This APC Smart-UPS is designed for IT professionals or network administrators to maintain business uptime and continuity. This 1000VA on-line 3U rackmount UPS provides pure sine wave power and extended runtime to support critical electronics during power disruptions. It comes with IEC 320 C14 input and 8x IEC 320 C13 outlets. It has a SmartSlot for optional Network Management Card that enables graceful shutdown of physical servers, virtual machines & HCI Clusters via PowerChute Network Shutdown. The UPS can connect to EcoStruxure IT or third-party centralized management platforms. The UPS has a 5-year warranty on the UPS and Lithium-ion battery.
| Category | Details |
|---|---|
| Main | |
| Run time for load | 29min 45s |
| Max. Capacity Used | 100 % |
| Main Input Voltage | 230 V |
| Other Input Voltage | 220 V |
| 240 V | |
| Main Output Voltage | 230 V |
| Other Output Voltage | 220 V |
| 240 V | |
| Rated power in W | 900 W |
| Rated power in VA | 1000 VA |
| Input Connection Type | IEC 60320 C14 |
| Output Connection Type | 8 IEC 60320 C13 |
| Number of rack unit | 3U |
| Cable length | 1.83 m |
| Number of cables | 1 |
| Provided equipment | CD with software |
| Communication cable | |
| Documentation CD | |
| Installation guide | |
| Removable support feet | |
| USB cable | |
| Warranty card | |
| Batteries & Runtime | |
| Run Time | View Runtime Graph |
| Battery type | Li-Ion (Lithium-Ion) |
| Number of battery filled slots | 0 |
| Number of battery free slots | 0 |
| Battery recharge time | 6 h |
| Battery voltage | 48 V |
| Battery charger power | 103 W rated |
| Battery life | 5…10 year(s) |
| Extended runtime | 1 |
| General | |
| UPS type | Double conversion online |
| Product web sub-family | Lithium-Ion |
| Number of power module free slots | 0 |
| Number of power module filled slots | 0 |
| Redundant | No |
| Physical | |
| Colour | Black with silver front bezel |
| Height | 8.5 cm |
| Width | 43.2 cm |
| Depth | 56 cm |
| Net weight | 13.7 kg |
| Mounting preference | No preference |
| Mounting mode | Rack-mounted with kit |
| Two post mountable | |
| USB compatible | Yes |
| Mounting position | Horizontal |
| Vertical | |
| Input | |
| Network frequency | 40...70 Hz auto-sensing |
| Input voltage limits | 160...275 V (40% load) |
| 80...150 V | |
| Output | |
| Maximum configurable power in VA | 1000 VA |
| Maximum configurable power in W | 900 W |
| Output frequency | 50/60 Hz +/- 3 Hz sync to mains |
| Wave type | Sine wave |
| Harmonic distortion | Less than 2 % |
| Crest factor | 3 : 1 |
| Bypass type | Built-in bypass |
| Conformance | |
| Product certifications | CE |
| EAC | |
| RCM | |
| VDE | |
| Marking | CE Mark |
| Standards | EN/IEC 62040-1:2019/A11:2021 |
| EN/IEC 62040-2:2006/AC:2006 | |
| EN/IEC 62040-2:2018 | |
| Environmental | |
| Ambient air temperature for operation | 0…40 °C |
| Relative humidity | 0…95 % non-condensing |
| Operating altitude | 0...10000 ft |
| Ambient air temperature for storage | -15…45 °C |
| Storage Relative Humidity | 0…95 % non-condensing |
| Storage altitude | 0.00…15240.00 m |
| Acoustic level | 50 dBA |
| Heat dissipation | 400 Btu/h |
| IP degree of protection | IP20 |
| Communications & Management | |
| Free slots | 0 |
| Preinstalled device | Network management card 3 with environmental monitoring |
| Alarm | Audible and visible alarms: prioritized by severity |
| Emergency power off | Yes |
| Surge Protection and Filtering | |
| Surge energy rate | 340 J |
| Packing Units | |
| Unit Type of Package 1 | PCE |
| Number of Units in Package 1 | 1 |
| Package 1 Height | 24.5 cm |
| Package 1 Width | 60 cm |
| Package 1 Length | 81 cm |
| Package 1 Weight | 21 kg |
| Logistical informations | |
| Country of origin | PH |
| Contractual warranty | 5 year repair or replace |
| Description | Downloads |
|---|---|
| SRTL1000RMXLI:Datasheet | Download |
| SRTL1000RMXLI:User Guide | Download |
