| Camera |
|
| Image Sensor |
1/2.8” 4K Exmor CMOS |
| Effective Picture Elements |
8 Megapixels |
| Output Resolutions |
4K/60, 4K/59.94, 4K/50, 4K/30, 4K/29.97, 4K/25, 1080p/60, 1080p/59.94, 1080p/50, 1080p/30, 1080p/29.97, 1080p/25, 1080i/60, 1080i/59.94, 1080i/50, 720p/60, 720p/59.94, 720p/50 |
| Minimum Illumination |
0.46 lux (IRE50, F1.6, 30fps) |
| S/N Ratio |
≥ 50 dB |
| Gain |
Auto, Manual |
| TV Lines |
1600 (Center/Wide) |
| Shutter Speed |
1/1 to 1/32,000 sec |
| Exposure Control |
Auto, Manual, Priority AE (Shutter, IRIS), BLC, WDR |
| White Balance |
Auto, Manual, ATW, One Push |
| Optical Zoom |
12X |
| Digital Zoom |
12X |
| Total Zoom |
144X |
| Viewing Angles |
DFOV: 80.6° (Wide) to 7.7° (Tele), HFOV: 72.8° (Wide) to 6.7° (Tele), VFOV: 44.1° (Wide) to 3.8° (Tele) |
| Focal Length |
f = 3.9 mm (Wide) to 46.8 mm (Tele) |
| Aperture (Iris) |
F = 1.6 (Wide) to 2.8 (Tele) |
| Minimum Working Distance |
0.3 m (Wide), 1.5 m (Tele) |
| Pan / Tilt Angles |
Pan: ±170°, Tilt: +90° / -30° |
| Pan / Tilt Speed (Manual) |
Pan: 0.1° to 100° / sec, Tilt: 0.1° to 100° / sec |
| Preset Speed |
Pan: 200° / sec, Tilt: 200° / sec |
| Preset Positions |
10 (IR), 256 (RS-232, RS-422, IP) |
| Camera Control - Interfaces |
|
| Interfaces |
RS-232 (DIN8), RS-422 (RJ45), IP |
| Protocols |
VISCA (RS-232 / RS-422 / IP), PELCO-D & PELCO-P (RS-232 / RS-422), CGI (IP), ONVIF |
| Image Processing |
|
| Processing Features |
Noise Reduction (2D / 3D), Flip, Mirror |
| Power Frequencies |
50 Hz, 60 Hz |
| AI Function Mode |
SmartShoot |
| Audio |
|
| Channels |
2ch Stereo |
| Codecs |
AAC-LC |
| Interface |
|
| Video Outputs |
3G-SDI, HDMI, IP, USB |
| Audio Outputs |
3G-SDI, HDMI, IP, USB |
| Audio Inputs |
MIC in, Line in |
| General |
|
| Power Requirement |
AC 100 - 240V to DC 12V/2A |
| Power Consumption |
19W |
| PoE |
PoE+ |
| Dimensions (W x H x D) |
180.0 x 192.0 x 145.0 mm |
| Net Weight |
2.0 (±0.1) kg |
| Application |
Indoor |
| Tally Lamp |
Yes |
| Security |
Kensington Slot |
| Remote Control |
Infrared |
| Operating Conditions |
Temperature: 0 °C to +40 °C; Humidity: 20% to 80% |
| Storage Conditions |
Temperature: -20 °C to +60 °C; Humidity: 20% to 95% |
| IP Streaming |
|
| Resolution |
4K 60fps |
| Network Video Compress Formats |
H.264, H.265, MJPEG |
| Maximum Frame Rate |
4K 60fps |
| Bit-Rate Control Modes |
VBR, CBR (selectable) |
| Range of Bit-Rate Setting |
512 Kbps to 120 Mbps |
| Network Interface |
10 / 100 / 1000 Base-T |
| Multi-Stream Capability |
4 |
| Streaming Capabilities |
4K 60fps: RTSP, HDMI & USB; 1080p 60fps: 3G-SDI |
| Network Protocols |
IPv4, TCP, UDP, ARP, ICMP, IGMP, HTTP, HTTPS, DHCP, RTP / RTCP, RTSP, RTMP, SRT, HLS, NDI, LLDP, VISCA over IP |
| NDI |
N/A |
| Genlock |
N/A |
| USB |
|
| Connector |
USB 3.1 |
| Video Formats |
MJPEG, YUY2 |
| Maximum Video Resolution |
2160p |
| USB Video Class (UVC) |
UVC 1.1 |
| USB Audio Class (UAC) |
UAC 1.0 |
| Web UI |
|
| Live Video Preview |
Yes |
| Camera PTZ Control |
Pan, Tilt, Zoom, Focus, Preset Control |
| Camera / Image Adjustment |
Exposure, White Balance, Picture |
| Network Configuration |
DHCP, IP Address, Gateway, Subnet Mask, DNS |
| Software Tools |
IP Search and Configuration Tool, PTZ Management, PTZ Control Panel, PTZ Link, OBS Plugin for PTZ Cameras, CaptureShare |
| OS Support |
Windows® 7 or later, macOS® 10.14 or later |
| Warranty |
|
| Camera |
5 Years |
| Accessories |
1 Year |
| Package Contents |
|
| Included Accessories |
Camera, Drilling Paper, Ceiling Mount Bracket (x2), Quick Start Guide, Cable Fixing Plate, M2 x 4 mm Screw (x3), Power Adapter & Power Cord, 1/4”-20 L=6.5 mm Screw (x2), Remote Control, M3 x 6 mm Screw (x3), DIN 8 to D-Sub 9 Cable, RS-232 In/Out Y Cable, Cable Ties (x4) |
| Optional Accessories |
AVer CL01 PTZ Camera Controller, L-Type Wall Mount |
