| Main | |
|---|---|
| Run time for load | 12000 W |
| Min-max | 1200-12000 W |
| 8 min 17 s | |
| Max. Capacity Used | 100 % |
| Main Input Voltage | 230 V |
| 400 V 3 phases | |
| Product or component type | Uninterruptible power supply (UPS) |
| Other Input Voltage | 220 V |
| 240 V | |
| Main Output Voltage | 230 V |
| Other Output Voltage | 220 V |
| 240 V | |
| Rated power in W | 12000 W |
| Rated power in VA | 15000 VA |
| Output connection type | 2 IEC Jumpers |
| 8 IEC 60320 C19 | |
| Output connector type | Hard wire 3-wire (H N + E) 1 |
| Hard wire 5-wire (3P + N + E) 1 | |
| Number of rack unit | 12U |
| Provided equipment | CD with software |
| Rack mounting support rails | |
| Smart UPS signaling RS-232 cable | |
| User manual | |
| Web/SNMP management card | |
| Batteries & Runtime | |
| Number of battery free slots | 0 |
| Number of battery filled slots | 0 |
| Battery voltage | 12 V |
| Number of battery replacement quantity | 4 |
| Battery type | Lead-acid battery |
| Battery recharge time | 2.5 h |
| Battery life | 3…5 year(s) |
| Replacement battery | APCRBC140 |
| Extended runtime | 1 |
| General | |
| UPS type | Double conversion online |
| Number of power module free slots | 0 |
| Number of power module filled slots | 0 |
| Redundant | No |
| Physical | |
| Colour | Black |
| Height | 53.3 cm |
| Width | 43.2 cm |
| Depth | 77.3 cm |
| Net weight | 247.73 kg |
| Mounting location | Front |
| Mounting preference | Lower |
| Mounting mode | Rack-mounted |
| Two post mountable | |
| USB compatible | No |
| Input | |
| Network frequency | 40...70 Hz auto-sensing |
| Number of input connectors | 1 hard wire 3-wire (1P + N + E) |
| 1 hard wire 5-wire (3P + N + E) | |
| Input voltage limits | 160...280 V |
| Maximum input current | 90 A |
| Switching current capacity | 100 A |
| Input harmonic distortion | Less than 5 % for full load |
| Input current | 90 A (1 phase) |
| 30 A per phase (3 phases) | |
| Load power factor | 0.8 |
| Input Power Factor at Full Load | 0.95 |
| Output | |
| Maximum configurable power in VA | 15000 VA |
| Maximum configurable power in W | 12000 W |
| Output frequency | 50/60 Hz +/- 3 Hz user adjustable +/- 0.1 Hz sync to mains |
| Wave type | Sine wave |
| Output overload operation | 60 seconds at 125% and 30 seconds at 150% |
| Efficiency | 93 % (in battery operation) |
| Harmonic distortion | Less than 5 % |
| Crest factor | 3 : 1 |
| Bypass type | Built-in static bypass |
| Internal bypass (automatic and manual) | |
| Optional external bypass | |
| Additional information | Configurable for 380 : 400 or 415 V 3 Phase nominal output voltage |
| Conformance | |
| Product certifications | VDE |
| Standards | EN/IEC 62040-1:2019/A11:2021 |
| EN/IEC 62040-2:2006/AC:2006 | |
| EN/IEC 62040-2:2018 | |
| Environmental | |
| Ambient air temperature for operation | 0…40 °C |
| Relative humidity | 0…95 % non-condensing |
| Operating altitude | 0...10000 ft |
| Ambient air temperature for storage | -15…45 °C |
| Storage Relative Humidity | 0…95 % non-condensing |
| Storage altitude | 0.00…15240.00 m |
| Acoustic level | 50 dBA |
| Heat dissipation | 2800 Btu/h |
| IP degree of protection | IP20 |
| Communications & Management | |
| Free slots | 0 |
| Preinstalled device | Network management card 2 with environmental monitoring |
| Emergency power off | Yes |
| Surge Protection and Filtering | |
| Noise suppression | Full time multi-pole noise filtering : 0.3% IEEE surge let-through : zero clamping response time : meets UL 1449 |
| Packing Units | |
| Unit Type of Package 1 | PCE |
| Number of Units in Package 1 | 1 |
| Package 1 Height | 99 cm |
| Package 1 Width | 61 cm |
| Package 1 Length | 100.3 cm |
| Package 1 Weight | 314.09 kg |
| Unit Type of Package 2 | PAL |
| Number of Units in Package 2 | 2 |
| Package 2 Height | 112 cm |
| Package 2 Width | 100 cm |
| Package 2 Length | 120 cm |
| Package 2 Weight | 626.864 kg |
| Contractual warranty | |
| Warranty | 2 years repair or replace |
| Description | Downloads |
|---|---|
| SURT15KRMXLI:Datasheet | Download |
| SURT15KRMXLI:User Guide | Download |
