | 120 cm |
| Package 2 Weight | 524 kg |
| Logistical Information | |
| Country of origin | PH |
| Contractual warranty | 3 years repair or replace (excluding battery) and 2 years for battery |
| Description | Downloads |
|---|---|
| SMX1500RMI2U:Datasheet | Download |
| SMX1500RMI2U:User Guide | Download |
