| Run time for load |
6min 15s |
| Main Input Voltage |
208 V, 230 V |
| Other Input Voltage |
220 V, 240 V |
| Main Output Voltage |
230 V |
| Other Output Voltage |
208 V, 220 V, 240 V |
| Rated power in W |
2700 W |
| Rated power in VA |
3000 VA |
| Input Connection Type |
BS1363A British, IEC 320 C20, Schuko CEE 7 / EU1-16P |
| Output Connection Type |
8 IEC 320 C13, 2 IEC Jumpers, 1 IEC 320 C19 |
| Battery type |
Lead-acid battery |
| Provided equipment |
CD with software, Rack mounting support rails, Smart UPS signalling RS-232 cable, Temperature probe, User manual, Web/SNMP management card |
| Batteries & Runtime |
Run Time, Extended runtime, Battery recharge time, Battery life, Replacement battery, Battery charger power |
| General |
Number of power module: 2400, Redundant: No, Physical, Colour: Black, height: 8.5 cm, Width: 43.2 cm, Depth: 66.7 cm, Net weight: 37.32 kg, Mounting location: Front, Mounting preference: Lower, Mounting mode: Rack-mounted, Two post mountable: 0, USB compatible: Yes |
| Input |
Input voltage limits: 140...280 V, Network frequency: 50/60 Hz +/- 3 Hz auto-sensing |
| Output |
Harmonic distortion: Less than 5 %, Maximum configurable power in VA: 3000 VA, Maximum configurable power in W: 2700 W, Transfer time: 2-4 ms, 6 ms typical : 10 ms maximum, UPS type: Line interactive, Wave type: Sine wave, Output frequency: 50/60 Hz +/- 3 Hz sync to mains |
| Conformance |
Product certifications: C-Tick, CE, EAC, GOST, IRAM, VDE, Standards: EN/IEC 62040-1:2019/A11:2021, EN/IEC 62040-2:2006/AC:2006, EN/IEC 62040-2:2018 |
| Environmental |
Acoustic level: 55 dBA, heat dissipation: 184 Btu/h, Operating altitude: 0...10000 ft, Ambient air temperature for operation: 0…40 °C, Ambient air temperature for storage: -15…45 °C, Storage altitude: 0.00…15240.00 m, Relative humidity: 0…95 %, Storage Relative Humidity: 0…95 % |
| Communications & Management |
Control panel: Multifunction LCD status and control console, Emergency power off: Yes, Free slots: 0, Preinstalled device: Network management card 3 with environmental monitoring, Control panel: LED status display with on line : on battery : replace battery and overload indicators, Alarm: Alarm when on battery : distinctive low battery alarm : configurable delays |
| Surge Protection and Filtering |
Surge energy rate: 645 J, Noise suppression: Full time multi-pole noise filtering : 0.3% IEEE surge let-through : zero clamping response time : meets UL 1449 |
| Packing Units |
Unit Type of Package 1: PCE, Number of Units in Package 1: 1, Package 1 Height: 24.3 cm, Package 1 Width: 59.6 cm, Package 1 Length: 86.9 cm, Package 1 Weight: 45.36 kg, Unit Type of Package 2: PAL, Number of Units in Package 2: 8, Package 2 Height: 119 cm, Package 2 Width: 100 cm, Package 2 Length: 120 cm, Package 2 Weight: 382.4 kg, Pallet unit layers: 2, Pallet layers: 4 |
| Logistical informations |
Country of origin: PH |
| Contractual warranty |
Warranty: 3 years repair or replace (excluding battery) and 2 years for battery, optional extended warranties available, optional on-site warranties available |
